Labeljet 210 Label Applicator
TheLabeljet 210 is a modern, microprocessor controlled, industrial label applicator. The integral stepper motor drives the label web at up to 98.4 feet per minute (30 m/min.). A shaft encoder input (for speed compensation) is standard, and optional application methods include tamp and blow modules
- Fast, accurate and simple operation
- Low maintenance
- High speed
- Stepper motor with microprocessor control
- Storage of multiple production settings
- Airjet, non-contact application
- Touch and tamp modules with various strokes
|
|
ALritma is a high performance self-adhesive label applicator designed to be integrated into packaging lines where production speed and reliability are primary needs. ALritma labellers are based on an innovative mechanical structure which can match great sturdiness with versatility.
It is available in three versions, S, M and L, for label widths up to 100, 200 and 300 mm. respectively. The label driving group has been designed to exploit the stepper motor features to the full, by guaranteeing an accurate label positioning even at the highest production speeds; the side access has made the web threading easier.
The applicator is controlled by a powerful microprocessor equipped with a Touch-Screen display visualising all the most frequently used parameters at once by means of function keys, which allow for the running of advanced functions by relieving the operator from complicated mechanical adjustments and considerably speeding up the format changeovers.
|
|
Dimensions: Height: 30.41" (772.5 mm), Length: 33.44" (849.3 mm), Width: 22.84" (580 mm)
Weight: 145 lbs. (65.7 kg)
Standard Label Dimensions: Max. Web Width: 7.13" (181 mm), Min. Web Width: .63" (16 mm), Min. Label Length: .5" (13 mm)
Label Packaging: 12" (305 mm) O.D. rolls std. on 3" (76 mm) I.D. cores, Up to 16" (406 mm) rolls with powered rewind
Dispense Speed: Up to 1,500" (3,810 cm) of web per minute (standard), up to 2,000" (5,080 cm) of web per minute with smart powered rewind
Label Dispense Accuracy: Up to +/- 1/64" (.4 mm)
Electrical: 115 Volts AC 60 Hz 3 Amps., 220 Volts AC 50 Hz optional
Air (as needed): 2 cfm at 60 psi to 90 psi when imprinter is used
Options: Smart 20" (508 mm) powered unwind and powered rewind, 6" (152 mm) label core adapter, Encoder kit for Automatic Speed Following, Strobe signals for "low label" and "out of labels", Clear label sensor upgrade, Hot stamp imprinter, Display tilt mounting brackets, Model 2700 T-Base stand
|
|
|
|
|
|
Sharp appearance and power under the hood
The TTX 67x doesn’t just look good. Even though its style makes it an asset to any location, what’s under the hood is power and performance pure. Fonts or logos, labels, badges or foils – the TTX 67x delivers excellent results every time. The crisp resolution of 12 dots per mm guarantees excellent legibility for bar codes and clean, sharp lines in graphics, even at an output speed of 300 mm/s.
From the stylish, powder-coated housing to the precise mechanics, the TTX 67x is a robust performer through and through - which creates the ideal basis for a long service life and reliability under the toughest industrial conditions. The machine also earns top marks on the ecology front: it’s designed to be recyclable at the end of its long life.
Another great feature is the variety of media that the TTX 76x can print, including cardboard, self-adhesive labels and plastics. So you can produce prints for just about any application: from shipping labels, price labels and even fanfold labels. A broad choice of fonts gives you utmost flexibility in your designs. Wherever it performs, the TTX 67x always makes an excellent impression.
|
|
Perfect impression for your product
Clothes make the man, the image sells products, quality tags enhance sales appeal in retailing. They not only provide the customer with information, they also create an identity and vouch for brand quality.
In order to give your product brands the competitive edge, you can have decorative labels and blister cards professionally made, with specified areas left blank. You can then add variable product data such as size, material, quantity etc. - with Avery Dennison.
|
|
The ID Technology Model 150 is an economical, fixed speed applicator; it is a rugged industrial-duty applicator that accurately (+/- 1/16") applies pressure sensitive labels at rates of 100-250/ppm, depending on label size. The synchronous drive of the Model 150 provides low maintenance, dependability and durability.
