The versatile Hannay PW-2 Series reel is designed to quickly mount to almost any type of pressure washer. It is ruggedly constructed of 12 and 14 gauge steel, with a black powder coat finish. It is designed for all mobile and portable pressure wash equipment as well as steam cleaning, spray and washdown applications.
The PW-2 Series reel has a pressure rating of up to 4000 psi and has an adjustable split bearing brake assembly allows for an infinite number of tension settings. The PW-2 Series also features a permanently attached direct crank rewind. A variety of optional mounting kits and accessories are also available..
Hannay Reels is the leading manufacturer of durable hose and cable reels for both OEM and aftermarket applications, offering thousands of standard models along with a wide range of custom design capabilities. The company’s superior manufacturing techniques, consistent quality, outstanding service and unmatched value result in the most dependable, best-engineered reels in the business. This formula has successfully allowed Hannay to help companies around the world improve the productivity, efficiency and safety of their operations since 1933. Hannay’s industry-specific expertise comes from decades of experience with a variety of markets, including firefighting, aviation, industrial, processing, audio/visual and transportation. For additional information, visit http://go.hannay.com/PR or email catalogs@hannay.com.
|
|
Kärcher high-pressure cleaners fulfill every demand and are used in the widest variety of fields. In agriculture, crafts and trades, industry, or municipalities – we are in our element wherever large areas must be cleaned daily.
Cold water high-pressure cleaners
Clean machines, vehicles and buildings daily: with high pressure and a high flow rate, cold water high-pressure cleaners remove even stubborn dirt. Ideal for large areas.
Hot water high-pressure cleaners
High pressure cleaners clean even better with hot water with the same amount of pressure. Kärcher machines are convenient to use, and they feature state-of-the-art technology.
Stationary
Kärcher stationary high-pressure cleaners are suitable wherever it is necessary to clean and disinfect several areas in a space-saving manner.
|
|
|
Hand-held or semi-automatic tools for cleaning and paint stripping on large-scale surfaces, such as ship hulls, storage tanks or engineering structures.
|
|
|
|
|
|
Industrial series:
a very ample and complete range that understands models to cold and warm water and with tensions both in singlephase that threephase. To use him in every sector for the cleaning with tall pressure and tall temperature with the possibility to mix, to application, a chemical additive. In the standard versions the powers reach 400 cafes with courses up to 60 lts. / min. In the water versions warm the temperature is adjustable up to 150° with possibility to produce vapor. With the specific kit it is possible to use her as hydrosandblasters. Thanks to the use of pomps and tested boilers and components to the state-of-the-art one our high pressure are how much of can offer better the market. Reliability, constructive quality and safety, are at the base of our products. We prepare of numerous used revised guaranteed.
Special series:
to application we are able to plan and to realize special groups with particular preparations. Our technical office is to your disposition.
Semiprofessional series:
numerous models both to warm water and to cold water for demands hobbyand for small interventions. They understand numerous accessories that make her functional for varied demands: kit uncork, kit sanding, rotating brush…
|
|
Destined for use by those professionals with very low cleaning frequency or intensity such as single employee tradesmen, or the smallest farms for occasional cleaning of equipment and vehicles, the POSEIDON 1 offers an attractive price, great compact design – and yet the quality and versatility of true professional spray equipment.
The POSEIDON 1 stands for:
• Great compact design
• Cleaning performance
• Unbeatable ergonomics
• Versatility of true professional spray equipment
The POSEIDON 1-20 XT comes equipped with versatile and easy to use
professional equipment:
• 15m DN6 hose
• Flexopower lance with high and low pressure functions
• Tornado Plus nozzle
• Turbohammer lance
• Ergo 1000 spray gun incl. hose swivel
|
|
Mazzoni’s range of cold water high pressure washers includes machines from 7 to 21 lts / min and from 120 to 200 bar.
For these machines the offer is particularly addressed to professional users but you even could find some commercial and hobby models.
