Operator Interfaces - Human Machine Interfaces
FEATURES:
Many PLCs supported
Friendly multiple languages supported to the end users
Temperature controllers & inverters directly connected to HMI via Modbus
Data logging, bargraphs, trends and alarms
Animation: display/hide, flash, color changed
Data entry and data displayfrom/to PLC registers directly
Free configuration software, configuration for all HMIs from PC software
Upto 65535 screens in each project, pop-up screen and associated screen supported
Ladder programming (Soft PLC) supported in HMI and Ladder online monitoring
Screen security
Floating point suppored
Ready made registers for Real Time Clock
Unique Tag database for HMI and PLC registers
256 real time alarms, and 30 or 2000 historical alarms
Global tasks, power-on tasks, list of predefined tasks and screen tasks-before, while and after
Ready made objects for lamps, botton , data entry, data display, trend, alarm, bitmaps, meters
Action for graphical objects from list of predefined tasks
Ready-made system coils for changing RTC data by sec., min., hour, day, month, year
|
|
Customised touch screen systems
Individual touch screen systems
Can be combined with other technologies (e.g. with membrane keyboards)
Customised electronic circuitry
|
|
Beijer Electronics EXTER™K10 keypad panel with Monochrome FSTN display
Display: Graphic monochrome FSTN, resitive touch
Presentation form: 160 x 32 pxl
Function keys: 6 (6 with integrated LED and text strip)
Front protection class: IP66 (waterproof even when exposed to high pressure washing).
With EXTER™, you get an operator panel that is ready to impress you. Its high-performance Intel Xscale® processor, robust construction and multiple communication ports make it a futureproof choice for your machines and processes. There are fourteen models to choose from - seven with touchscreen display, six with keypad control and one mobile operator panel. The award-winning, slim design and the powerful performance make EXTER™ an operator panel beyond the ordinary.
|
|
AutoLog® AL121CE - HMI
Graphical 12.1 " Windows CE touchscreen which has full support for Web Studio SCADA development tools. More than 200 device drivers. Powerful CPU processor. Versatile connections.
Type TFT Color LCD
Screen size (diagonal) 12.1"
Max. colors 65536
Resolution 800x600
Pixel size (HxV, mm) 0.3075 x 0.3075
Viewing angle (°) 95 down / 95 up / 120 left / 120 right
Luminance (cd/m2) 250
|
|
|
|
|
|
Touch screens are often used as an alternative—or in addition to—more traditional human-machine interface technologies, such as a membrane switch or keyboard. The use of a touch screen allows the keypad to be reconfigured as desired to suit the application. Because of their intuitive nature, touch screens are often used in applications where the user cannot be trained to interface with the device. Kiosks and point of sale devices exemplify these applications.
The process of authentication or the fundamental skills of communicating and learning can be enhanced with a touch screen that provides tactile feedback. Devices that provide synchronized sound and graphics upon touch are more intuitive, personal and satisfying. Now the predictive sensation of touch and response can be applied to touch screens to heighten interaction and usability.
Advanced Input Systems can help Original Equipment Manufacturers heighten the level of interactivity and build a more engaging user experience with TouchSense® technology. This programmable technology by Immersion® adds tactile feedback to touch screens. And sensory-based touch screens that “touch back”, supply distinct benefits and give users a new and more satisfying experience—one that’s more interactive, engaging, intuitive, and fun.
|
|
Beijer Electronics EXTER T40/T40m, touchscreen panels with 3.5” display
Display: Graphic 64K color TFT/Graphic 16 grayscales
Presentation form: 3.5”, 320 x 240 pxl
USB Host
Front protection class: IP66 (waterproof even when exposed to high pressure washing).
With EXTER™, you get an operator panel that is ready to impress you. Its high-performance Intel Xscale® processor, robust construction and multiple communication ports make it a futureproof choice for your machines and processes. There are fourteen models to choose from - seven with touchscreen display, six with keypad control and one mobile operator panel. The award-winning, slim design and the powerful performance make EXTER™ an operator panel beyond the ordinary.
|
|
Beijer Electronics H-series H-T50b, touchscreen panel with mono STN LCD 4.7” display
Display: Mono STN LCD, 16 shades of blue
Presentation form: 4.7”(diagonal), 240 x 128 pxl
The H-series offers valuable HMI functionality at an affordable level. The series include keypad and touch screen interfaces and is available in seven different sizes from 3 to 10.4 inches. Offering three levels of functionality – Standard, Plus and Network – the H-series enables you to select and pay for what level of HMI technology you need.
|
|
AGP3000 Series : 20 models of Graphic Operator Interfaces ... 6 screen sizes. (3.inch/5.7inch/7.5inch/10.4inch/12inch//15inch/).
