With its modern design and functions, its compact size and ergonomic shape, SYMPATY is an easy-to-use compilation of simple technology, offering the opportunity for increased productivity and a guarantee of the quality of the packaged product.
3-step filling process: 1) tap removal. 2) removes air from the bag, meters flow and fills bag – nitrogen injection (if option) 3) tap fitting.
TECHNICAL SPECIFICATIONS
Liquid flow rate: 82 HL/h
Air pressure: 6 bar
Power: 1 KW
Voltage: 220 / 380 V
Frequency: 50 / 60 HZ
Air consumption: 1 bar
Nitrogen pessure : 0.3 m3/h
GENERAL SPECIFICATIONS
Minimum height in mm: 1500
Width in mm: 700
Depth in mm: 1000
Weight in kg: 80
|
|
A modern, upgradable, automated filling machine, the Premia is ideal for medium and large-scale fiiling of vacuum bags and rigid containers from 2 tp 30 litres. The Premia carries out the following operation completely automaticallty : Begins filling cycle (DAS system) - removes top - removes air from the bag, meters flow and fills bag - nitrogen injection ( if option) - fits top - ejects the filled bag.
TECHNICAL CHARACTERISTICS
Liquid flow rate 82 HL/h
Air pressure 6 bar
Power 1KW
Voltage 220 / 380 V
Frequency 50 / 60 HZ
Air consumption 1 bar
Nitrogen pessure 1 m3/h
GENERAL SPECIFICATIONS
Minimum height in mm 1580
Width in mm 750
Depth in mm 930
Weight in kg 103
|
|
A modern, upgradable, high-performance filling machine, the Advance is ideal for medium and large-scale fiiling of vacuum bags and rigid containers from 2 tp 30 litres. The chassis is made entirely of stainless steel. The Advance carries out the following operation completely automaticallty : begins filling cycle (DAS system) - removes top - removes air from the bag, meters flow and fills bag - nitrogen injection ( if option) - fits top - ejects the filled bag.
TECHNICAL CHARACTERISTICS
Liquid flow rate 125 HL/h
Air pressure 6 bar
Power 2 KW
Voltage 220 / 380 V
Frequency 50 / 60 HZ
Air consumption 1 bar
Nitrogen pessure 1.8 m3/h
GENERAL SPECIFICATIONS
Minimum height in mm 1670
Width in mm 750
Depth in mm 930
Weight in kg 120
|
|
|
|
|
|
A totally new, fully-patented « 3 in 1 » concept, LINEA PACK® PACK offers the following range of functions in one single, exclusive machine unit : a cardboard box shaper, an automatic filling machine and a box sealer incorporating the Hot-Melt system. Extremely compact and space-saving, ideal for fixed or mobile filling lines LINEA PACK® provides a compilation of modern technology offering the opportunity for increased productivity while ensuring the quality of the packaged product.
Scope of application : Wine, fruit juice, water, milk, syrup, alcoholic beverages, soup... LINEA PACK® LINEA can be used to fill vacuum bag containers ranging from 2 to 20 litres Suitable for use with the following tap models: Vitop, Flex-Tap, Press-Tap, Vinitap. Other models as option.
STANDARD EQUIPMENT :
- Filling head which guarantees non-drip filling
- Hydraulic circuit which can be sterilised with hot water, steam or chemicals
- Siemens Touch screen with integrated modem (optional modem card) displaying
the different operating modes : work, maintenance, settings (with « repeat
» function), cleaning,...
- Integrated CIP circuit with liquid outlet for fixed work stations and
automated cleaning of vacuum and nitrogen circuits
- Vacuum monitoring and control : pressure and activation (integrated
anti start-up safety device)
- 360° multi-directional finger retainer plate
- Box shaper with squaring, bottom sealing and pressing functions
- Bag, tap and box detection... with associated alarm signals
- Overlapping flap closure kit as standard on box shaper and sealer
- Bag insertion chute adaptable to all box formats
- Post-insertion bag compacting function...
|
|
Autokap™1200 Series Single-Head Fully-Automatic filler can fill:
- 3 litre bags at up to 16 bags per minute
- 5 litre bags at up to 14 bags per minute
- 10 litre bags at up to 11 bags per minute
- 20 litre bags at up to 9 bags per minute.
