TIGMATE™
The TIGMATE™ is a complete AC/DC, TIG and Stick welding package. All you need is a bottle of argon shielding gas or your choice of Stick electrodes and you're ready to start welding.
In the TIG mode, the TIGMATE™ offers superior performance: 18 gauge to 3/16 in. (1.2 to 4.8 mm) steel and stainless steel; 14 gauge to 3/16 in. (1.8 to 4.8 mm) aluminum. For thicker metals, take advantage of the Stick mode using 3/32 and 1/8 in. (2.4 and 3.2 mm) electrodes.
- Upgraded circuitry gives you finer TIG output adjustment with the remote foot or fingertip control. If you need more output while using the remote control, simply increase the setting of the front panel amperage control.
- AC output for superior aluminum welding, DC output for mild and stainless steel
- Four-position polarity and range selector switch offers two AC current ranges, DC electrode (-) for TIG, and DC electrode (+) for Stick
- Special arc starting circuitry eliminates high-frequency starts
- Built-in arc assist stabilizer for AC TIG on aluminum
- Built-in arc assist starter for DC TIG
- Process switch automatically sets machine for TIG or Stick
- Unique "flow-through" shielding gas TIG torch connection allows removal of torch without tools
- Preset automatic postflow timer protects tungsten tip, workpiece and torch
- Automatic high temperature shutdown
|
|
Based on the very latest IGBT inverter technology, TIG power sources with high frequency arc striking of the MATRIX series are equipped with an innovative digital panel for the complete control of all the welding parameters.
The excellent technical characteristics of these welding machines, coupled with the feature of digital control, allow high quality TIG welding, suitable for the toughest industrial applications and maintenance.
These highly advanced technology power sources are robust and user friendly: MATRIX HF’s, DC output only, enable TIG welding of mild and stainless steel, copper and its alloy.
MATRIX series power sources also offer excellent performance also in MMA welding with the most difficult basic and cellulosic electrodes.
|
|
|
|
|
|
The YC-300BZ3 DC inverter TIG welding power source has been developed on Panasonic digital technology. It is 100% digital controlled and offers high quality welding.
Technical Data:
100% full digital control high performance welding
• Exact output parameters
• Sharp and stable arc start as low as 4 amp.
• Welding Method:
1. DC TIG, DC pulse TIG for mild and stainless steel as well as titanium 0.3 – 6 mm, copper and brass 0.5 – 3 mm
2. DC TIG arc spot for mild and stainless steel with 2 x 2 mm thickness
3. DC stick for diameter 2 – 6 mm
• Duty cycle: 300A / 40%
• Weight: 36 kg
• Digital interface with Panasonic robots
• Arc drive function for stick welding
• Dimensions: 510 x 380 x 410 mm (L x W x H)
• 400 V AC, 3 phases, 50 / 60 Hz
Digital display, LCD, jog dial
• Digital display for both programmed parameter and actual welding parameter
• Easy and logical parameter setting by LCD and jog dial
Quality control
• 99 memory programs
• Digital connection with the PC / network for production
management and quality control
Customer Benefits:
• Sharp and stable arc start
• Reliable quality for low maintenance and service cost
• Easy parameter setting by jog dial
|
|
|
|
|
|
TETRIX 350 AC/DC activArc
TIG inverter AC/DC welding machine, modulare
HIGHLIGHTS
Maximum efficiency for all requirements with reproducible welding results and excellent quality thanks to the fully digital inverter welding technology
Synchronous operation of 2 machines for two-sided, simultaneous welding, AC special for the easy joining of very different thickness aluminium panels
Maximum flexibility thanks to the modular and futureoriented machine system: Upgrade to fit the need – no additional tools or specialist staff required.
EWM activArc – the powerful TIG arc
Self-explanatory, intuitive operating concepts for everyone - either the standard setting, job mode or synergic one-dial operation
Maximum mobility: fits through standard doors, easy loading and unloading thanks to the even wheel gauge
Intelligent casing design with optimised air guidance for longer duty cycle and ventilation control for less contamination in the machine.
