These switch solutions feature low noise, low voltage and low on-resistance with 50 functions offered in SPST, SPDT and Mux.
|
|
|
The MT093 is fabricated in ISO-CMOS technology providing low power dissipation and high reliability. The device contains a 8x12 array of crosspoint switches along with a 7 to 96 line decoder and latch circuits. Any one of the 96 switches can be addressed by selecting the appropriate seven input bits. The selected switch can be turned on or off by applying a logical one or zero to the DATA input.
|
|
New Analog Switching ICs - Operating Range of 2.7 V to 12 V
DG9051, DG9052, DG9053
- Input voltage range of 2.7 V to 12 V for single supply implementations and ±2.7 V to ±6 V for dual-supply implementations
- Bi-directional signal, rail-to-rail analog signal handling
- Guaranteed 2-V logic high/0.8-V logic low when operating from a single 5-V or dual ±5-V power supplies
Low Rds (on) Analog Switch Family: DG271x, DG274x, and DG2799
- Designed for Direct Battery Operation
- Low level logic control - full voltage range (1.6 V to 4.3 V)
- Rds (on) as low as 0.25 Ω typ. @ 2.7 V
- Supports continuous current up to 300 mA for Reed Relay replacement
- For portable apps.: cell phones, PDAs, set-top boxes, gaming
|
|
austriamicrosystems analog switch family offers lowest on-resistance, excellent matching, fastest switching times and outstanding overall performance, making it ideal for demanding applications in the communications and industrial markets.
AS1741: Dual 0.8 Ohm SPST Switch NO
AS1742: Dual 0.8 Ohm SPST Switch NC
AS1743: Dual 0.8 Ohm SPST Switch NO/NC
AS1744: Dual 4 Ohm SPDT Switch NO/NC
AS1745: Dual 4 Ohm SPDT Switch NO/NC
AS1746: Dual 0.5/0.6Ohm, Low Voltage, SPDT Switch, NC/NO
AS1751: Quad 0.9 Ohm SPST Switch NO
AS1752: Quad 0.9 Ohm SPST Switch NC
AS1753: Quad 0.9 Ohm SPST Switch NO/NC
|
|
| ... products without technical information |
| |
FEATURES:
110mW (5V Input) High-Side MOSFET Switch.
500mA Continuous Load Current per Channel.
220mA Typical On-State Supply Current.
1mA Typical Off-State Supply Current.
Current-Limit / Short Circuit Protection.
Thermal Shutdown Protection under Overcurrent Condition.
Undervoltage Lockout Ensures that Switch is off at Start Up.
Output can be Forced Higher than Input (Off-State).
Open-Drain Fault Flag.
Slow Turn ON and Fast Turn OFF.
Enable Active-High or Active-Low.
APPLICATIONS:
USB Power Management.
Hot Plug-In Power Supplies.
Battery-Charger Circuit.
|
|
|
Analog Devices' X-stream%u2122 family of digital switches includes high speed crosspoint and 2:1 Mux/DeMux switches. Analog Devices crosspoint and 2:1 Mux/DeMux switches are ideal for WDM, enterprise and metro networking systems commonly employed by Internet service providers, data centers, telecom central offices, and storage area networks. These crosspoint switches are also suited for broadcast video applications.
|
|
|
|