- TFT colour screens (65.536 colours) or STN (4096 colours), B&W or Amber.
- Aluminium die-cast bodies.
- Connectivity with numerous devices : serial interfaces, Ethernet, Expansion Unit, USB (x 1 ou 2), CF-card, sound out, very powerful CPU. 5 multimedia models= Video In + Sound In.
- All protocols available: Unitelway, Modbus, MPI, Sysmac...
Pro-face, world leader on touch panels invits you to discover a powerful and easy-to-use range of products.
|
|
|
|
|
|
Touchscreen HMIs that strike the perfect balance of advanced features and value.
The G3 Kadet series of operator interface panels offer a host of functional interface and connectivity features for applications where FTP access, data logging, and web server capabilities are not needed. Based on the G3 series, with many of the same capabilities, the G3 Kadets offer far more features than conventional HMIs while providing an advanced interface that is ideal for OEMs, discrete machinery and process machinery.
Available in 4.3", 5.6" and 8" models, the G3 Kadet series offers the same protocol conversion benefits as the original G3. The units have multiple serial ports, drag-and-drop configuration via Crimson programming software, and port sharing capabilities. The larger models feature integrated Ethernet allowing simultaneous communications with up to six device types including PLCs, PCs, drives, PID controllers
and more.
Models :
- G304K 4.3" Operator Interface with TFT Display
- G306k 5.6" Operator Interface with TFT Display
- G308k 8" Operator Interface with TFT Display
* CONFIGURED USING CRIMSON® 2.0 SOFTWARE
* TWO SERIAL COMMUNICATIONS PORTS
(1 RS-232 AND 1 RS-232/422/485)
* UNIT’S CONFIGURATION IS STORED IN NON-VOLATILE FLASH
MEMORY
* BRIGHT 4.3-INCH TFT ACTIVE MATRIX 256 COLOR 480 x 272
PIXEL DISPLAY
* THREE FRONT PANEL LED INDICATORS
* NEMA 4/IP65 FRONT PANEL
* POWER UNIT FROM 12-28 VDC
* RESISTIVE ANALOG TOUCHSCREEN
|
|
|
|
|
|
A New Generation of Graphic OITs
The Silver Series Plus operator interface terminals offer a wide array of display sizes and connectivity options, high quality displays, enhanced data management and monitoring features, & high quality graphics & design options.
The enhanced displays come in 6”, 8”, 10” & 12” sizes, & all units feature 65K-color high-brightness, high-contrast TFTs with high-precision touchscreens.
The OITs deliver a wide variety of connectivity options. 10/100BaseT Ethernet allows for multiple high-speed network configurations. There are three USB 2.0 host ports, three COM ports, audio in/out ports, CompactFlash port, & 44-pin IDE interface.
Many enhancements have been made to the Silver Series Plus’s configuration software. One of these is data management tools – which now includes data sampling & data logging features. Other enhancements include the ability to program projects in up to eight different languages & improved security features with up to six levels of password protection.
Pricing for the Silver Series Plus operator interfaces is extremely affordable – with the 6” display listed at just $600.
|
|
Embedded panels
Description
Magelis Smart is as easy to set up as it is to maintain.
