The YC-300BZ3 DC inverter TIG welding power source has been developed on Panasonic digital technology. It is 100% digital controlled and offers high quality welding.
Technical Data:
100% full digital control high performance welding
• Exact output parameters
• Sharp and stable arc start as low as 4 amp.
• Welding Method:
1. DC TIG, DC pulse TIG for mild and stainless steel as well as titanium 0.3 – 6 mm, copper and brass 0.5 – 3 mm
2. DC TIG arc spot for mild and stainless steel with 2 x 2 mm thickness
3. DC stick for diameter 2 – 6 mm
• Duty cycle: 300A / 40%
• Weight: 36 kg
• Digital interface with Panasonic robots
• Arc drive function for stick welding
• Dimensions: 510 x 380 x 410 mm (L x W x H)
• 400 V AC, 3 phases, 50 / 60 Hz
Digital display, LCD, jog dial
• Digital display for both programmed parameter and actual welding parameter
• Easy and logical parameter setting by LCD and jog dial
Quality control
• 99 memory programs
• Digital connection with the PC / network for production
management and quality control
Customer Benefits:
• Sharp and stable arc start
• Reliable quality for low maintenance and service cost
• Easy parameter setting by jog dial
|
|
Panasonic presents the full digital AC/DC-TIG power source
YC-300BP2 which was invented for AC-, DC- and Mix- TIG welding. The BP2 can be used until an AC-frequency up to 400Hz.
The BP2 is easy to operate even if several assigned functions are selected and it has a well arranged control panel. Up to 50 different welding conditions can be stored and operated.
|
|
|
|
|
|
Genesis 503 PME
These are inverter power sources purposely designed for exceptional quality continuous wire welding (MIG/MAG, PULSED MIG) and electrode welding (MMA); TIG welding with contact ignition is also possible.
The control panel is easy to use and 52 different synergic curves are available to the operator for MIG/MAG and pulsed MIG welding of all the most common materials.
A duty cycle tested at 40° C ensures interruption free operation to 100% at 25° C.
performance in pulsed arc welding. They are ideal for use even with thin aluminium and stainless steel sheet, with which they give a weld quality similar to that achievable with TIG welding.
The WF104 separate wire feed unit weighs only 19 kg (without wire reel) and can be positioned above the power source on a pin, which permits 360° rotation, or at a distance near the work place by means of a connection cable bundle up to 10 m long; the microprocessor, the Encoder and a sturdy 4 roller gearmotor ensure maximum precision in welding wire delivery speed.
At switch-off, the last welding condition is stored, making it easier to re-start work after interruptions.
|
|
|
|
|
|
Pi 200 and Pi 250 are for quality welding operations in TIG AC/DC and MMA. You have never seen such a variety of readily accessible facilities for TIG weld-ing: increased programming, simple operation and user-friendly design, as well as inverter technology combined with innovative operation and communi-cation possibilities.
Mono-phase and three-phase
A high-performance mono-phase or three-phase Pi machine is always available and perfect for a wide range of TIG and MMA welding operations. Both the Pi 200 and the Pi 250 are available in three ersions, all of which have easy-to-use control panels:
Pi DC for MMA welding with simple TIG LIFTIG®.
Pi DC HP - TIG with pulse and Synergy Plus™ as standard features.
Three optional pulses:
Pi offers three optional pulse versions: traditional manual pulse, quick pulse, and Synergy Plus™ for DC welding which automatically adjusts all overarching pulse para-meters. Another advantage of Synergy Plus™ is that the traditional sound in pulse welding has been replac-ed by a sound that does not cause stress. Pi 200 HP and Pi 200 AC/DC, the two mono-phase machines, feature PFC (Power Factor Correction), a function that makes it possible to weld with up to 200 A if only 16 A mains fuses are available.
Controlled cleaning zone:
All Pi AC/DC machines - including the mono-phase version - are fitted with the D.O.C.® system,Miga-tronic's revolutionary dynamic oxide control. In
welding aluminium, D.O.C.® ensures a controlled cleaning zone along the weld, increases the welding speed by up to 30% and reduces the consumption of energy and tungsten electrodes correspondingly.
|
|
| ... products without technical information |
| |
Applications include:
-Automotive sheet metal and components
-High-speed bi-metal contact welding
-Storage Batteries
-Aircraft components (aluminum and titanium)
-Nut resistance spot welding
-Projection welds
-Motor armature fusing
-Markless welding
The ISA range of Inverter power supplies provides the highest level of control available today in large scale resistance spot welding. All models are intelligently packaged in “NEMA” style enclosures and are designed to deliver robust performance in the harshest of production environments.
|
|
|
|
|
|
Miyachi Europe offers the high end welding system AWS3 with ISQ 20-10K especially for automotive, tooling and electric/electronic industry requiring high end interfacing and high speed automation. The new product expands the weld current range up to 10kA.
Applications:
Automotive: Lead frame welds, connectors, compacting, pumps, motors, coils
Tooling: Burrs, saw blades large
Electric/Electronic: Components (e.g. capacitors, resistors), fuses, motor switches, relays, contacts, electrical motor fusing, magnet wire welding
Technical Specifications:
max current weld head with short secondary cables 2 x 400mm², length 500mm measured = 10kA
Benefits:
+ Compact design like ISQ20-6
+ High duty cycle
+ High output power (250A)
+ External transformer water cooled
+ Interfacing identical to ISQ20-6
+ Full AWS3 functionality
Dimensions (mm):
Inverter: 216 x 420 x 480 (W x D x H)
Transformer: 284 x 110 x 170 (W x D x H)
Weight (in kg): Inverter: 20kg; Transformer: 16kg
Power requirements: 3 x 400VAC, 50/60 Hz, 20kVA
Legal Approvals: CE compliant
|
|
Inverter Power Supply - IS 120
Inverter Power Unit
Controlled DC Inverter for a wide range of applications - Compact device with terminal and remote transformer
Features
External programming panel
Connection to all mian voltages
Indication of all actual values
Status and error detection in clear text
Applications
Well-suited for automation
Maximum quality requirements
Safety critical environment
Materials with very poor welding properties
Use
Economical and efficient operation
Stable processing and high reproducibility
High grade of weld
Integrated process monitoring
Optimum quality documentation
|
|
Inverter type power supply for spot welding (resistance)
Average rate 1000 - 2000 Hz
18 to 72 KA standard - Parallel to strong currents
QUALITY - PERFORMANCE
- Provision of energy very quickly
- Time welding reduced
- Low projection area
- High quality welding
- Increased speed welding
- Ideally suited for hard coating materials
- Welding of non-ferrous materials (aluminum - copper - brass - etc ...)
- High reproductibility of welding points
- Loop and exhibit no influence on the welding
- Ease of integration transformer welding weight and small size (board)
ECONOMY
- Performance (70%)
- Reduction of energy consumption
- Reduced infrastructure costs
- Need cooling reduced
- Low wear electrodes
CONTROLLER FOR THE RESISTANCE WELDING
|
|
|
|