The ID Technology Model ST1000 is a full featured label applicator with variable speed motor that achieves speeds up to 1,000 inches of label web per minute. Like other ID Technology engineered equipment, the Model ST1000 has a modular, simple, user friendly design that sets this applicator above the competition.
|
|
Q60 WIPE-ON APPLICATOR
- Capable of dispensing speeds up to 1200" per minute; optional 2200" per minute with +/-1/32" applied accuracy
- Remote electronics
- Stepper driven label feed
- May be used as a stand-alone unit or integrated into Quadrel's rotary systems, pharmaceutical systems and the popular Versaline labeling system
|
|
|
|
|
|
Features
Standard machine
- ICA SET4 can be installed in any industrial context, it is versatile and ideal for most applications of labels on any side of the product (even fragile), be it still or in motion and of variable sizes.
- Housing for rolls of 200 mm length and 76 mm internal diameter.
- Powered unit for re-winding of silicon paper with standard spindle.
- Linear pneumatic rollers with standard working stroke up to 300 mm.
Industrial PC
- ICA SET4 is controlled by a local or remote PC and can be connected to all standard interfaces. Possibility of Ethernet connection to various controlled units.
- The use of an industrial PC on machine board can be envisaged to control all the machine functions, equipped with dustproof 15" coloured touch-screen display.
DAT RF
- ICA SET4 for the connection to the remote manager PC can be equipped with Incas
DatRF terminal: terminal for the radio frequency collection and management of data, equipped with alphanumeric back-lighted display and membrane keyboard. IP65 protection level.
Labels 4"
Min. label sizes 50x50 mm
Max. label sizes 110x160 mm
Printing area 104x156 mm
Possibility to have customised labels with the customer's logo and barcode,
Possibility to rotate the printing direction: 0°, 90°,180°, 270°.
Printing quality: 8 dot. Application speed up to 20 labels/min. (format 100x100 mm).
|
|
|
|
|
|
ICATECH
Print-apply systems
Features
Standard machine
• ICATECH can be installed in any industrial context, even if demanding, it is versatile and ideal for most applications of labels on any side of the product (even fragile), being the package still or in motion and of variable sizes.
• Housing for rolls of 200 mm length 280 mm, complete of tensioner, and internal diameter of 45 or 75 mm.
• Powered unit for re-winding of silicon paper with standard spindle.
• Linear pneumatic rollers with standard working stroke up to 400 mm (higher upon request).
• Label front application or label side application through articulated arm, perpendicular to the working direction.
Industrial PC
• ICA TECH is controlled by a local or remote PC and can be connected to all standard interfaces. Possibility of Ethernet connection to various controlled units.
• The use of an industrial PC on machine board can be envisaged to control all the machine functions, equipped with dustproof 15” coloured touch-screen display.
Dual action option
• The use of articulated arm and head enables the application of two labels (up to A5 format) on two adjacent sides of the package/pallet.
Labels
4” 6”
Min. label sizes 16x13 mm 51x13 mm
Max. label sizes 114x250 mm 183x250 mm
Printing area 104x240 mm 168x240 mm
Possibility to have customised labels with the customer’s logo and barcode,
Possibility to rotate the printing direction: 0°, 90°,180°, 270°.
Printing quality: 8 dot. Application speed up to 60 labels/min. (format 100x100 mm).
|
|
|
The QuickWrap is ideal for small and mid-sized production environments where a fully automated line doesn’t make sense, this semi-automatic label applicator helps operators apply labels faster and more accurately, increasing productivity and order fulfillment.
|
|
Weber's new Alpha V40 label applicator provides fast, dependable labeling for a diverse range of applications. This versatile system employs the wipe-on or tamp-blow method to apply pressure-sensitive labels in line at high speed.
The Alpha V40 automatically peels labels from the liner, then gently but firmly affixes them to products or packages as they pass by on a conveyor line or other handling system.