This line includes a stainless steel fixed station with dampner that can be easily used for the cleaning of hard and large surfaces especially in the food industry.
Four models of petrol engine units with motor Honda and electric or manual starting complete this range of products.
Professional pumps and elastic coupling always complete our high pressure washers.
|
|
|
|
|
|
Overview
The unique GPW-1000-P Air Powered Hi-Pressure Washer can be used safely in all areas. It is ideal for applications where electric or gasoline powered units are prohibited due to hazardous conditions such as in refineries, and chemical, paint and nuclear plants.
GPW-1000P-50 Air Powered Hi-Pressure Washer.
Specs
. Motor Power: Up to 2 HP (1.9 kW) depending on air pressure and volume
. Air Requirements: Minimum 80 PSI at 75 CFM (5.5 BAR at 2.1 m3/min), Maximum 100 PSI at 85 CFM (7 BAR at 2.4 m3/min)
. Output Water Pressure: 1,000 PSI at 2.2 GPM (70 BAR at 8.3 LPM)
. Pump: Twin-piston cast iron
. Dimensions: 37" (940mm) high x 20" (510mm) wide x 17" (430mm) deep
. Weight: 67 lbs (30 kg) net dry
Features
. Air powered - shock resistant
. Stainless steel construction - long life
. Steel reinforced hose - rugged
. Stainless steel wand - durable
. Five quick disconnect nozzles - matches application
. Can use hot water - additional cleaning power
. Soap container - easy injection of chemicals
|
|
PRAMAC PW 3000
Main features
Maximum pressure : 200 bar
Flow : 15 l/min
Drive : Gearbox
Engine manufacturer : Honda
Starting system : Recoil
PW Series
Easily transportable and ready to use, this is the ideal machine for the myriad of professional and residential uses.
|
|
|
|
|
|
The Nilfisk-ALTO NEPTUNE range spans the compact to the very heavy duty lines and is fit for any imaginable application in automotive, industry or agriculture. Even the most compact units offer the customer the benefit of some of the most powerful innovations on the market.
The NEPTUNE 2 is the newest offering in our compact class, destined for use by garages, car dealers, tradesmen, small to medium farms and small construction companies.... It comes in a new, vertical design that not only significantly reduces footprint and storage space, but also enables the products to be wall-mounted as semi-stationary units.
The NEPTUNE 2 can be easily stored and transported. In a workshop, the small footprint allows the machine to be easily placed in a corner - or on a wall - well out of the way. The new, versatile design can be placed vertically or horizontally during transport - ideal for a commercial van or station wagon. The optimally studies design with large wheels and good ground clearance can be easily tipped and pushed or pulled along uneven ground or up steps.
Design is one element. Technical performance, low cost cleaning and reliability are further key criteria.
The new NEPTUNE 2 is characterized by:
-26% smaller footprint than competition giving new storage and transport possibilities
-16% lower fuel consumption - a major benefit as fuel prices soar
-27% longer run time on a full fuel tank reduces machine down time
-100% mobility
Plus all the traditional Nilfisk-ALTO values:
-Reliability
-Unbeatable ergonomics
-Excellent cleaning performance
|
|
Mazzoni proposes a complete range of hot water high pressure washers.
Its offer, especially addressed to the professionals, also includes models for commercial and hobby use.
Available from 7 to 30 lts / min and from 120 to 250 bar, all Mazzoni hot water high pressure washers are equipped with professional pumps and elastic coupling.
All the models are sturdy but easy to handle and allow an intensive use even in unfavourable conditions. The heaviest versions, for example, have been equipped with a fifth jockey wheel that facilitates the displacement and also with a painted iron chassis to make them adapt to be used in the yards.
Several models of stainless-steel static machines for the cleaning of tools and machineries and anywhere it is necessary a regularly cleaning (food industry, motor shows, workshops, service areas).
