The range of MVE-type External Electric Vibrators is the result of more than forty years of experience in vibrating technology for the building industry as well as for other industrial applications worldwide. OLI® Rotary Vibrators afford a guarantee of long term durability, reflecting the care taken over selection of components (well sized SKF bearings) and the high level of precision adopted in manufacture, whilst maintenance is minimal and simple in the extreme.
MVE-type External Electric Vibrators are used in a number of different applications: as material flow aids, for screening, conveying, cleaning, detaching, compacting, and sorting.
- Motor protection: IP 66 - NEMA 4
- Insulation class: F
- Adjustable frequency
- Continuous duty: S1
- Centrifugal force: from 4 to 13000 kg (from 8.8 to 28660 lb)
- Standard voltage: 230/460 V, 60 Hz
- 900 - 1200 -1800 - 3600 R.P.M.
- Standard: ATEX II3D certified
- Standard: ETL (UL-CSA) Class II Div 2
- On demand: ATEX Exe II 2 GD
- On demand: ATEX Exd II 2 GD
- Excellent price-performance ratio
- Ex-stock delivery
|
|
Eriez Bin Vibrators are used in applications ranging from the tiniest hopper to huge bunkers. Depending on your location, two different styles may be available.
Bin Vibrators - Electro-permanent
AC-operated units provide efficient, economical movement of hard-to-handle bulk materials. They use up to 80% less power than some other units.
Bin Vibrators - Inertial
Want the best of both electromagnetic, as well as rotary drive bin vibrators? Take a look at Eriez' new line of Inertial Bin Vibrators, that give you the advantages of each.
Bin Vibrators - Pneumatic
Oscillating piston-type vibrators are ideal for small hoppers, tables and transfer chures
|
|
|
SPV Series Vibrators are engineered for quality and long service life. All models feature low operating temperatures thanks to radial fins and oversized electrical components. There are single phase and three phase models, with forces to over 57,000 pounds. Visit our website for further data, or contact our sales team for assistance in sizing an SPV Series Vibrator for your application.
|
|
|
|
|
|
MARTIN® Electric Vibrators CD Series
MARTIN® Electric Vibrators improve the handling of bulk materials in industrial vibration applications like bin activation, screening, feeding, and compaction.
Engineered for Continuous Duty
MARTIN® Vibrators are specially built to withstand the rigors of industrial vibration.
Efficient Operation
Higher force-to-energy consumed ratio than hydraulic or pneumatic vibrators means lower operating cost.
Versatile
Available in 900, 1200, 1800, and 3600 rpm. Ranging from 13 to 49,000 pounds of force. Various electrical ratings are available.
Quiet Operation
A typical MARTIN® Electric Vibrator generates 65 to 70 dB. Comparable air-powered vibrators produce 85 to 90 dB.
Precise Control of Force
Adjustable eccentric weights provide precise control of output.
Low Maintenance
Bearing lubrication (on a 1000- or 2000-hour schedule) is the only required maintenance. (Some models use sealed bearings, eliminating all lubrication.)
Dust-Tight, Water-Tight
O-ring seals and machined surfaces protect against the entry of dirt and water.
Vibrators to Meet Special Requirements
UL and CSA-accepted models are available for hazardous duty locations or for non-standard electric hook-ups. Controls and mounting accessories are also available.
|
|
Series EBB
400 V 50 THREE-PHASE Hz
FIXING HAS SIDE OR CENTRAL SUPPORT
The vibrators, series EBB, are used for the vibrating screens, the blutoirs and the machines of vibrating completion (fettling):
Tropicalized engine
Classify insulation F
Mechanical protection: IP65-7
Support bearing with double oil hole
|
|
|
The MVB series is made up of vertical vibrators with lateral flange and shaft projecting on both sides. The MVB-FLC series is made up of vertical vibrators with central flange and shaft projecting on both sides. These vibrators are typically used in circular screens and medium-size and large sieves, and can be supplied in 4 different versions: A, B, C, D (see page 82) according to the type of eccentric weights supplied with the vibrator and which must be mounted by the user. Size 50 is only available in B, C and D versions. The size 50 complies with the most recent IEC and EN international standards for use in atmospheres with potentially explosive powders. In particular, the size 50 series can be used in areas 21 and 22.
|
|
|
|
|
|
MARTIN® Flanged Electric Vibrators
MARTIN® Flanged Electric Vibrators with mounting flanges and double-ended shafts are designed and manufactured for use with vibrating machines such as circular screens or sifters
Designed for Easy Positioning
MARTIN® Flanged Electric Vibrators are engineered for simple installation.
Extensive Adjustable Ouput Range
Industrial vibration output is adjustable from 0 to 7000 Kg. (68.7 kN).
Unmatched 3-Year Warranty
Backed by Martin Engineering's industry-leading guarantee.
Using the power of applied vibration, MARTIN® Engineered Vibration Technologies energize material, reducing friction against container walls as well as internal particle-to-particle cohesion. The material moves more freely, feeds more effective, sorts more consistently, compacts more efficiently, and handles more easily.