The wipe-on unit applies labels up to 4.72" wide and 19.7" long (98? long optional) at speeds up to 210 feet per minute, while the tamp-blow model handles labels up to the same width and 6.3" long. Both systems apply labels to an accuracy of ±0.04".
The system can be configured to label the sides, tops or bottoms of products. For added application utility, it is available in both right- and left-hand versions.
|
|
Comet Applicator
The Harland range of ps-label applicators has been designed and manufactured to rigorous quality standards to ensure optimum compatibility and conformity. With a record of trouble-free installation world-wide, they can handle applications from price marking and promotional labelling to highly decorative branding, at varying speeds and different configurations.
They can be supplied as stand-alone units, integrated into existing production lines or as a fully automated system with suitable product handling, conveying and finishing units.
Features
- Robust
- Simple to operate
- Micro-processor control
- Quick release waste removal system
- Product memory capacity of 100
- Stepper motor drive
- Centre line labelling
- Security code protection to prevent unauthorised use
- Accuracy + 0.5mm beak edge
- 400mm O.D. reels
|
|
The MR inline labellers can be mounted to your existing packaging machine or transport system. Various mounting possibilities ensure fast and easy integration depending on the required task
Applications:
- Top and bottom labelling
- Labelling onto the side
- Corner-wrap labelling
- Wrap-around labelling
Your benefit:
- Easy and flexible integration into existing production or packaging lines
|
|
The CHARLIE basic configuration is provided with the following modules:
- Labeling head - LS or HS model. Provided with a label unwinding roller and a backing paper collecting roller.
- Smoothing brush for smoothing labels on flat or squared bottles.
- Control panel with start, test and speed controls.
Labeling head for round and flat bottles.
The “Basic” configuration is provided with a simple labeling head equipped with an adjustable stand in aluminum .
Ideal for:
- Label application on round and flat bottles in an already-existing equipment
- The automation of the labeling system guaranteeing precision and reliability yet keeping costs low.
Available in two modules:
LS: low speed - up to 4000 BPH
HS: high speed - up to 10000 BPH
Technical features:
Internal diameter: min. 42mm; max. 80mm
External diameter: min. 42mm; max. 300mm (LS); max. 400mm (HS)
|
|
HERMA 400 Fix – compact label dispenser
The strong motor, the standard reel holder and the robust built make HERMA 400 Fix a perfect compact dispenser for manual labelling. Easily expandable with a direct product jig and a hot-foil printer. This user-friendly, low-maintenance, wide-spread solution is proven even under industrial conditions.
The HERMA 400 Fix utilises the same servo drive and integrated operator display as our state of the art "standard" HERMA 400 applicator range.
|
|
Label-Aire is proud to introduce the newest addition to its line of advanced pressure-sensitive label applicators. The NEW Label-Aire® Model 3111 HS represents the pinnacle in advanced high speed air-blow pressure-sensitive labeling technology.
The Label-Aire 3111 HS "High Speed" label applicator can apply labels accurately up to a blistering 1,000 labels per minute. The 3111 HS utilizes Label-Aire's innovative Air-Blow technology which retains the label by vacuum on a honeycomb applicator grid. At the precise moment the product passes under the grid, the label is blown onto the product. Peel tip sensing ensures repeatable label placement accuracy. The 3111 HS also features a DC Servo which allows the unit to handle up to 5,000" (12,700 cm) of web per minute at peak velocity.
Label-Aire's 3111 HS offers added versatility in that it can be mounted in almost any position adjacent to the production line to apply labels to the tops, sides, or bottoms of products.
|
|
ALcode - Print & Apply labeling systems - are systems for the printing/application of self-adhesive labels. They may be interfaced with a computer and can apply the just-printed label to both still and moving products.
For label printing, ALcode can integrate the various thermal transfer engines made from the Japanese SATO (or compatible). Which has specifically developed them for the use on automatic applicators: resolution of 8 or 12 dots/mm., up to 300 mm/sec. of print speed, 4 ", 5 " or 6 " of printable width.
