Microprocessor based Data Logger model DATALOG-16
Product Description:
In a process industries, where "n" number of parameters are required to be monitored and recorded, for various reasons, the data logger featured here is most ideal. Using single data logger it is possible to monitor and log the temperature or process values sensed through thermocouple or RTD(Pt-100) or other process variables, of 2 to 32 different points. One or more data loggers can be combined for monitoring more than 32 channels. The measured analog values are also stored in the internal non-volatile memory along with the real time and date. The stored datas can be down loaded to the dot matrix printer using the built in parallel port and/or on to the computer using the built in serial port on RS485 link. Alarm facility is provided by common high and low relays and 32 dc drivers for high and low alarms per channel. External relay cards can be operated using this driver signals.
Supporting window based data acquisition software allows user to monitor the on-line or off-line datas in the graphical or tabular form on the screen. The high and low alarm levels are also programmable for each channel.
|
|
|
|
|
|
DataRec is fully programmable data recorder that allows to collect production or test data in a simple, fast and reliable way.
The presence of different interfaces allow an easy connection to many kinds of industrial plants, equipments and test instruments.
DataRec may be connected to your existing ethernet LAN to share the collected data as a normal Personal Computer.
Moreover thanks to the integrated web-server you could access your data from the internet or they could be sent directly to your e-mail address at prefixated times.
The two USB interfaces allow the connection with Personal Computer, printers and additional mass storage devices.
Finally, adding the expansion boards is possible to manage optocoupled digital I/O and analog inputs.
DataRec comes together with all the software needed for its configurations and for view and manage the collected data.
The collected data may be exported to the most common spreadsheet formats and it is also possible to connect it to your existent SQL database server through your ethernet network.
|
|
Using the built-in Ethernet interface, the DEWE-201 can be connected to other PCs or Notebooks. Or, several DEWE-201 can be connected together for distributed multi-channel applications. The DEWE-201 can therefore be used as a stand-alone FAST data logger, or as a networked data acquisition instrument
Only 286 x 210 x 88 mm and less than 4 kg - the DEWE-201 is an impressive high-performance DYNAMIC data logger. An internal 4 GB Flash-disk stores acquired data, a 30 GB 'automotive' hard-disk is also available as an option. Like all Dewetron systems, the DEWE-201 is a rugged, all-metal PC instrument with high quality plug-in signal conditioning, an internal A/D card, and great software. Because it's a regular computer running Windows XP, you can load whatever software you like. It has a DVD-CD-RW drive as standard, so you can burn gigabytes of data to inexpensive media in minutes. Or use the standard Ethernet or USB 2.0 interfaces to transfer data to another computer.
|
|
|
|
|
|
The DAQ500 Series are complete 16 or 32-channel multiplexed signal conditioning systems with a 16-bit resolution ADC and 10 BaseT Ethernet connectivity to a PC or laptop for setup, data display and processing. The ultra-compact 57.5mm (2.26") high, 112mm (4.41") wide, 220 mm (8.66") deep fully enclosed chassis weigh just 1.09kg (2.4lbs), making them suitable for in-vehicle applications. The DAQ500 Series chassis can be powered from DC voltage sources ranging from 10-18 volts. Power consumption is 10 watts for typical configurations, 30 watts maximum. Local data storage is available via a CompactFlashT module. Auto configuration on power-up provides stand-alone capability and along with the simple user interface makes data collection and storage a two-mouse click process.
The signal conditioning consists of 16 or 32 multiplexed differential input analog channels that can be configured with fixed 2-pole filters and fixed gains of 1/3 to 100. Filter options are available in a 1,2,5 progression from 10Hz to 1kHz. Filters and gain are configured in 8-channel groups. Input voltage ranges up to ±30 volts are supported. Channel inputs have over-voltage protection to 70 volts peak-to-peak. End-to-end channel calibration is accomplished by configuring the input multiplexers via software to receive a reference voltage provided by an internal calibrator.
Two channels of TTL level digital I/O are provided. These channels can alternately be configured as counter inputs. External sample clock and trigger inputs are provided as well. The internal sample clock can be programmed via software for sample rates from 0.0625Hz to 50kHz.
|
|
16 True Differential or 32 Single-Ended Universal Analogue Inputs for Voltage, Current or Resistance Measurements - Plus 2 High Voltages, 4 Pulse and 8 Digital Event/State Inputs
Analogue Inputs Can Be Used with Thermistors, Thermocouples, 2, 3 or 4-Wire RTD Temperature Sensors and 4 to 20 mA Signals
User Selectable Logging Rates of Up to 100 Hz on Up to 4 Channels
Download of Internal Data to Removable MMC/SD (Multi Media Card/Secure Digital) Memory
Large Non-Volatile Internal Memory - Data Retention is Virtually Indefinite
Ethernet, USB and RS-232 Communication Ports
Sensor Power and FET Alarm Outputs For Use With External Devices
Easy Access to Information Using the 2 Line, 20 Character LCD and Push Button Panel
Calculated Channels Derived from Real Channels Using Advanced Mathematical Functions
|
|
|
|
|
|
The application process datalogger
The HOTBOX-PRO is a universal datalogger for the recording of 4 independent and/or process dependent measured variables. By a large selection of external sensors and in combination with the datalogger family ECOLOG can be found for the most different applications an optimal solution for the recording and documentation process.