Simple and easy tp use
Standard Windows XPe technologies
Touch-sensitive screen and viewing angle of up to 160°
Swapable with most Magelis
Dependable availability
Compact
Rugged : Hardened and UL 508, CSA certification
Open
Internet/intranet access
Easier to upgrade : Fast Ethernet 10/100 Mbps port, Compact Flash card, 2 PCMCIA expansion slots
2 Fast Ethernet ports
|
|
Operating temperature -20 ... +70 °C ; Storage temperature -40 ... +80 °C ; Operating load 0.5 + - 0.3 N Operating life 10.000.000 Hits by finger
Operating life 100.000 Characters by pen ; Light Transmissivity > 80 %
Top surface hardness >2H
|
|
|
The LabVIEW HMI family of industrial panels provides three different hardware platforms so LabVIEW developers and programmers can deploy operator interfaces alongside a broad range of NI product platforms. The National Instruments FPT-1015 is a 15 in. flat-panel touch screen for all PXI embedded controllers and a flat-panel monitor for the NI Compact Vision System. The NI TPC-2006 is a 5.7 in. Windows CE touch panel computer programmed with LabVIEW PDA to create a remote terminal for headless real-time controllers such as Compact FieldPoint and CompactRIO. The NI PPC-2015 is a Pentium 4 PC that runs Windows XP and works with a wide range of I/O devices from National instruments; it connects via Ethernet to all NI PACs. To create an HMI for a broad range of distributed data the LabVIEW Datalogging and Supervisory Control (DSC) Module provides connectivity to NI hardware and third-party hardware through OPC, Modbus TCP/IP, and gateways for industrial communication protocols.
|
|
|
|
|
|
Human Machine Interface
Automata, starting from customer requiremts, develops human machine interface complete projects.
it writes specifications of "Industrial Design" to conform the product to esthetic and ergonomics of application, studys layout colors, defines graphic pages and explicative synoptics. Beside that Automata design both electronics and mechanical parts (also by die casting) and take care of manufacturing proces tune.
In order to have so high integration level of the product, Automata uses Co.Design technics, that is team work of designer for all design and manufacturing process, sharing project files, cooperating with the customer and engineers involved into product definition.
Design approach
- Adaptation of esthetic shapes an colors to machines requirements
- Study of ergonomics and usability of interface unit
- Easiness of "comunicabiliy" of machine functionality
Proposal processing
- Proposal of different project solutions
- Definition, by computer emolution, and "maquettes" made of polystyrene of pojects chosen.
- Realization of prototypes with techniques of quick production
|
|
|
Full graphics capable HMI family, AC or DC supply versions. Recipe, alarm and data logging. Animation and bitmap functions. Common software for all models. IP65.
|
|
Operator panels of series AS-Pxx:
The devices allow for simple operation, diagnosis and monitoring of your machines and systems. You can design the user interface according to your requirements.
An intuitive operator prompting via touch screen, assigned function
keys or a combination of both are possible. The use of insertable strips allows for individually labelling the keys.
Operator panels of series V606:
The convenient and cost-efficient operator panels for all systems,
which can be connected via modbus, are particularly suited for simple visualization tasks. In combination with our controllers, it provides you with a complete automation solution.
|
|
Flexible Design and Options
- Available in 12", 15" & 17" touch screen sizes
- Standard and Performance configurations for ease of ordering
- Deluxe units come with either a CD-RW or DVD+/-RW drive
- Optional stainless steel bezel
- Memory and hard drive upgrades available, including Compact Flash
- Key communication interfaces - Ethernet, USB, serial, parallel; ISA & PCI slots are available for field bus or other add-on requirements
Ease of Use and Maintainablilty
- Five built-in system access keys that provide full functionality without a keyboard or mouse
- Front USB port for easy access to portable devices
- Hardware diagnostics information that can be communicated to GE Fanuc software
- Meets stringent specifications for industrialhardened equipment, including hazardous locations (Class I Div II)
|
|
The 1001 Series is a keystart control panel fully equipped with all the necessary instruments and protection
Construction and finish
- Components installed in a heavy duty sheet steel enclosure
- Phosphate chemical pre-coating of steel provides corrosion resistant surface
- Polyester composite powder top-coat forms high gloss and extremely durable finish
- Lockable hinged panel door provides for easy component access
Mounting
- Mounted to generating set baseframe on robust steel stand
- Vibration isolated from generating set
- Located at rear of generating set with excellent panel visibility
- Installed as an integral part of the enclosure on-enclosed generating sets
Instrumentation
- AC instruments are 90° deflection, 72 mm square, flush mounting
- AC instruments in accordance with IEC60051 and 60529, DIN43700 and 43718, BSEN60051 and 61010, UL94
- Engine gauges are heavy duty, 52 mm diameter, electrically operated
|
|
|
With a complete range of Touch Panel PCs, Industrial Panel PCs, and Industrial Flat Panel Monitors, Advantech offers a wide range of HMI products for industrial automation needs. By creating value-added, standard product solutions and by offering customization, Advantech can provide platforms to meet any requirement.