In every ALcode print apply system, the mechanics, pneumatics and electronics have been suitably integrated to meet the typical requirements of machines operating in an industrial environment, which need to combine reliability, user-friendliness, accessibility, and interchange ability.
A range of standard devices has been engineered for the application of labels, thus enabling ALcode to apply labels in any position and at any linear speed
|
|
|
|
|
|
With the UDA 150-S from KBA-Metronic it is possible to separate, label, check and, if needed, to even select folding boxes of very different sizes on a complex system outside of the production line.
Just like a modular system, you can combine different labeling technologies and camera systems with the UDA-150S. Depending on the customer’s requirement, the inkjet, laser, hot-stamping module and/or thermal transfer printer can easily be integrated.
Fine-adjustable photo lenses scan the folding boxes in order to obtain the exact position for the marking. The reliable coding systems from KBA-Metronic for the printing of EAN or data matrix code, expiry date, batch number etc. on the folding boxes as well as the use of track & trace systems for product safety and traceability offer miscellaneous possibilities to meet the quality requirements on safe packaging.
The UDA 150-S already processes small and medium runs with material sizes from 30x60 mm to 300x400 mm in a cost-efficient and flexible way.
|
|
Our complete line of printer applicators can print and apply labels at any angle using tamp, tamp-blow, or air-blow technology.
All models are designed for rugged use and virtually maintenance-free operation and of course, are compatible with all O.E.M. print engines.
|
|
APL 7000 L/R ; for labelling one side of the pallet or secondary packaging.
Label print & apply system especially designed for labelling one label per application cycle, having the possibility to use a big size label (150x210mm) for secondary packaging at average linear speed. For upper side, side and bottom applications (APL 7000L model) and for front applications with a rotating actuator (APL 7000R model). Fits a print & apply system which fits a 4" or 6" printing motor with the best units in the market: DATAMAX, SATO or ZEBRA. High resolution of 203DPI or 300DPI.
It's always necessary to stop the product to apply the label.
|
|
The Videojet P3400 label printer applicator is easy to use and maintain, and features the versatility of modular spares to deliver maximum uptime and performance. Available with multiple printer options and a variety of application choices, the Videojet P3400 provides a customizable, off the shelf solution.
- Simple, modular design
- RFID Enabled
- High quality thermal transfer printing
- Built to last in the most rugged industrial environments
- User configured beacon and status output
- Multiple label configuration menu
- Flight time compensation for automatic label placement control
- Ethernet connectivity for set-up and control
|
|
A new generation of quality and performance for label print/apply systems.
For the best of the best in label printer/applicators, Diagraph is proud to introduce the Platinum Series. Engineered for high-performance, high-speed, 24/7 operation in the most demanding conditions.
|
|
APL 4000 B; especially designed for labelling secondary packaging without contact.
The labelling is done by air blow and ejecting the label. It integrates these printing engines: DATAMAX, SATO or ZEBRA. For high volume label applications, it allows the user to simultaneously encode data and printed information on an intelligent label with a RFID chip, in accordance with the EPCglobal specifications.
|
|
APL 4000 L; automatic label print & apply system especially designed for labelling secondary packaging at average linear speed.
It integrates these printing engines: DATAMAX, SATO or ZEBRA. For high volume label applications, it allows the user to simultaneously encode data and printed information on an intelligent label with a RFID chip, in accordance with the EPCglobal specifications.
|
|
APL 4000 R; it is designed to apply labels at the front or the back side of packaging.
The system integrates these printing engines: DATAMAX, SATO or ZEBRA. For high volume label applications, it allows the user to simultaneously encode data and printed information on an intelligent label with a RFID chip, in accordance with the EPC global specifications.
|
|
APL 8000 Series; Self-adhesive labels real time print & apply system for pallets 1, 2 or 3 sides labelling of a pallet.
