Safety enclosures for explosive environments are meant to
be used in areas with explosion risk 1, 2, 21 and 22 gaz « G »
and dust « D » according to 94/9/CE directive.
They ensure emergency stop, load break for electrical
maintenance and switch disconnection next to all low voltage
network.
|
|
|
|
|
|
Our product range contains a wide variety of enclosures which offer a selection of sizes, designs and materials. It is designed for single installations as well as for large distribution units. The dimensions of the enclosures are so designed that they can be combined into a large modular unit. A large number of components, such as contactors, switches, instruments and PLCs can be built into these enclosures. Naturally, customer-supplied equipment layout is designed by us to customer's requirements. Cable entry is either direct (cable glands or conduit entries) or indirect via en EEx e housing (stud-type or conductor bushings).
The design and installation of explosion-protected distribution and control boards having flameproof enclosures require considerable experience and careful consideration of relevant regulations in relation to the application data. Only thus are technically and economically satisfactory solutions, which combine a user-friendly design with a high degree of safety, possible. In addition to Ex-regulations, the general regulations must all be bserved in the assembly of distribution and control boards.
Standard industrial electrical equipment can be bult into enclosures. It is, however, subject to a "type test" by a recognised testing station. R. STAHL has such certificates issued by PTB permitting the assembly of explosion-protected systems for all standard applications.
|
|
Under ATEX, the requirements placed on EX enclosures for use
in explosion hazard atmospheres are high.
For this reason, Rittal refuses to compromise in this area. Enclosure concepts proven a million times over are tailored to the specific Ex requirements.
The results is a series of empty enclosures providing ideal conditions for applications in the chemicals
and petrochemicals industries, in the offshore sector
and in the foods industry.
|
|
|
Explosion-proof boxes, control stations and panels EEx d IIB and IIC, aluminium alloy, steel or stainless steel (316L), with front window, box extension. Boxes assembling.
|
|
We were dissatisfied with what was available for mounting single and multiple rail-mount instruments in the field, so we designed our own. Made of metal with a rugged clear polycarbonate cover, the R-BOX meets standards for enclosing indoor and outdoor electronics approved for use in instrinsically safe and non-incendive areas. It installs quickly and easily on a surface or pipe, or in a panel.
Use the R-BOX with our SPA and SPT Site-Programmable Alarms and Transmitters, TRY and SIY PC-Programmable Transmitters, and our complete line of economical ECT Signal Isolators, Converters, Repeaters, and Splitters.
|
|
Technical Data:
Version: II B
Explosion protection: Ex II 2 G
Ex II 2 D
Ex d, Ex d[ia] II B
Certificates: empty enclosure: INERIS - 00 ATEX 0021 X
Material: copper free aluminium
Surface treatment : unpainted, painted on request
Ingress protection : IP 65/67 in accordance with EN 60529 on request
Temperature range:
-50°C to +55°C / Ex-d IIB T6/T5/T4
-50°C to +40°C / Ex-d (ia) IIB T6
-50°C to +40°C / Ex-d (ib) IIB T6
-50°C to +55°C / Ex-d IIB+H2 T6/T5/T4
-50°C to +40°C / Ex-d (ia) IIB+H2 T6
-50°C to +40°C / Ex-d (ib) IIB+H2 T6
|
|
ATEX
EX enclosures are specially made for use in hazardous environments. They are designed, manufactured and tested to international standards. All certificates, such as ATEX, are issued by the manufacturer under license from a test authority. EX enclosures are made of either aluminium, polycarbonate or polyester.
- Aluminium from 45*50*32 to 600*310*180 mm
- Polycarbonate from 188*188*130 to 558*378*180 mm
- Polyester from 75*80*55 to 405*400*120 mm
AL: (ALX) IP 66; IK 08; NEMA Typ 1, 4, 4X, 6, 12 and 13
PC: (FEX) IP 66; IK 08; NEMA Typ 1, 4, 4X, 6, 12 and 13; UL 94-5V; UL 508
PE: (PEX) IP 66/67; IK 08; NEMA Typ 1, 4, 4X, 6, 12 and 13; UL 94-5V; UL 508
|
|
|
|
|
|
Spacial 3D.ATEX enclosure
The new "ATEX European Directive", relating to equipment used in explosive, gas or dust-laden atmospheres imposes significant improvements in safety of persons and equipment in chemicals,
refining, flour-milling, grain storage, etc. From 1st July 2003, only those products that meet the requirements of this directive can be marketed and installed.
* The Spacial 3D.ATEX enclosure range is ATEX approved by the LCIE under
reference number 02 ATEX 0037 U.