COMFORT, SYNERGIC: Ideal for robot, industrial bus and mechanised applications and documentation via optional interface
MAIN AREA OF USE
TIG AC welding: Aluminium and aluminium alloys
TIG DC welding (minus pole): Unalloyed, low-alloy and high-alloy steels, nickel-based alloys, copper and special metals
MMA welding (direct current) with rutile and basic coated electrodes: Unalloyed and low- and highalloy steels, nickel-based and copper alloys
FEATURES
TIG and MMA inverter AC/DC welding machine
Mobile, water cooled, decentralised, modular, 5 m mains supply lead
Powerful cooling module with centrifugal pump, pressure monitor, pump and temperature-controlled fan
100% tested and free welded
|
|
|
|
|
|
TETRIX 521 AC/DC activArc
TIG inverter AC/DC welding machine
HIGHLIGHTS
Maximum efficiency for all requirements with reproducible welding results and excellent quality thanks to the fully digital inverter welding technology
Unique AC functionality: Synchronous operation of 2 machines for two-sided, simultaneous welding, AC special for the easy joining of very different thickness aluminium panels, e.g. 1 mm to 10 mm
EWM activArc – the powerful TIG arc
Self-explanatory, intuitive operating concepts for everyone - either the standard setting, job mode or synergic one-dial operation
Maximum mobility: fits through standard doors, easy loading and unloading thanks to the even wheel gauge
Intelligent casing design with optimised air guidance for longer duty cycle and ventilation control for less contamination in the machine.
Powerful cooling system for the torch, with centrifugal pump, cooler with large surface area and an extra-large tank
COMFORT, SYNERGIC: Ideal for robot, industrial bus and mechanised applications and documentation via optional interfaces
MAIN AREA OF USE
TIG AC welding: Aluminium and aluminium alloys
TIG DC welding (minus pole): Unalloyed, low-alloy and high-alloy steels, nickel-based alloys, copper and special metals
MMA welding (direct current) with rutile and basic coated electrodes: Unalloyed and low- and highalloy steels, nickel-based and copper alloys
FEATURES
Mobile, water cooled, decentralised, can be lifted by crane and moved by -fork lift, 5m mains supply lead
pressure monitor, pump and temperature-controlled fan
100% tested and free welded
|
|
|
|
|
|
PICOTIG 230 AC/DC PowerSinus
TIG and MMA inverter AC/DC welding machine
HIGHLIGHTS
Professional TIG AC and DC welding with excellent ignition and welding characteristics
Simplest possible operation – ideal for assembly work
Overvoltage protection – accidental connection to 400 V mains voltage does not result in damage to the machine
Also ideal for construction site use thanks to the exceptionally large mains voltage range for problem-free use on long mains leads and on a generator
MAIN AREAS OF USE
TIG AC welding: Aluminium and aluminium alloys
TIG DC welding (minus pole): unalloyed, low-alloy and high-alloy steels, nickel-based alloys, copper and special metals
MMA welding (direct current) with rutile and basic coated electrodes: unalloyed, low-alloy and high-alloy steels, nickel-based and copper alloys
Production and repair work, metal construction, facade, conservatory and window construction, roof-fitting, heating and ventilation construction, food and chemical industries, pipeline, closed container and equipment construction, vehicle, machine, plant and tool construction, and more
FEATURES
Portable, gas cooled
Robust plastic casing, with practical carrying strap as standard
AC and DC TIG welding with HF ignition and liftarc
Non-latched, latched, tapping mode
Manual welding: hotstart, arcforcing, antistick
One-dial operation – one large rotary dial for setting all values
Reproducible setting of all welding parameters on the digital display
|
|
|
Unitek Peco's Dual Pulse Series is a full range of Capacitive Discharge (CD) power supplies for precision resistance welding applications. Their unique "Dual Pulse" function overcomes process variables; part and electrode surface inconsistencies contribute to poor welds. Plating irregularities or contaminants, including oxides and oils, affect weld reliability. The “Dual Pulse” function virtually eliminates these problematic variables.
