Electronic DC braking, suitable for all asynchronous motors, especially suitable for retrofitting into existing plants, extending the life of drive units by infinitely variable braking torque, wear-resistant and maintenance-free
|
|
DC braking with one-way rectification
suitable for all asynchronous motors and for mono phase motors
controlled by microcontroller
easy mounting, also for retrofitting into existing plants
wear-resistant and maintenance-free
integrated braking contactor
printed circuit-board version with fault signalling contact
for snap-on mounting onto 35mm DIN rail
degree of protection: case version IP 20, printed circuit-board version (LP) IP 00
meets trade assoc. requirements for category 2 acc. to EN 954-1 according to the test principles of woodworking machines GS-HO-01 and is already certified
|
|
|
|
|
|
¨ Rapid braking of three-phase induction motors fed by frequency inverters without an integrated braking chopper
¨ Elimination of production stops due to unwanted inverter tripping caused by overvoltage in the DC link
Applications
Braking of three-phase drives fed from frequency inverters,
in particular:
¨ Drives with a large inertia, e.g. large fans, centrifuges
¨ Drives with requirement for rapid braking, e.g. saws, planing and milling machines
¨ Drives for transport, long travel and hoisting applications
¨ Retrofit to existing inverters without a braking chopper e.g. to avoid nuisance tripping with link overvoltage.
¨ Often a price advantage compared to braking choppers of original inverter manufacturer
Features
¨ Compatible with all frequency inverters with a DC voltage link operating at input voltages up to 3 AC 690 V
¨ Simple wiring without control voltage - only two cables to the DC link required
¨ Integrated braking resistor with TRANSOMIK B
¨ External braking resistors with overtemperature protection (OPTION BR) with TRANSOMIK BC
¨ Adjustable brake threshold-voltage;
- TRANSOMIK B: • Factory adjustable
- TRANSOMIK BC: • Switchable preset values
¨ TRANSOMIK BC is especially suitable for quasi- continuous braking duty (e.g. heavy-duty braking for crane drives)
¨ Special monitoring functions with TRANSOMIK BC:
- Heat sink overtemperature trip
- Additional with TRANSOMIK BC2:
- Monitoring LED's
• Electronic overload-monitoring of brake resistor
• Fault latch with relay output
¨ TRANSOMIK BC2 can be paralleled for higher braking powers
|
|
The motor start and braking device of the VersiComb series from PETER electronic, for motor ratings up to 15KW, represents an alternative with a good cost-performance ratio in order to replace star-delta starting in combination with a d.c. braking device.
The devices of the VersiComb II type enable soft start and wear-free braking of three-phase asynchronous motors. Their advantages in comparison with direct-on-line starting or star-delta starting are a torque increase without jerk and current reduction during the starting phase.
This gives the mechanical system and the drive components a longer life.
|
|
|
|