* Enclosures carry double marking:
- new approach: 00 81 Ex II 2 G/D,
- additional marking according to
EN 50014 and EN 50019 stadards: EEx e II.
technical characteristics
* Sheet steel enclosure.
* Degree of protection: IP66.
* Ambient temperature maximum permissible range -25°C to +40°C.
* External mechanical impact resistance: IK 10.
* Textured epoxy polyester powder paint finish, colour grey RAL 7032.
* Enclosures are fitted with 4 shouldered M8x25 backstuds for chassis attachment..
* Polyurethane seal.
* Compared to the Spacial 3D universal enclosure, the Spacial 3D.ATEX enclosure offers:
- 4 fixing holes fitted with 4 crimped blind nuts,
- crimped blind nut for external earth connection (earthing braid not supplied).
|
|
|
Pepperl+Fuchs products are used throughout the world in applications involving industrial, hazardous and corrosive environments. By engineering a complete solution at our own facility, Pepperl+Fuchs is able to offer its world-class products in a variety of panels and enclosures designed and built according to your specifications.
|
|
Junction boxes are used for carrying and distributing electrical power in hazardous areas. They are supplied in different sizes with and without small equipment fuse, and are therefore suitable not only as pure connection and distribution boxes, but also for protecting electrical loads up to 6,3 A. Cable glands in plastic are used as standard cable entries. Bell-mouthed or metal glands can be fitted if ordered. The metal cable entries are connected to the earthing system via brass plates.
Explosion protection to CENELEC, IEC
For use in Zone 1 and Zone 2, Zone 21 and Zone 22
Enclosure in glass fibre reinforced polyester resin
Degree of protection IP 66
|
|
4B INLINE JUNCTION BOX
- For use in Atex zone 20& 21
- Tough moulded nylon body
- Accepts 5 x 2,5mm2 cable cores
- Threaded to take standard M25 glands
|
|
Junction boxes, cabinets and control stations for increased and intrinsic safety EEx e / ed / ia /eia / deia.
Aluminium, polyester and stainless steel (316L). Boxes assembling.
|
|
|
|
|
|
The recently developed CUBEx control enclosure product line from R. STAHL now makes it possible to combine compex control and distribution panels into comprehensive, space-saving units. Adds a whole new dimension to individualised and flexible solutions for your applications. Other customer-specified control and distribution panel designs are also possible. The CUBEx system increases the flexibility of your applications and ensures that all internationally recognised installation technologies can be employed. All standard, commercially-available electrical equipment can be installed. The space-saving design of this IIB enclosure enables a mounting distance of just 10 mm between units. Moreover, flameproof enclosures incorporating "D2D" technology enable the direct connection enclosures or terminal chambers are required. CUBEx is the logical next step in the development of IIC tchnology integrated in the renowend 8220 Series. For use in Group IIB hazardous areas in Zone 1 and Zone 2 or Zone 21 and Zone 22.
The main connection switch of the lighting and heating panels CUBEx Series 8264/5-ExV is operated through the side wall via an actuation mechanism. The circuit breakers are fitted on the second mounting level and are actuated via totary drives. As an option it is possible to fit test keys to the ELCBs to make it possible to actuate the back wall of the enclosure for fixing the devices. Cable entry is done directly via tapped holes, wired directly to the switches. For current distribution the original comb type rails are used at the switching units. A typical design allows for 12 or 24 circuit breakers. Different designs upon request.
|
|
R. STAHL supplies explosion protected terminal boxes in various versions and sizes, as individual enclosures or as terminal box combinations, presented in ecnclosure series.
8118:
glass fibre-rinforced polyester resin, in 3 basic enclosure sizes
8146:
glass fibre-reinforced polyester resin, in 8 basic enclosure sizes and various heights
8125:
painted steel plate or stainless steel, in 6 basic enclosure sizes and various heights
Explosion protection to CENELEC, IEC, NEC
For use in Zone 1 and Zone 2
Terminals fitted to order
Cable entry mounting to order
Degree of protection IP 66
Specialised knowledge is required for designing and construction of explosion protected electrical engineering, it is vital to observe the explosion protection regulations. R. STAHL is experts in this subject! R. STAHL design and manufacture explosion protected terminals to order and to customer specifications taking into account all relevant regulations and standards.
|
|
|
|
|
|
Smart cabinets with a single front door in finely polished Aisi 304 EN-1.4301 stainless steel.
Its monobloc manufacture allows protection up to IP66 with a maximum resistance of IK10 complying with EN-60529 and EN-50102 standards and Nema 4x by UL. A drainage channel prevents any liquid contact with the polyurethene joint or hidden hinges.