Designed and manufactured in accordance with the traceability standards for the entire delivery and distribution chain. It complies with the GS1-128 standards as well, as well as with the GS1 International pallet labelling recommendations. A print & apply system which allows the integration of a 6" printing engine with the best print engine units in the market: DATAMAX, SATO or ZEBRA. High resolution of 203DPI or 300DPI.
|
|
APL 4000 C; it is designed to apply labels in corners on secondary packaging, labelling two adjacent sides with one label.
The system contains a soft foam brush or cylinder, used to perfectly apply the label in a 90º angle. It integrates these printing engines: DATAMAX, SATO or ZEBRA. For high volume label applications, it allows the user to simultaneously encode data and printed information on an intelligent label with a RFID chip, in accordance with the EPC global specifications.
|
|
|
|
|
|
The Label-Aire Model 3138-N RFID Printer Applicator brings RFID technology to your print and apply operation and keeps you ahead of your competition.
The Model 3138-N RFID Printer Applicator delivers on its promise of accuracy, reliability, and ease of use. That translates into lower operating costs and increased productivity for your business.
The 3138-N RFID comes standard with such Label-Aire virtues as easier setup, troubleshooting, and change-over, and more reliable operation while allowing you to easily encode RFID tags.
The 3138-N RFID is based on Label-Aire's most advanced printer applicator, the 3138-N. The 3138-N RFID’s advanced features include automatic setup with multiple programmable label pages for easy change-overs to labels of different sizes, rate compensation for improved label placement accuracy, and advanced user-configurable I/O connectivity. All these handy features greatly simplify setup and change-overs. This unit's advanced RFID features include EPC, Class 0, Class 0+, Class 1, Gen 2 RFID tag encoding, fully integrated UHF/EPC print-and-apply technology, user friendly Label-Aire RFID tag formatting software, and an innovative Tag Rejecter mechanism. Like all Label-Aire printer applicators, the 3138-N RFID is compatible with any O.E.M. RFID printer on the market.
Put this most advanced RFID printer applicator to work for your company all day, every day. The Model 3138-N RFID Printer Applicator is built to meticulous quality standards and designed to withstand the most intense operation.
|
|
APL 4000 D; system for the identification and double labelling of secondary packaging.
It also offers the possibility to apply and print two adjacent labels on the upper part and/or the side, vertically as well as horizontally. It integrates these printing engines: DATAMAX, SATO or ZEBRA. For high volume label applications, it allows the user to simultaneously encode data and printed information on an intelligent label with a RFID chip, in accordance with the EPCglobal specifications.
|
|
|
|
|
|
* Ij3000 XLS Controller :
The Ij3000 XLS Controller was designed and built to meet any demanding coding application. Diagraph has engineered the XLS Controller to exceed performance expectations. The XLS Controller seamlessly integrates Impulse Jet and Integrated Valve technology offering a networking function that delivers reliable, high quality printing to any automated production enviroment.
* Ij3000 ES Controller :
The Ij3000 ES Controller is a powerful, low-cost web-server based HMI features a color touchscreen display, drives Diagraph’s Integrated Valve or Impulse Jet printheads, and has a 100-base T Ethernet network port for web browser, network connectivity. Diagraph has created special package “Ij3000 ES kits” for dual head Integrated Valve 9 or 18 dot printhead applications and has special introductory offer. Interested parties should call 800-722-1125 for details.
* NEW! IV-18 Dot Printhead for IJ3000 Ink Jet System
Diagraph is pleased to introduce the IV18-Dot Printhead for the Ij3000 Integrated Valve Large Character Ink Jet System. Key Standard Features Include: Two-piece, die-cast aluminum housing, environmentally sealed printhead for harsh environments, robust metal housing over entire printhead, built-in LED display and membrane switch for: -->channel purge (one or all channels) -->electronic pulse width (dot size) adjustment -->pressure gauge, automatic first dot correction, overdrive protection, photocell mounting bracket holes, backwards compatibility with existing Ij3000 and Series 1 printheads. The IV-18 Dot Printhead is driven by Diagraph’s Ij3000 Ink Jet Printing System.
|
|
|
|