|
|
|
|
|
|
Advanced Capacitive Discharge Welders (patent pending)
Features:
- Dual pulse function
- Built-in peak current monitor
- Process monitor
- Set test pulse and pulse limits
- Upslope function
- Polarity Programming by pulse
- Four selectable pulse widths
- High resolution 6.5" color display
The new range of Advanced Dual Pulse CD welders were developed to provide a new level of welding performance, process monitoring and user interface.
The 100ADP replaces the 125DP, the 300ADP replaces the 250DP and 250DPS, and the 1000ADP replaces the 500DP, 500HV and 875DP units.
The all new design that includes a proprietary charging unit improves pulse rise times and repetition rates. The monitoring capability with color coordinated display provide at a glance information of weld and process performance.
Unique features such as programmable pulse polarity and uplsope provide easy setup for even nugget formation and electrode wear in series welding, and a means to alleviate weld splash.
The ADP welders are particularly suited for applications such as battery welding.
|
|
| ... products without technical information |
| |
|
|
|
|
The Arc Machines Model 415 is designed to be a versatile welding automation control and power supply system. The standard Model 415 can be used to weld all alloys that are weldable with the Gas Tungsten Arc Welding process (GTAW, or TIG) using straight polarity DC current. The basic Model 415 features a complete complement of controls, water cooling and gas control necessary to operate all AMI orbital weld heads for in-place field welding tasks ranging from small diameter fusion tube welds to heavy-duty piping and vessels. All welding tasks are performed with the unparalleled level of precision and repeatability that have become a world-wide AMI trademark.
The Arc Machines Model 415 Windows™ based power supply/controller features the absolute latest state-of-the-art technology, from its 400 ampere second-generation solid-state Thompson buck-converter power supply to its color VGA display with touch screen.
The Model 415 is an extremely capable power supply that is very easy to operate. The heart of its flexibility is our emphasis on user-definability. Almost all function ranges and modes can be defined by the user to exactly match the welding head or fixture being used. These features include the ability to add up to 4 optional closed-loop motor servos and 8 optional open-loop motor manipulator controls that make it ideal for work-cell manufacturing environments or for use with custom welding heads having unique functions.
Remote operation of the Model 415 requires a minimum of additional options. Most remote welding modes and controls such as lighting and video controls are included as standard equipment.
|
|
| ... products without technical information |
| |
|
|
|
|
The Arc Machines Model 415 is designed to be a versatile welding automation control and power supply system. The standard Model 415 can be used to weld all alloys that are weldable with the Gas Tungsten Arc Welding process (GTAW, or TIG) using straight polarity DC current. The basic Model 415 features a complete complement of controls, water cooling and gas control necessary to operate all AMI orbital weld heads for in-place field welding tasks ranging from small diameter fusion tube welds to heavy-duty piping and vessels. All welding tasks are performed with the unparalleled level of precision and repeatability that have become a world-wide AMI trademark.
The Arc Machines Model 415 Windows™ based power supply/controller features the absolute latest state-of-the-art technology, from its 400 ampere second-generation solid-state Thompson buck-converter power supply to its color VGA display with touch screen.
The Model 415 is an extremely capable power supply that is very easy to operate. The heart of its flexibility is our emphasis on user-definability. Almost all function ranges and modes can be defined by the user to exactly match the welding head or fixture being used. These features include the ability to add up to 4 optional closed-loop motor servos and 8 optional open-loop motor manipulator controls that make it ideal for work-cell manufacturing environments or for use with custom welding heads having unique functions.
Remote operation of the Model 415 requires a minimum of additional options. Most remote welding modes and controls such as lighting and video controls are included as standard equipment.
|
|
|
|