|
|
|
|
|
|
Features of full graphic-capability operator terminals for controls:
- Many PLCs supported,
- Temperature controllers & inverters directly connected to HMI via Modbus
- Friendly multiple languages supported to the end users
- Many available sizes like 12.1" color, 5.7" color & mono, 4.1" & 2.5"
mono
- Data logging, bar graphs, trends and alarms
- Animation: display/hide, flash, color changed
- Data entry and data display from /to PLC registers directly
- Free Windows based configuration software for all HMIs
- Upto 65535 screens in each project, pop-up screen and associated
screen supported
- Ladder programming (Soft PLC) supported in HMI and Ladder online
monitoring
- Screen security
- Floating point supported
- Ready made registers for Real Time Clock
- Unique Tag database for HMI and PLC registers
- 256 real-time alarms, and 30 or 2000 historical alarms
- Global & power-on tasks, list of predefined and screen tasks-before, while and after
- Ready made lamps, button, data entry, data display, trend, alarm,
bitmaps & meters
- Action for graphical objects from list of predefined tasks
- Ready made system coils for changing RTC data by sec,min, hour, day, month, year
- IP65 design, CE, cUL, UL certificates
|
|
HMIs & Displays
The scalable product line of the new HMI systems (Panel PCs, Micro Clients, Touch Panels)offers a wide range of processor capacities and display dimensions from 7.0" up to 19". The 100% industry-capable Panel PCs and displays meet toughest industrial requirements concerning shock, vibration and temperature resistance. However specific your requirements we supply you with semi- and full-customized Panel PCs and displays for your control and visualization applications.
|
|
|
|
|
|
HMI solutions for every application
Mitsubishi Electric has pushed forward the development of its visualisation programme, realigning the products in this sector with a new concept called Vision 1000. This concept is built around three series of products: the GOT1000, E1000 and IPC1000 series. All three series share flexibility, openess and seamless compatibility with all Mitsubishi Electric automation systems.
GOT1000 Series
The GOT1000 series is the ultimate in control unit quality and performance. The impressive array of functions and simple touchscreen operation give users everything they want and need.
E1000 Series
The new control units are also packed with advanced Mitsubishi technology standards, such as comprehensive communications support, which includes networking, Internet and SMS mobile network text messaging capabilities - along with features like multi-language user interfaces and dual driver support.
IPC1000
Personal computers are a part of everyday life as Industrial PCs are a part of Automation and process control. Mitsubishi’s new IPC1000 Series including Eco panels and flexible Business panels, bring together the very best of open PC technology with a long understanding of the rigors of the industrial environment.
|
|
RAFI produces complete control panels and data entry systems including electronic circuitry and interfaces. We design our systems with special emphasis on reliable data input and convenient operation. A wide range of technological and design options enable RAFI to quickly implement individual solutions. For example, we utilise the following equipment for in-house production:
CAD development tools (3D)
Screen printing machines for the production of overlays
Sheet metal machining equipment for front panels
SMD and conventional assembly of printed circuit boards
Individual assembly and testing facilities
|
|
Advanced Input Systems integrates a wide variety of display technologies into user interface products—with great design and cost flexibility. We translate your needs into the ideal display solution to meet variable lighting, environmental and user conditions.
The myriad of end applications suited for display technologies today has created a diverse portfolio of choices. From text delivery to complete integrated solutions, each display technology provides unique capabilities and functions best matched to a specific need. Advanced Input Systems offers the necessary experience to integrate whatever choice of display technology OEMs require to meet technology, time to market and cost parameters.
Available Technologies:
1) LED: Segment and Dot Matrix Light Emitting Diode (LED)
2) LCD: Active, TFT (Color)
3) LCD: Passive
4) Passive LCD
5) Electro-Luminescent (EL)
6) Vacuum Florescent
7) Touch Screens
8) Display Controllers
|
|
Control panels up to 500 x 500 mm
We offer a customized production of such control panels. So we are able to take all your wishes into consideration.
We supply them both, for suface wiring and concealed wiring.
