NetTEST II is an essential must-have analysis and test tool for the
successful operation, maintenance and service of any PROFIBUS network.
Already the basic system for detecting installation errors sets a new standard in the field of analysis and test tools.
With the DP Master functionality NetTEST II becomes an outstanding tool for the mobile commissioning of DP Slaves. The entire PROFIBUS
network can be lined up without using a PLC.
Equipped with the online functionality NetTEST II also detects sporadic errors in running systems. So NetTEST II becomes the absolute all-rounder among PROFIBUS analysis and test tools.
The automatic generation and filing of detailed test records fulfils all
requirements of state-of-the-art quality management systems.
|
|
|
|
|
|
Diagnosis Tool for PROFIBUS (DP and PA) and Foundation Fieldbus FF H1
The Busmonitor is an indispensable tool for commissioning, maintenance and diagnostics of PROFIBUS and Foundation Fieldbus networks, as well as for the development of PROFIBUS and Foundation Fieldbus products.
Because of the PCMCIA interface it can be installed on a portable PC. This makes it perfectly suited for the requirements of every day use. The ease of use is guaranteed by simple handling of the tool without need of time consuming training.
In online operation the PROFIBUS DP Busmonitor records the message interchange up to a baud rate of 12 Mbit/s (DP) with single bit accuracy. The passive RS485 interface, which is integrated in the plug, guarantees a reactionless measurement during the operation of the bus. In Foundation Fieldbus FF H1 operation with the active IEC1158-2 probe head all telegrams are recorded as well.
In offline mode the recorded messages are displayed. They can be decoded on different protocol levels (physical level, FDL, DP-DPV1 or combined). The recording contains a precise time stamp providing a precise measurement of the bus timing even with 12 Mbit/s (DP).
A various number of filters can be defined for recording as well as for displaying messages. These filters can also be used to search for certain messages. The start of a recording session can be defined by trigger conditions, i.e. a certain telegram or the n-multiple appearance of a telegram.
With the remote control functionality the Busmonitor can be remote-controlled by any other computer via the DCOM interface.
|
|
|
|
|
|
The PB-T3 is the most widely used bus testing tool worldwide for PROFIBUS DP physical segment and signal testing. It is indispensable for installation, commissioning, preventive maintenance and troubleshooting. Functions:
• Non-reactive measurement of physical characteristics during operation
• Intuitive user interface in English, German, French, Italian and Chinese
• Automatic detection of the baud rate of all bus stations
• Fieldbus topology scan
• Display of quality levels to indicate the signal quality of each station
• Reliable detection of even very short-lived faults
• Storage oscilloscope with trigger output
• Long-term measurement
• Master simulator for measurements even without a PLC
• Detailed test report and handover certificate
The bus check product line from Softing features a range of efficient diagnostic tools for different fieldbus systems. Besides the PB-T3 PROFIBUS Tester, the PROFIBUS portfolio comprises the BC-400-PB and BC-450-PB Protocol Analyzers for PROFIBUS DP+PA, and the BC-230-PB Diagnostic Monitor for PROFIBUS PA.
|
|
|
|
|
|
BC-450-PB Protocol Analyzer
for PROFIBUS DP+PA
This powerful diagnostic tool analyzes PROFIBUS communication during operation. Intended for both service technicians and fieldbus experts, it provides support in commissioning, optimization, preventive maintenance and troubleshooting. PROFIBUS DP and PA networks can be connected simultaneously; the network type is detected automatically. The Diagnose mode continuously analyzes the state of each station on the bus and shows the results in a clear, easy-to-read display. Functions:
• Live list indicating station states using “traffic light symbols”
• Event counters for retransmissions, restarts and diagnoses
• Cyclic and acyclic input and output data
• Parameterization and configuration data
• Complete plain text decoding of all diagnostic information
• Unique support of the Simatic Diagnostic Repeater and the DP/PA Link
• History for diagnostics and events
• Detailed test report and handover certificate
The Trace mode logs and displays the frames according to user-defined trigger and filter settings, such as PROFIBUS services, addresses and data. Even a slow deterioration in the physical state of a fieldbus can be detected indirectly on the basis of error frames, retransmissions and device restarts.
The bus check product line from Softing features a range of efficient diagnostic tools for different fieldbus systems. Besides the BC-450-PB Protocol Analyzer for PROFIBUS DP+PA, the PROFIBUS portfolio also comprises the purely DP-oriented BC-400-PB Protocol Analyzer as well as the PB-T3 Signal Tester for PROFIBUS DP and the BC-230-PB Diagnostic Monitor for PROFIBUS PA.
|
|
Advanced diagnostics
The Advanced Diagnostics Module for the Power Hub monitors the physical layer and communication online and in real time. A comprehensive set of measurements brings transparency to field device communication. It helps you speed up your processes because you know where to look:
Speed up commissioning: Check device polarity, noise, jitter, duplicate addressing. The Commissioning Wizard automatically configures alarm values, historian and other values to inform you about changes that may harm your process plant communication.
Optimize your plant during start-up: Fine-tune fieldbus communication
Increase plant up-time: Detect and resolve issues before they become problems
Enhance troubleshooting techniques: Look at details via the built-in oscilloscope
All data is readily available in the control room via easy to use DTMs. Fieldbus just got much easier. Advanced Diagnostics is the perfect tool for the expert and the novice user.
|
|
