V-Carb End Mills designed with unique 5-flute geometry reduces harmonics that improve finishes...allows heavier stock removal...can run at higher production rates...suitable for a variety of materials up to 45Rc
|
|
Workpiece requirements call for ever better tool surfaces. Walter Prototyp finishing cutters have special geometries that satisfy this demand. Our geometry prevents chatter marks and produces smooth milling characteristics.
The product range includes tools with different cutting edge lengths and helix angles
N60 – finishing cutter with 60° helix angle
High-twist solid carbide shank cutter for the purest finish
60° helix angle produces a soft cutting action and achieves the best surface finish on the workpiece
Good removal of chips due to the high helix angle, thereby preventing scratching of the machined surface on the component
N45 - finishing cutter with 45° helix angle
Tool specifically for the machining of ISO material groups P, M, and K
Stable and smooth machining of the workpiece due to the all-new microgeometry on the cutting edge, thereby eliminating vibrations.
High-quality TiAlN coating for maximum tool life
|
|
|
|
|
|
WELDON 3AF Finisher:
The 3AF is intended for finishing operations in aluminum and non-ferrous materials. These tools have a high shear 40 degree helix and come standard with a cylindrical margin to provide chatter resistant machining and superior finishes in all non-ferrous materials. Although intended for finishing, the 3AF has also proven itself in lighter roughing applications.
In addition to square end tools, we provide a broad radius program for our 3AF series.
The 3AF is available from stock as a bright tool or with Zirconium Nitride (ZrN) and Titanium Carbonitride (TiCN) coatings for improved performance and extended tool life. Special quotes and non-stocked coatings are available upon request.
WELDON 5SF Finisher:
We round out our Weldon Premium Carbide offering with the 5SF. This tool is intended for finishing operations, though it can also handle medium to light peripheral roughing, in steel and ferrous alloys. A full eccentric primary grind, sharp corners, a 40 degree helix to ensure proper chip evacuation and an odd number of flutes to reduce unwanted harmonics come together in our 5SF to deliver superior finishes in ferrous materials. The 5SF should be your first choice in premium carbide for finishing and medium to light peripheral roughing for steel and ferrous applications.
Our 5SF square end tools are complemented by a broad radius program.
Aluminum Titanium Nitride (AlTiN) and Titanium Carbonitride (TiCN) tools are available from stock in stub, standard, long and extra long lengths. Special quotes and non-stocked coatings are available upon request.
|
|
|
|