Mazzoni is able to rapidly answer to all your needs also with personalised products able to satisfy the most particular demands.
|
|
|
|
|
|
Stationary installations from Nilfisk-ALTO are the answer to your cleaning needs. Machines can easily be installed in any location around the site. A carefully planned and optimized piping system will then ensure that you can easily and quickly clean at any area of your installation.
The Nilfisk-ALTO SOLAR BOOSTER 5 series is adapted to general use in light industry, vehicle cleaning and even self-service. The Nilfisk-ALTO SOLAR BOOSTER 7 series is optimal for tough and intense cleaning applications in heavy industry, transport and food industry. The famous C3 pumps used in the 7 series will just run and run… providing a valuable partner for the toughest jobs.
All Nilfisk-ALTO SOLAR BOOSTERS come equipped with galvanized steel frames and cabinets for ease of maintenance, and is easy to service. All units are equipped with Nilfisk- ALTO’s expandable control technology – meaning any standard machine can be turned into a personalized solution, thanks to a wide range of factory mounted options.
Diesel powered stationary heating for maximum efficiency Diesel powered stationary heating for maximum efficiency in the automotive, industrial and shipping sectors.
Electrical powered stationary heating for maximum efficiency in the automotive, industrial, food and shipping sectors.
Gas powered stationary heating for maximum efficiency in the automotive, industrial sectors.
|
|
Dynajet 150t
Compact, powerful and well thought out of right down to the last detail. Ideal for cleaning professionals, refurbishing experts and all users requiring the greatest cleaning performance from the combination of water pressure, amount of water and optimum water temperature. These professional machines are run with powerful diesel engines.
|
|
Dynajet 500th
Ideal for cleaning and refurbishing professionals as well as all users who have high demands in cleaning. The Dynajet 500th offers an optimum combination of water pressure and water flow rate and an optimum water temperature. Due to its design, the Dynajet 500th can be transported to the work place completely ready for operation. The speed of the diesel engine can be adjusted manually. Both the high pressure pump and the two high pressure burners operate independently of an external electrical power supply. Thanks to the integral water tank it is possible to carry out cleaning work flexibly and without a stationary water supply. Ideal for cleaning facades, old buildings, vehicles, construction machines, form-work, scaffolding, etc. as well as refurbishing facades, balconies and old buildings
|
|
| ... products without technical information |
| |
The Hypro Series 5200 Big Twin piston pump is suitable for applications in high pressure washers for industrial and agricultural cleaning needs. It is also useful as a sprayer pump to apply a wide range of chemicals. The Series 5200 is constructed of cast iron body and cylinder heads, unitized stainless steel valve assemblies and double row ball bearing supported crankshaft.
Performance Information
- Max. flow: 10 gpm/37.9 lpm
- Max. pressure: 400 psi/27.6 bar
- Max. rated speed: 600 rpm
- Max. fluid temperature: 140°F/60°C
|
|
The Hypro Series 5200 Big Twin® piston pump is suitable for applications in high pressure washers for industrial and agricultural cleaning needs. It is also useful as a sprayer pump to apply a wide range of chemicals.
The Series 5200 is constructed of cast iron body and cylinder heads, unitized stainless steel valve assemblies and double row ball bearing supported crankshaft.
|
|
The Hypro 2535S triplex plunger pump is designed for durability, top performance, and convenient servicing. It achieves up to 38 gpm (144 lpm) and 1200 psi (83 bar). The 316 stainless steel two-piece manifold minimizes washout and corrosion. A strong power end including oversized crankshaft, bearings, and connecting rods easily handles abuse caused by start-up and intermittent operation.
Backed by the best warranty in the industry, Hypro pumps are designed for, and not adapted to, the car wash industry, resulting in pumps that deliver higher pressure and increased reliability.
|
|
|
Self-serve carwash and tunnel prep unit owners across the country are making the switch to Hypro’s 2300 Series plunger pumps. Backed by the best warranty in the industry, Hypro pumps are designed for, and not adapted to, the car wash industry, resulting in pumps that deliver higher pressure and increased reliability.
|
|
URACA high pressure and ultra high pressure plunger pumps are outstanding in their compact design and flexible applications. Based on the industrial process pump design, the pumps are relatively unsusceptible to small particles in the tap water, even at high pressures.