The following designs are available:
Mat aluminium, brushed surface
drawn aluminium, glossy surface. Anodized in nature, gold, dark bronze and black
As plastic mosaic panel
Upon request, the instrument panels can also be engraved, e. g. with letters, numbers, flow charts, symbols, etc.
All the control panels are also available assembled with Schlegel or DUX control units.
Mounting dimensions:
- 16 mm
- 22 mm
- 30 mm
or according to customers' requirements
|
|
The 950 Series includes a compact, single channel device and a deluxe, multi-channel device for operation of up to four mass flow instruments. The 950 Series is designed for use with the Sierra Model 830L, 830M, 840L and 840M instruments, but can be used on any brand of MFM or MFC. Both of these powerful digital systems supply power (+/- 15 VDC), display the flow rate, and offer set point control for MFC’s.
951 UNIQUE PRODUCT FEATURES
- 5 digit LED display
- Front-panel pushbutton set point, calibration and alarms
- Integral power supply (+/- 15 Vdc)
- Compact size—1/8 DIN
- CE Approved
954 UNIQUE PRODUCT FEATURES
- 4 line, 20 character LCD display
- Valve Close, Valve Open (Purge) pushbutton override
- Front-panel menu adjustable:
- Flow units
- Set Point
- Totalizer
- Gas K-factors
- Alarms
- Master/Slave Ratio Control
- Calibration
- Analog Outputs: 0-5, 0-10 VDC and 4-20 mA
- Digital Output: RS-232 and RS-485
- CE Approved
|
|
Whether you require an intricate device incorporating multimedia options, cursor control, and touch screen or perhaps just a single-station keypad, Advanced Input Systems is dedicated to providing end-to-end solutions. Rapidly and cost effectively.
Hybrid keyboards use a combination of two or more switch technologies. Hybrids are particularly useful when a high-speed typing array is combined with a large number of special function keys. These keyboards give our customers yet another way to differentiate their products from the competition and to meet the needs of their unique application.
|
|
Beijer Electronics H-series H-T80c/H-T100t, touchscreen panel with color STN/TFT LCD 7.5”/10.4” display
Display: Color STN LCD/ Color TFT LCD
Presentation form: 7.5”/10.4” (diagonal), 640 x 480 pxl
Keypad: 1 Menu key and 6 user-defined function keys
2 USB Hosts, 1 USB Device, CF-card
The H-series offers valuable HMI functionality at an affordable level. The series include keypad and touch screen interfaces and is available in seven different sizes from 3 to 10.4 inches. Offering three levels of functionality – Standard, Plus and Network – the H-series enables you to select and pay for what level of HMI technology you need.
|
|
IndraControl V - The Front-End for Operation, Monitoring and Diagnostics.
Are you looking for an operator terminal or industrial PC with robust, reliable technology and flexibility? Would you like to have a choice in the location of your operator controls? The Rexroth IndraControl V series always provides the right solution that is tailored to your specific automation application.
|
|
|
|
|
|
|
For additional information please contact sales@nematron.net. An enhanced version of the PowerView 6000/8000 Series brings higher performance and greater hardware expansion capabilities to Operator Interface Terminal applications. The extensive communication support for a wide range of popular PLCs and Servo Controllers will allow simultaneous connection of up to 16 different controllers along, with Peer-to-Peer and Global variables functions. A comprehensive range of hardware interfaces are offered as standard and extend application support for USB, Compact Flash, Hard Disk, Bar Code Scanner, Wireless and many other devices. Free downloadable ViewBuilder 8000 configuration software supports all standard HMI functions, and includes macro, math and logic capability for advanced operations. Included with ViewBuilder is a subset of the popular Symbol Factory 2.0 graphics library, containing over 2,000 graphical objects. ViewBuilder 8000 takes full advantage of the PV8000s high resolution display with a wealth of application development tools. Enhanced graphics capability provides support for BMP, JPG, and both static and dynamic GIF file formats. The advanced object libraries containing bar graphs, trend displays, list & dropdown menus, user configurable shapes and engineering icons facilitate fast mimic and screen development reducing project implementation time. Alarm management, historical and real time event & trend functions bring performance and functionality typical of larger scale SCADA Systems to the PV-8000 Operator Interface Terminal. Ethernet, OPC Server (optional), and Serial are amongst the extensive Communication options.
|
|
|
|