Complies with all EC regulations.
Consoles
Elegant, functional consoles manufactured in finely polished
Aisi 304 EN-14301 stainless steel, easily accessed whose design allows for an IP55 protection and maximum resistance of IK10.
Upper door with shock absorbers which makes opening easier, with open bottom and hidden hinges.
It comes with a galvanised mounting plate
Officially approved for food, chemical, pharmaceutical, transformer and telecommunication industries for use both inside and outside, due to the advantages of high resistance to chemical agents and durability.
delvalle serves to order any measurements required, including custom built holes and cut outs both for door and case.
All models in stock for immediate delivery.
Special solutions:
Custom built to order.
Plinths (page 19).
Metal legs.
Polycarbonate window door.
Manufactured in Aisi 316 EN-14401 stainless steel.
Bakelite isolated or stainless steel mounting plate.
Superior EMC electromagnetic protection between frame and contact surfaces which guarantees a perfect electrical connection. EEC regulation 89/336.
|
|
Explosion-proof boxes
Explosion-proof boxes, control stations and panels EEx d IIB and IIC, aluminium alloy, steel or stainless steel (316L), with front window, box extension. Boxes assembling.
|
|
Switch and control systems
- Electric switch and control systems
- Marshalling and distribution panels
- Electrical switch panels in accordance with national and international standards
- Special cabinets (steel, stainless steel, aluminum) for instrumentation, control and electro-technics and for use in hazardous areas
BARTEC BENKE designs and manufactures control system solutions for automation of machines and processes.
|
|
The robust junction boxes made of plastic stainless steel and light alloy are featured by their friendly mounting and installation capability and their design.
They are fitted with pillar terminals for cable of up to 6 mm2. The practical orientated housing form allows for a problem-free access to the connection
terminals for installation.
|
|
|
|
|
|
The CEFEM dust SAFEBLOC ATEX is a cut-off and lock device intended to be used in areas with risk of explosion: zone 21 and 22, for dust "D", according to the EU directive 94/9/EC.
It complies with standards and regulations to ensure the safety of operators involved in the emergency break, the break for mechanical maintenance and the safety break beside any low-voltage circuit terminal.
They are composed of an IM switch disconnector, with a visible cut off, controlled by a right side handle, lockable by three padlocks on OFF position.
A position indicator (ON / OFF or I / O) allows you to view at one glance the position of the switch.
The cut-off system is clearly visible to the operator through a glass window triplex.
These 2mm thick boxes steel are very robust.
A double lock prohibits the opening of the door when the switch is ON and the closure of the switch when the door is open.
Further functions can be equipped according to your specifications: push buttons, lock, cable glands, instrumentation, etc…
Application:
All industries dust ATEX: zone 21 or 22
Cement, Mining, Quarrying, Steel, Paper, and Sugar.
|
|
| ... products without technical information |
| |
ComEx is a flexible system offering standard as well as customer-specific local control and indicating units.
You have the choice between three standard enclosures which can accomodate up to three different control and indicating devices. Combinations of up to three ComEx enclosures are possible.
Either stuffing box glands in M20 x 1.5 and M25 x 1.5 made of plastic or cable glands made of metal are available for the electrical connection. The plastic glands require no lock nuts. Metal glands are screwed into a metal earth plate sheet inside of the enclosure. Maximum amount of cable clands: two off M20.
To ensure easier operation on site, each enclosure can be equipped with an individual info-label. For offshore applications special oil-resistant attachments are available.
|
|
| ... products without technical information |
| |
| ... products without technical information |
| |
INTERTEC offers the widest selection of explosion-proof heaters worldwide.
- ATEX/CENELEC approvals for Europe
- CSA/NRTL approvals for America
- GOST approvals for the Russian Federation
Our EX-heaters in combination with EX-controllers satisfy all requirements from freeze protection as well as high demands in the analyse technic.
For further questions please contact: Tel.+49-9445/9532-0
|
|
THERM HI "smart heater" is a system consisting of
an explosion-proof electric heater and a
microprocessor, designed to control the air
temperature in instrument enclosures and protective
cabinets and to limit the surface temperature of the
heater.
The "option E" is equipped with an intrinsically safe
sensor, thus allowing measurement and accurate
regulation of the temperature of the instruments and
equipment (e.g. of manifolds).
... THERM HI heaters are designed to solve
sophisticated and complex heating problems in
hazardous areas, and in particular for high
temperature maintenance of analyzing equipment.
|
|
|
|