Options
- Flanged housing for hydraulic drives ISO 125 / ISO 140
- Drain device
- Suction and discharge connections, optionally on left or right-hand side
- position of drive, optionally on left or right-hand side
- special designs: hot water, stainless steel, solvents
- stuffing box cooling / flushing is possible with power end cooling
- pump unit with electric or diesel drive
- pump unit suitable for pressure tests with ATEX certificate
|
|
The Jet Edge iP55-75 is a 75-horsepower intensifier pump rated at 60,000 psi (4,100 bar). It is capable of producing output pressures from 1,000 to 55,000 psi (3,800 bar) with flow rates of 0 to 1.5 gallons (5.7 liters) per minute to a variety of cutting, surface-preparation or cleaning tools.
Features
- High efficiency TEFC motor
- 1,500 or 1,800 nominal motor speed (rpm)
- Electronically shifted intensifiers
- Wye-Delta soft start with disconnect
- 0.5 gallon (1.9 liter) high pressure attenuator with 1.45 micron filtration
- Safety shutdown systems
- Automatic safety pressure bleed-down valve
- Thermostatically controlled cooling system
- Programmable Logic Controller (PLC) for operation and safety monitoring
- Axial piston, variable displacement, pressure-compensated hydraulic pump
- Liquid-filled pressure gauges
- UHP safety shielded tubing
|
|
|
|
|
|
Maximum Productivity, Lower Cost of Operation
Maximum productivity and low operational costs are the keys to keeping your business competitive. Flow's 55,000 psi HUSKY pump sets a new industry standard for both productivity and reliability, giving you a portable ultrahigh-pressure waterjet pump that contributes to your bottom line by allowing you to work more efficiently and take on more jobs. The HUSKY is the world's first 55,000 psi direct drive triplex pump with full pressure compensation giving you the power you need to reduce your operating costs and increase productivity on a square foot basis. Now you get Flow's proven HUSKY UHP pump with a world class Caterpillar C-9 engine that meets Tier II emission requirements, on board diagnostics and lower fuel consumption.
The 55,000 psi HUSKY is compatible with all other Flow machines, meaning no additional investment in technology is necessary to upgrade.
Benefits
Maximum productivity from 55,000 psi - the highest pressure available in the industry
Lower cost of operation gives contractors a competitive advantage when bidding on jobs
Compatible with all existing Flow industrial cleaning products
Latest technology makes 55,000 psi pump the easiest-to-use, most reliable pump in the industry
Standard Features
290 hp Caterpillar C-9 Engine, producing 210 nhp - the highest available nozzle horsepower
Automated settings for multiple tool operation
Diagnostic sensors to assist with troubleshooting and preventative maintenance
Engine meets worldwide Tier 2 emission standards
On-board water booster and filtration system
Full pressure compensation allows for multiple tool use
Triple high-pressure outlet ports
82 gallon fuel tank
Multilingual remote operator box
Small 58.5" x 102" footprint
Specifications
Operating Pressure: 55,000 psi (3,790 bar)
Maximum Flow Rate: 6.5 gpm (24.5 lpm)
Approximate Weight: 5575 lbs (2534 kg) dry
Fuel Capacity: 82 gal (310 l)
Engine: 290 hp (216 kW) Caterpillar C-9
Nozzle Horsepower: 210 nhp (157 kW) continuous duty
Speed: 2,100 rpm continuous duty
Water Filtration: 10 micron absolute
Mounting Type: Skid or optional trailer mount
|
|
| ... products without technical information |
| |
High Pressure Spray Gun/Lances
Heat resistant nylon trigger. Available with a variety of lances.
Normal flow rate: 10.5 gpm.
Pressure range: 2900 - 4050 psi.
