An innovative programme of high performance solid carbide drills offering an optimum blend of performance, tool life and hole quality:
- Spotting Drills
- Stub Drills
- 3 Flute Drills
- Jobber Drills
- Double Margin Drills
- Drills for Aluminium
- Drills for Stainless Steel and Exotic Materials
- Multi-Application Drills
- Straight Flute Drills
- Drills for Deep-Hole Applications
- Replaceable Head Drills
|
|
|
|
|
|
CoroDrill Delta-C R846
Sandvik Coromant has developed a new drill, CoroDrill Delta-C R846, for Heat Resistant Super Alloy machining in aerospace applications, such as the production of gas turbine casings. The new drill is designed for the continuous and reliable production of holes in demanding HRSA materials, which place heavy demands on the cutting edge. The geometry of the new CoroDrill Delta-C is optimised for maximum efficiency in repeat short hole drilling. The new cutting edge has a more consistent curve for added strength in the outer corners where cutting forces can be highest in demanding applications. This distributes the cutting forces evenly over the cutting edge – giving an even wear without sudden changes.
CoroMill Plura
The CoroMill Plura solid carbide endmill family covers most milling applications from roughing to superfinishing, keyslot milling and chamfering.
The endmills are designed with several length options to maximise productivity from short to long reach. They are supplied in diameters from 0.4 - 25 mm and also available in an multi-edged version for super finishing and a spherical version for optimised accessibility.
CoroMill Plura endmills are supplied in three different carbide grades covering wet and dry milling in steels, stainless steels, cast iron, heat resistant super alloys, hardened materials as well as aluminium.
|
|
The CHAMDRILLJET family features high volume production with incredible chip evacuation.
ISCAR's gundrills are for applications requiring high precision deep drilling.
- Specially tailored - drilling tools upon request
- Solid carbide drills
- UNICHAMDRILL
- Carbide drill heads, twist drill
- CHAMDRILLJET
- DR Drill inserts, soft cut
- Drilling, DZ Drill types and diameter range
- PICCOMF
- Metal chamfering tools, chamfering rings
- The PRE-THREAD DCT CHAMDRILL
- New modular chamfering drill holders
|
|
Solid Carbide Endmills
High precision and wear resistance of solid carbide tools are a guarantee of success for economically effective cutting operations.
The new Tungaloy endmill series reaches exactly this high demand of performance. It features a wide range of tools for different milling operations of various work materials such as steels, stainless steels, hardened steels and nonferrous metals. As a result of our new development and field testing we are able to offer a new series of end mills with numerous cutting angles, made to fit the standards of work materials. Because of an oxidation resistant and stable coating (TiAlN-PVD), endmilling can proceed even at high speed. The simultaneous high process stability and reliability of the new Tungaloy solid carbide endmills can result in a decrease of production time and employee investment.
|
|
METRIC SIZES from 3mm to and including 16mm
SGS Tool Company adds to its High Performance Drill line with the introduction of Ice-Carb, an Internal Coolant Drill for drilling depths up to 7 x Diameter.
ICe-Carb%u2019s unique geometry features enhance coolant flow and chip removal. Each tool comes with SGS%u2019 exclusive Ti-NAMITE-A (AlTiN) tool coating for higher thermal stability and greater wear resistance in deep hole drilling.
The tool%u2019s drilling depth potential eliminates the need for pecking in most applications and the corner protection increases tool life.
|
|
ENGINEERED HARDFACING :
Shaped carbide, either discs or stars, are brazed onto drilling tools that are used to cut steel casing or to help remove down-hole junk.
|
|
Solide carbide drills
Coated and uncoated high-performance drills for both dry and wet drilling applications
|
|
Solid Carbide Drilling
KMT high performance HP Solid Carbide Drills offer the highest metal removal rate in the industry. Bottom line savings from increased speed can result in cost savings up to 50% versus competitor's products. With through coolant diameter ranges from 3,00 mm to 21,00 mm (.118" to 1.011"), the HP drill series is application specific in steel, stainless steel and high temperature alloys, and iron.
210/211/212 HP KC7515
For stainless steel and high temperature alloys.
224/225 HP KC7315
Ultra high speed drilling
254/255/256HPC KC7315
Excellent hole quality in regards to straightness ...
|
|
|
The Miller high-performance drilling tools fit perfectly into the HPC philosophy of the MAPAL Group. The Mega Drill drilling tool series provides high-performance tools for solid drilling. Special cutting edge geometries which are well-suited to the material to be machined ensure technological advantages and the excellent economic efficiency of all solid carbide drilling tools. Besides the extensive standard product range also special tooling solutions for special applications can be provided.
|
|
PCB Drills
Micron -Drills, designed for drilling printed circuit boards, play significant roles for developing electronics-related industry. They promise high-precision and high-efficiency drilling of various circuit boards with long tool life, including multilayer boards. Tungaloy’s advanced technology, with development and manufacturing of carbide materials for drills, does not allow competitors to imitate.
|
|
DATRON Mini-Tools
High Speed Cutting Tools
On the basis of our testings and the experiences of our customers we develop special tools for high-speed machining.
Efficiency and quality of CNC-Machining is exceedingly determined by the technological design and the quality of the CNC-Tools. As a result of our long-term experience DATRON is able to offer tool models in the range of Mini-Tools that provide a high-quality and remarkably faster machining than any other competitive product.
|
|
The use of the highly wear and oxidation resistant Miracle Coating achieves long tool life at extreme feed rates or during high temperature conditions experienced during deep drilling operations.
This range of drills achieves state of the art performance and hole precision even under the toughest cutting conditions.