All HOTBOX-PRO are completely configured, tested and delivered with conformity certificate. HOTBOX-PRO datalogger need the evaluation software elproLOG version 3.10 or higher.
Specifications:
- 64.000 data points, free programmable
- Display for measured value, date, time, alarm, battery, status information
- 4 Channel with sensors programmed to the internal or external connection
- 2 digital input for external start, alarm delay, alarm RESET, marking
- 1 alarm exit, common alarm, normally open contact
- Work temperature range -35°C to +55°C (datalogger, sensors may be different)
- Dimensions (LxHxD without external sensors) 165x191x59mm
- Weight (dependent on type and sensors) approx.. 1.2 to 1,5 KG
- Voltage supply: 2 lithium batteries 3.6 VDC for independent datalogger, Power supply 12VDC or rechargeable battery for the supply of the connected sensors
- PC port COM 1-6 (RS232-C)
- Accuracy: Temp. +/- 0.3°C, Humidity: +/- 2%, CO2: +/- 0.5%
|
|
Key features
- Measurement of almost all transducer types
- Also suitable for strain gauge measurements
- Up to 1000 channels using a single base unit
- 18 Bit A/D converter
- Resolution up to 1 µV/V (or 0.05 µm/m)
- Built-in carrier-frequency amplifier
- RS232- and IEEE-interface
To measure as efficiently as possible with a large number of channels, it is important to optimize the technical setup as much as possible. The setup of Autolog data-acquisition systems is such that the main components like processor, voltmeter, amplifier and power supply are located in the base unit. More channels can easily be added by using extension boxes with input modules only. This concept also allows easy expansion of an existing configuration.
|
|
MDS-100
The MDS-100 is designed for acquisition, storing, processing and displaying of data acquired from electricity, heat or gas meters equipped with a pulse output or RS485 serial interface. Data from MDS-100 can be transferred via different communication media to a central station for monitoring and billing energy consumption. The data logger is compatible with SCADA.
|
|
|
|
|
|
Multi functionally measuring instrument and data logger with 5 measuring inputs, 2 outputs, RS232, Ethernet, analog
Technical features
- Modern housing with rubberized impact protection and positioning clip; also moisture-proof thanks to new, injectionmolded connectors and sealing lips.
- 5 ALMEMO® input sockets, electrically isolated, for 5 ALMEMO® sensors, 20 sensor chann., 4 additional internal function chann.
- 2 ALMEMO® output sockets for digital interfaces, analog output, trigger input, alarm contacts, memory card.
- High-speed, high-resolution A/D converter, 24-bit, 50 meas. op. per sec. New measuring ranges Pt100, 0.000 to 65.000 °C.
- Ideal display with large, brightly illuminated graphics.
- Easy and convenient operation by means of 4 soft-keys and cursor block, Comprehensive menu system with wizards and help windows.
- 9 measuring menus (3 can be freely configured by user from range of 50 functions).
- Measured values can be displayed graphically in line diagram or bar chart form and from 1 to 20 measured values can be displayed numerically in various sizes.
- Measuring functions : Measured value, zero-setting, setpoint adjustment, maximum and minimum values stored with date and time-of-day, smoothing, average values over time or measuring points, limit value monitoring, cold junction compensation, temperature compensation, and atmospheric pressure compensation
|
|
myDatalog Mobile
Application
Portable measurement instrument to acquire and record analogue and digital signals from a standardised interface, to be used in:
-Sewer systems
-Industries
-Public water and sewage systems
Measurement Examples:
Level, temperature air/water/surface, flow, rainfall, weather station, relative humidity, pH, conductivity, CSB, pressure
|
|
Description:
The model D101 is battery operated data logging unit that records data or measurements from other instruments. It is used along with Anaheim Scientific "H Series" products when a data logging application requires the recording of a meters measurements. The D101 comes with Software, a RSCBL2 PC Interface Cable and one 2EPCBL Cable to interface the D101 to an "H Series" instrument.
Features:
* Stores 8,000 measurement values
* Settable sampling time 1 second to 9 hours
* Auto or manual logging
* Saves data with time stamp information
* Large LCD display
* Two year warranty
Applications:
* Connect to "H Series" Anaheim Scientific products
* Record measured values over extended periods of time
* Export recoded data to Spreadsheet programs for reporting data
|
|
Recording pressure at compressors
For optimization, high pressure, low pressure and 2 temperatures are recorded simultaneously.
Material:
1x HOTBOX SE universal datalogger 2501
1x Pressure sensor -1..9 bar 3280-A
1x Pressure sensor -1..24 bar 3280-B
2x NTC temperature sensor -50°..+140°C 3055-L03
1x Connector for 2 NTC sensors 2540-P4
1x Connector for 2 pressure transmitter 2540-P5
2x Sensor mounting and test 2540-B
|
|
The data logger serves for the supervision and event storage in four channels with the following features:
* one DMS-bridge input
* two Pt-100-inputs
* one frequency input for NPN- or PNP-signals
* battery buffered alarm loft for at most 50.000 stored events
* battery buffered real time watch
* serial interface for PC communication
* event supervision in second time
|
|
Micro Technic offers a range of combined RTUs and data loggers, dedicated at bringing your remote process data available anywhere and anytime!
Bring your product online with our range of GPRS data loggers!
|
|
MDS-5 Com
The online data logger with integrated GSM / GPRS modem. Up to 12 channels with SMS alarms.
|
|
