Epson audio solutions offer a wide range of applications such as speech enabled portable devices, assistive applications for visually / speech impaired persons, educational toys, mobile handsets (ring tones and music playback) portable music players, automotive audio systems and automotive navigation systems.
Voice synthesis IC product corresponding to several languages that can be voice conversions.
Seiko Epson Corporation ("Epson") today announced it has developed a new synthesis chip for embedded applications featuring Fonix text-to-speech (TTS). The S1V30120 is a companion chip that converts text-based characters into a synthetic speech signal, which is output via the integrated D/A converter. Since it uses a message protocol based on a clock-synchronous serial interface, the chip can be easily integrated with a wide range of host devices and microcontrollers.
The S1V30120 also supports decoding of ADPCM data, which allows mixtures of pre-recorded speech and synthetic speech to be combined as required. (For example, fixed phrases could be implemented using pre-recorded signals, while variable phrases would be synthesized.)
Target applications include a wide range of systems that require voice guidance such as those embedded in home appliances, buildings, and office/industrial equipment.
|
|
CS42324(detail) 10 Single-ended Inputs 6 Single-ended Outputs
Power supply VA = 9 or 12;VD = 3.3;VL = 1.8 or 3.3
Type multi channel
|
|
Features:
- Complete CODEC and filtering system including:
- Transmit high-pass and low-pass filtering
- Receive low-pass filter with sin x/x correction
- Active RC noise filters
- µ-law or A-law compatible COder and DECoder
- Internal precision voltage reference
- Serial I/O interface
- Internal auto-zero circuitry
- Receive push-pull power amplifiers
- µ-law-TP3064
- A-law-TP3067
- Designed for D3/D4 and CCITT applications
- ±5V operation
- Low operating power-typically 70 mW
- Power-down standby mode-typically 3 mW
- Automatic power-down
- TTL or CMOS compatible digital interfaces
- Maximizes line interface card circuit density
|
|
Data transmission via radio is always made in a serial manner.
Actual data are normally stored in a parallel form, so that there must be a conversion from parallel data into a serial bit stream. On the receiver side, this serial data stream will be converted back to its original parallel format. The radio channel is not free of noise and disturbances so that techniques for error recognition and error correction must be applied.
|
|
|
The ADV202 is a complete compression/decompression CODEC that is fully compliant to the JPEG2000 standard and is the only device in the market today that is capable of compressing and de-compressing both SD and HDTV video in real-time. Targeted at both still image compression and high-resolution video, the ADV202 performs the computationally intensive operations necessary to perform this new standard in a single chip.
|
|
|
|
|
|
Fujitsu's MB86H51 LSI product can compress and decompress full High-Definition (HD) video (1,920 dots x 1,080 lines) in the H.264 format in real-time. This is the industry's first full HD H.264 High Profile Level 4.0 video processing LSI with memory in one package. This LSI can be used for video processing in products covering a wide range of fields from consumer applications, such as digital video cameras, hard disk digital video recorders (DVRs), & home network appliances, to industrial applications, such as security cameras, and broadcasting equipment.
Proprietary video compression algorithms from Fujitsu Laboratories realize a reduction in the processing burden while producing superior image quality. Meanwhile, Fujitsu's system memory technologies enable a compact system with low power consumption.
Fujitsu plans to continue to be an industry leader of H.264 video processing LSIs in the future with full HD transcoders and full HD multi-decoders that can handle various video formats, and will provide customers with video processing LSIs for high-performance digital equipment.
|
|
|
|
|
|
Highly accurate, analog front end product for scanning equipment with built-in timing generator.
The S1R77 Series is an analog front-end IC converting analog image data output from an inline image sensor such as CCD and CIS to digital data. I provides a selection of products incorporating a variety of peripheral circuits such as a clock generation circuit and differential output circuit, which contributes to space savings and total cost reduction, and results in effective EMI reduction. Using this series allows you to easily build a scanner system providing high-quality images.
The S1R77000 series of ICs includes the analog processing section (correlated double sampling, gain control, and A/D converter circuits) for image sensors such as charge coupled device (CCD) solid-state image sensors in addition to the clock forming circuits that drive them. Use of the new Epson products will enable designers to create systems offering high image quality with the minimum of stress.
The S1R77000 series contributes to space and overall cost savings by including a built-in timing generator for the image sensor. In addition, the S1R77013 includes a spectrum spread function, and the S1R77021 and S1R77081 include built-in RSDS(TM) interfaces that are effective in reducing electromagnetic interference.
|
|
|
Incorporate personal video recording capability into cable and DBS set-top boxes and consumer digital video products using Broadcom's MPEG-2 digital video/audio encoder and multiplexer chips. These advanced chips enable manufacturers to develop entertainment systems that support such features as watch and record, selective viewing, fast forward, fast reverse, skip forward, skip back, slow motion and frame-by-frame viewing.
|
|
Fujitsu offers a comprehensive suite of Digital Video Broadcasting (DVB) solutions for digital television applications.
The product portfolio includes the "SmartMPEG" Digital TV Decoder Family which is ideally suited for Set-Top Box, Personal Video Recorder (PVR), dual/twin receiver Set-Top boxes, Integrated Digital TV sets (IDTV), and other DVB applications.
Digital TV
The SmartMPEG family incorporates devices which provide the most cost-effective system solution for both Free-to-Air applications and for Pay TV. SmartMPEG has also been designed for PVR systems, which support such features as watch and record, fast forward, fast reverse, pause and slow motion.
Fujitsu's MPEG-2 Encoders together with SmartMPEG allow manufacturers to develop entertainment systems for home and in-car applications as well as semi-professional systems.
|
|
The AD725 is a very low cost general purpose RGB to NTSC/ PAL encoder that converts red, green and blue color component signals into their corresponding luminance (baseband amplitude) and chrominance (subcarrier amplitude and phase) signals in accordance with either NTSC or PAL standards. These two outputs are also combined on-chip to provide a composite video output. All three outputs are available separately at voltages of twice the standard signal levels as required for driving 75 ohm, reverse-terminated cables.
|
|
austriamicrosystems offers highly-integrated and flexible analog audio front-end solutions with outstanding performance, which incorporate a low power stereo audio codec functionality and are especially designed for portable audio applications.
AS3510: Audio frontend for mobile music
AS3514: Stereo Audio Codec with System Power Management
AS3515: Analog frontend for mobile application processors
AS3517: Stereo audio codec with advanced system power management
|
|
| ... products without technical information |
| |
RF special products, ideal for gate door openers, burglar alarms, car alarms, personal security, home security, remote controls, access control.
Monostable or latchable outputs. Ideal complement for AUREL data receivers and four channels transmitters with UM3750 encoder. Ideal for applications where more than once coded control is requested.
|
|
|
The MX165C CTCSS Encoder/Decoder is a low voltage, CMOS device that meets TIA/EIA-603 Standards. The MX165C will encode and decode the tones 159.8Hz, 183.5Hz, 189.9Hz, 196.6Hz, 199.5Hz, 206.5Hz, 229.1Hz, and 254.1Hz in addition to the 39 standard CTCSS tones, for a total of 47 CTCSS tones + Notone. With the incorporation of the on-chip TX and RX speech filter, the MX165C enhances voice/tone multiplexing by attenuating TX and RX speech 36dB at frequencies below 250Hz while passing signals > 300Hz with only 1dB of ripple. This not only minimizes CTCSS talk-off in the TX mode but also improves Hum and Noise performance in the RX mode.
|
|