Ask our experts more. MPS drills on demonstration every day at EMO, Mitsubishi Materials, Hall 5, Stand D20.
Available from Ø3.0 – Ø20 l/d x 3, and up to l/d 30 for diameters up to 10mm.
|
|
|
Solid Carbide Drills in Jobber Length...Fast Sprial...Three Flute...Straight Flute...Flat Drills...and Conbide Drill and Countersinks. Fractional and Metric Sizes
|
|
MDS and KDS Drills meet the industry demand for effective and efficient driling of steels, cast irons and exotic materials. Available in large to very small diameters, they offer excellent productivity and about 10 times the tool life of HSS drills.
• Increased strength - A thicker web and narrower flute increase torsional rigidity throughout the drill body, reducing oversizing and improving surface finish.
• Lower cutting forces - Positive radial rake angles significantly reduce cutting force, torque and power requirements.
• Better chip removal - The cutting edge geometry, formed by the concaved cutting edge and flute wall produces short, curled chips which are easily evacuted.
• Advanced tool materials - A titanium substrate increases tool strength, while PVD coating improves wear, adhesion-resistance and cutting forces.
|
|
|
|
|
|
Sutton Tools recognises the relentless challenge facing metal working industries to produce faster and more efficiently than ever before and is pleased to provide the high performance market with the most cost efficient cutting solution with the release of it’s High Performance Range of Drills.
The comprehensive range of high performance drills now includes Cobalt and Vanadium based grades of high speed steel(HSS-Co, HSSE-V), as well as the latest developments in Powdered Metallurgy high speed steel (PM-HSS) and Carbide ranges, manufactured to DIN standards, which are complemented by TiN, TiCNite, AITiN (multi-layer) and CrN ceramic surface coatings and state of the art Vacuum Heat Treatment.
There are so many variables that affect the final outcome, and hence overall cost effectiveness of a job, that selecting the right drill can be some what of a challenge.
However the Sutton High Performance Range has simplified this task, by colour coding the tools to the material group in which it is intended for, allowing you to quickly select the most suitable tool for your job.
For more information visit our website on http://suttontools/IndustrialDrills
|
|
Dormer offer a range of solid carbide and carbide tipped reamers in several variations to meet the demands of higher productivity machining:
- NC High Speed Precision Reamers
- Machine Reamers with Extremely Unequal Spacing
- NC Centesimal Reamers for High Precision Chucks
- Expanding Machine Reamers
|
|
Typ 507 Reamer:
Solid reamer, left hand spiral 8-10°, extreme
differential pitch. Solid carbide tip 6-11 mm,
brazed fl utes Ø 12-40 mm. Grade ISO K10.
DIN8094 Form B.
Type 507C Reamer:
Solid reamer, left hand spiral 8-10°,
extreme differential pitch. Solid carbide
tip 6-11 mm, brazed fl utes Ø 12-40
mm. Grade ISO K10.
Type 509 Reamer:
Solid reamer, straight flutes, extreme differential pitch.
Grade ISO K10. DIN 8051 Form A.
Type 509C Reamer:
Solid reamer, straight flutes, extreme differential pitch.
Grade ISO K10.
Type 509CC Reamer:
Solid reamer, straight flutes, extreme differential.
Cermet: high cutting speed and wear resistance
in steel and cast iron applications. The optimum
solution when the cutting conditions are stable.
Common features:
- Reamers are stocked in tolerance H7 and also
semi-finished for quick
conversion to customers' requirements.
- Differential pitched flutes, for round holes and elimination of vibration.
- Lapped flutes for a better surface finish.
|
|
Solid Carbide Drills
2 Flute - 118° Four Facet Point
3 Flute - 130° High Performance Point
Cutting Edge Tolerance/Shank Tolerance +.000 - .0002
|
|
| ... products without technical information |
| |
Posimatic™ - Swiss Automatic
Stellram has a range of tools for use on Swiss Auto type lathes with small cross section shanks from 0.375” (10mm) square to 0.750” (20mm) square. Grades and geometries are available to handle the specific feeds and speeds associated with these machines.
Some other features of this program are:
- Nose radii starting at 0 for excellent surface finishes and sharp internal corners
- New –62 geometry and new PVD technology
- Equal shank and tool tip dimensions on all toolholders for programming ease
- Boring bars with standard coolant holes to aid in chip evacuation
- Part-off inserts from 1.6mm/0.063” to 3.0mm/.118” widths
- Integral shank cutoff and grooving holders for maximum rigidity
- Back turning holders and inserts for turning behind a shoulder eliminates additional operations
- Tungsten Carbide reinforced boring bars to eliminate chattering
|
|
The surface plate centers are very portable and can be used
With less strain and effort the the heavy cast iron base centers
, without sacrificing accurancy .they also minimize space requirements on your surface plate .
All components are replaceable including the hardened tool stell centers
|
|
HSK system developed for leading turn-mill machines.
Highly accurate and rigid toolholders using the new HSK-T(ICTM) standard.
What is HSK-T and the ICTM standard.
ICTM is an open standard jointly developed by a consortium of leading Japanese manufacturers based on the ISO 12164-1:2001 HSK standard shank.
It is a highly accurate and rigid face contact type aiming at improving tool accuracy by utilising a high tolerance key fit. Additionally, ICTM standard tools are compatible with the widely used HSK-A type. The ICTM standard is now acknowledged as HSK-T.
|
|
ANSI Combo Toolholders
- A multiple-clamp and lock pin design for NC/CNC machines
- Maximum insert locking power with industry-standard NL lock pin mechanism
- Two different assembly options: 1. for unground P-Type inserts 2. for conventional precision-ground or utility-ground inserts with chipbreaker plates
|
|
|
|