Maximum temperature: 320º F.
Spray angle: adjustable from a straight jet to a large-angle spray.
Materials: fiberglass reinforced nylon (body), brass, 203 stainless steel, 440 stainless steel. Typical applications: high-pressure washing.
|
|
SP 503: Depending on their discharge pressure and capacity, the spray guns and lances are suitable for washing, cleaning and cutting.
- Operating pressure max: 500 bar
- Recommended flow rate max: 75 l/min
- Length of standard tube: 800 mm
- Overall weight: 2.35 kg
|
|
|
|
|
|
Safely and Quickly Removes Tough Materials
Flow International Corporation's A-3000 ultra light hand tool combines the power of ultrahigh-pressure (UHP) water (and its relatively low water volumes) with extremely high nozzle rotation speeds. The result is a versatile tool that offers excellent removal rates for a wide variety of industrial cleaning projects.
This multi-purpose tool offers superior performance and control. Rotating a variety of multiple-orifice tips at up to 3,000 rpm, the A-3000 delivers as much as 6.5 gallons (22.7 liters) per minute of ultrahigh-pressure water. It is the only hand tool rated for operating pressures of 45,000 psi (3,100 bar).
Multiple Applications Multiply the Savings
The A-3000's high rotation speed makes it the ideal tool to remove the toughest coatings, including epoxies, resins, paint, rust, scale, calcium deposits and oxides. And because it is air-powered, the A-3000 is easily operated from any compressed air supply.
With its unmatched productivity and low water volumes, the A-3000 is an environmentally-sensible alternative to grit blasting, burning and chemical removal. The A-3000's light weight reduces operator fatigue so workers can work longer, and more safely.
Benefits
Reduced operator fatigue improves safety and productivity
Pneumatic power means no oil spills
High removal rates with minimal waste water
Standard Features
Remotely located on/off valve
Advanced ergonomic design
Lightweight
Patented swivel design allows quick change of high-pressure seals and easy maintenance
Second safety trigger requires operator to have both hands on tool for safe operation
Runs from any compressed air source with greater than 32 scfm at 90 psi
Flow patented HornetTM nozzles
Specifications
Tool weight: 11.0 lbs (4.98 kg)
Maximum operating pressure: 45,000 psi (3,100 bar)
Air required: 32 scfm @ 90 psi
Working rotation speed: 3,000 rpm
Motor horsepower: 0.7 hp (0.5 kW)
|
|
Eco Top guns include high-pressure guns with operating pressures up to 2500 bar with pneumatically driven lead-through and electric or pneumatic remote control.
Equipped with guard bow and trigger safety lock. Plastics hand grip and stainless steel lead-through.
High cleaning efficiency due to rotating nozzle carriers.
Rotational speed control due to air pressure and air flow rate.
Fully covered hand grip in two-sheet design, made from impact resistant and chemically resistant plastics (protection system IP 67).
All functional parts are protected against penetrating water and dirt.
Special air motor with stainless steel housing
Nozzle pipes with protection pipe between 300 and 770 mm
|
|
| ... products without technical information |
| |
High Pressure Cleaner
400L Removable tank, quick to fit and remove
Water level indicator
Drain plug
Weight: 170Kg
PERFORMANCE
Adjustable pressure: up to 7L/min, 50 -130 bar
Electric 48V, 2Kw motor
High/Low pressure handgun spray, 10L/min, 10 bar
15m spring retractable hose reel
Ventury additive and injector system
Option : spray line
OPTIONS (400L Version)
Front mounted jet spray
• Manually adjustable for use on the right or left hand side
• 4 jets covering 1.10m
• Manual valve control
Extending arm
2m reach for clearing obstacles,
Height of 1.8m
200L Compact Version
Weight: 140Kg
Multipurpose function allows simultaneous cleaning and collecting
400L High pressure cleaner and watering hybrid
A multiple solution combining cleaning and watering in the same journey
|
|
|
|