Martin Engineering makes bulk materials handling cleaner, safer and more productive, with engineered systems including conveyor belt cleaners, conveyor load zone/transfer point chutes, impact cradles and slider beds, skirtboard sealing systems, air-supported belt conveyors, air cannons, pneumatic (air) and electric industrial/bin/railcar/truck vibrators, belt training/alignment devices, dust suppression/collection/control systems, and specialized contract services including installation/maintenance and silo/bin/bunker cleaning.
|
|
Unidirectional balanced linear vibrators
Features:
Power supply: 230 V - 50 Hz
on demand different voltages / frequencies
(110 V - 50/60 Hz)
|
|
VIBRAFRANCE vibrators are manufactured in solid cast iron housing and high resistant aluminium for continuous working with on standard :
• Tropicalized motors
• Mechanical protection : IP65-7
• Winding insulation in accordance with ASTM, with polyester resin class H
• NiCrMo head-treated steel shafts
• High load capacity bearings with special "LONG-LIFE" KLUBER STABURAGS NBU 8 EP lubrication
• Conforms to CE directives
|
|
|
|
|
|
Syntron® Bin Vibrators offer an efficient, cost-effective means to maintain free flow of product from bins, hoppers and chutes, with a direct and positive result on the bottom line. Whether the need is to ensure constant, uninterrupted material flow, or to eliminate the necessity for manual manipulation of a bin, hopper or bulk material, Syntron Bin Vibrators increase productivity and reduce production costs.
Three types of Syntron Bin Vibrators - electromagnetic, rotary electric and pneumatic - provide, product flow solutions for just about any industry, application or environment. Compact yet mighty, Syntron Bin Vibrators are designed for years of high-performance, trouble-free continuous or intermittent operation, with the broadest selection of models and power ranges available.
- Syntron Electromagnetic Bin Vibrators are ideal for continuous or intermittent operation. An easily adjustable control assures optimum and variable material flow. Dependable Syntron Electromagnetic Bin Vibrators are virtually maintenance-free because the electromagnetic design eliminates moving parts. Most models come standard with fully-enclosed dust-tight and watertight construction.
- Syntron Electric Rotary Bin Vibrators are motor driven for reduced noise levels. These rugged bin vibrators are totally enclosed for reliable operation in dusty, dirty or moist environments. Adjustable eccentric weights allow easy adjustment of force to suit varying applications.
|
|
The MVSI series represents the line of reference products for manufacturer's of vibrating machines and plants operating in many industrial sectors and is made up of the largest range on the market, with centrifugal force values up to 26000 Kgf (254kN).
It is characterised by state-of-the-art technological evolution in the perspective of continual performance improvements. The MVSI-S02 series, now inserted for sizes 00-01-10-20-30-60-70-80-90 and 97, in the implementation phase on the entire range, represents another step forward in the sturdiness and reliability of the product. The MVSI series has been conceived to guarantee higher performance in all conditions and environments and complies with the most recent IEC and EN international standards for use in atmospheres with potentially explosive powders. In particular, the MVSI series can be used in areas 21 and 22.
|
|
The MVCC series of vibrators with direct current has been designed for use in those situations where network electricity is not present. In particular for hoppers, silos and gate-controls and roll-on roll-off vehicles (concrete mixers, pumps for concrete, plasterers, salt distributors, gravel spreader, fertiliser spreader, hauled silos, industrial sweeper filters). The newly-conceived electric motor, with permanent magnet poles, and the increase in size of the electrical parts, allow constant, high yielding performance.
The MF models have a multi-hole fi xing base to adapt to diff erent centre distances of drilling.
|
|
|
|
|
|
More than forty years of experience in the vibration of concrete products put the technical staff of SOMAI into the position to develop a wide range of electric motor vibrators, which satisfy the most extreme requirements of the producers of from works and prefabricated parts.
In addition to the vibrators operating with the traditional converters at 150-200 Hz, which can reach 4500 - 6000 - 9000 revolution per minute, have been realized special vibrators for operation with the modem electronical frequency regulators. These multitension and multifrequency vibrators operate which a centrifugal force ranging from 3000 to 9000 RPM.
The vibrators of the series VEP/VEM building are suitable for the continuous use 5/ and for 20 minutes of discontinuous use S2 under the heaviest conditions and in particularly humid or dusty environment.
They have all been projected. Constructed and thoroughly tested in the SOMAI works at Cisliano and are the fruit of long experience in the development of technologically leading machines and modern tools.
|
|
|
Electric rotary vibrators for heavy duty industrial applications, such as vibrating screens, dewatering screens, feeders, grizzly feeders, spiral elevators, vibrating fluid beds, conveyors, foundry shake-outs, pre-fab moulds
|
|
Italvibras produces 2 series of electric vibrators with frequency variation which can be applied to systems and machines in the precasting industry: ITV-VR Series, with variable frequency; ITVAF Series, with fi xed frequency. The ITV-VR series electric vibrators are able to provide a centrifugal force of up to 5300 Kgf (52 kN) at a frequency varying from 0 to 6.000 rpm. The ITVAF series electric vibrators with fi xed vibration (6000 or 9000 rpm) provide a vibrating energy of up to 1480 Kgf (14,6 kN).
Both are available with either the fixed or cradle connection.
|
|
|
Electric rotary vibrators at high frequency and variable frequency for cement vibration, vibrating tables and prefabrication moulds.
|
|
|
Unbalanced motors are suitable as drives for vibration conduits and pipes, vibrating and bar grate filters, vibration funnels and vibrating tables, worm conveyors or water removal equipment. As vibrators for silos, bunkers, deflection grills, downspouts, chutes, filter, filling plants, they guarantee a smooth material flow. Whether in gravel drainage, screening, dedusting or filters, with the conveying of large volume quantities or in case of special tasks involved in process engineering, such as e.g. concrete compaction, dosing and material loosening, AViTEQ unbalanced motors perform their work reliably in every case. Take advantage of our more than 50 years of experience in vibration conveying technologies in all sectors.
|
|
Features:
- Output voltage regulation
- Range adjustement proportional to set value
- Smooth activation, two preset times
- Adjustment of the minimum and maximum output voltage via separate potentiometers possible
- Different versions for the adaptation to your individual requirements
- Level scanning system and part overflow controller
- Feeder drive and sensors: plug-in types
|
|
|
Frequency converters from 14 to 200 has - 42 V - 200 Hz for electric vibrating needles 42 V - 200 Hz
|
|