Filler Description
- Autokap™ 1200 is a Single-Head Fully-Automatic bag filler ideal for a large range of fresh or stable liquid products.
- The filler can fill bags from 1.5 to 25 litres in capacity.
- Autokap™1200 is Servo driven and is designed for automatically loading bags into boxes.
- Each filler is specified for the required type of liquid to fill. A large range of fitments is compatible with the Autokap™1200 series.
- Up to four fillers can be installed as integrated pair for high output applications.
|
|
Autokap™1400 Series Single-Head Fully-Automatic filler can fill:
- 3 litre bags at up to 32 bags per minute (16 bags per minute per head)
- 5 litre bags at up to 26 bags per minute (13 bags per minute per head)
- 10 litre bags at up to 22 bags per minute (11 bag per minute per head)
- 20 litre bags at up to 16 bags per minute (8 bag per minute per head)
Filler Description
- Autokap™ 1400 is a Fully-Automatic bag filler ideal for a range of fresh or stable liquid products. It is available both as a single or twin head filler.
- The filler is designed to fill 1.5 to 25 litre bags in capacity.
- Autokap™ 1400 is designed for automatically loading bags into boxes.
- Each filler is designed for the required type of liquid to fill. A large range of fitments is compatible with the Autokap™ 1400 series.
- A box conveyor can be fully integrated to the filler (available as option.)
|
|
Production is dependent on product supply conditions and the dexterity of the operator.
Typical examples of output based on water are the following:
- 1000 litre bags at up to 7 to 12 bags per hour
- 200 litre bags at 20 to 25 bags per hour.
Filler Description
- Autokap™ 1000 is a Single-Head Semi-Automatic Bulk filler that can fill bags ranging from 250 to 1400 litre directly into drums and bins.
- The filler is setup to run a center glanded bag usually supplied in a folded format.
- After loading the bag, the fill head moves to the bottom of the container and rises as the bag fills from the bottom of the container.
- Fillers are specified for the required type of liquid to fill. The Autokap™1000
series is compatible with a large range of fitments.
|
|
|
|
|
|
Sterikap™ 890 Single-Head Semi-Automatic Aseptic filler can fill:
- 5 litre bags at 3 to 4 bags per minute
- 10 litre bags at 2 to 3 bags per minute
- 20 litre bags at 1 to 2 bags per minute
Sterikap™ 820 Single-Head Semi-Automatic Aseptic Filler Extended Shelf Life (ESL) filler can fill:
- 5 litre bags at 5 to 6 bags per minute
- 10 litre bags at 3 to 4 bags per minute
- 20 litre bags at 2 to 3 bags per minute
Filler Description
- The Sterikap™ 800 is a Single-Head Semi-Automatic bag filler ideal for a range of Aseptic and Extended Shelf Life (ESL) products.
- The filler can fill bags from 1.5 to 25 litres in capacity and be fitted with a variety of taps, caps and tubes.
- Sterikap™ 800 is ideal for startup and medium production. Bags are manually loaded into the filler. After filling, they are released for loading into boxes.
- The fill chamber and all product lines are automatically cleaned in place (CIP) after each production run and sterilized in place (SIP) before each run.
- The fill chamber is fully enclosed and sterility is maintained during production with a combination of steam, sterilant water or sterile air.
|
|
Intasept™ 2400 Single-Head Semi Automatic Aseptic filler for the 32mm gland format can fill:
- 5 litre bags at up to 4 bags per minute
- 10 litre bags at up to 3 bags per minute
Filler Description
- The Intasept™ 2400 Single-Head Semi-Automatic Aseptic range can fill bags from 2 to 30-litres in capacity.
- Bags are manually loaded into the filler. After filling, they are released to the rear of the machine for loading into boxes.
- The fill table can be adjusted to allow manual filling of 210 litre bags into drums (available as option).
- Two fillers can be installed as an integrated pair for twin-head operation.
- Intasept™ 2400 is available with 16mm or 32mm fill head. The filler is available in a qualified version for biomedical and pharmaceutical applications.
|
|
