All Laser Mech cutting heads come with the following features and benefits:
* Magnetic Crash Protection – Eliminates breakaway screws and reduces downtime after a crash to a few minutes
* Easy-Access Lens Drawer(s) – Makes lens replacement, cleaning, and beam centering quick and easy
* Manual Focus Adjustment – Over ¾ of an inch of focus adjustment reduces setup time
* Fixed Tip Assembly – Never have to center the tip again
STATIC SENSOR HEADS FURTHER UPGRADABLE TO NON-CONTACT
The addition of Laser Mechanisms' Height Sensing Unit (HSU) will allow you to remove the foot follower (as needed) and will enable your laser to cut sheet metal non-contact. Here are just some of the benefits:
* Fully integrates with the Mazak controls (L32, L-Plus and L32B)
* Switch between non-contact and contact cutting in minutes
* Reduces the footprint allowing for tighter nesting of parts – reducing scrap considerably
* Non-Contact cutting does not scratch the workpiece
|
|
All Laser Mech cutting heads come with the following features and benefits:
* Magnetic Crash Protection – Eliminates breakaway screws and reduces downtime after a crash to a few minutes
* Easy-Access Lens Drawers – Makes lens replacement, cleaning, and beam centering quick and easy
* Manual Focus Adjustment – Over ¾ of an inch of focus adjustment reduces setup time considerably
* Fixed Tip Assembly – Never have to center the tip again
NON-CONTACT HEIGHT SENSING OPTION (For HC and HD Lasers)
The addition of Laser Mechanisms' Height Sensing Unit (HSU) will allow you to remove the foot follower (as needed) and will enable your laser to cut sheet metal non-contact. Here are just some of the benefits:
* Fully integrates with the Mitsubishi controls
* Switch between non-contact and contact cutting in minutes
* Reduces the footprint allowing for tighter nesting of parts – reducing scrap considerably
* Non-Contact cutting does not scratch the workpiece
|
|
|
|
|
|
Cutting System YRC
3D cutting with fibre optical coupled lasers
Applications:
o 3D cutting
o robot
o multiple linear drive laser equipment
o cutting of thin metal sheets
o cutting of metals
System types/Lasers:
o for all solid-state lasers like Nd:YAG, disc, fibre optical and diode lasers
Features:
o complete system consisting of linear drive, cutting system, controller and collimation unit
o integrated, non-contact, patented distance sensors
o error signals if collision or cable breakage occurs or if measuring area tolerances are exceeded
o symmetrical design
o easy access to all connections (top)
o integrated collision detection
o water cooling system for optical components and fibre sockets
o all water-conducting parts made of stainless steel
o integrated collimation unit
Technical Specifications:
o max. laser power: 4 kW
o electronics: Lasermatic® Z
o focal lengths focusing: 73 mm, 100 mm
o focal lengths collimation: 73 mm, 100 mm
o max. clear aperture: 26 mm
o axial lengths: 350 mm / 380 mm
o dimensions (W x H): 163 x 132 mm
o mass of complete system: about 5 kg
|
|
Our CL-830 laser which is modified slightly for use in the stone cutting industry with added lens protection and a robust power supply it is made to stand up to the rigors of stone cutting.
The CL-830-B comes with the CE-HPS-800 bar mount bracket for easy mounting and a power supply that will work with either 110V or 220V. For flat mounting situations you can use our standard CE-305 bracket.
|
|
The vast experience of El.En. in design and manufacturing of scanning heads equipped with galvanometric driven mirrors allow the realization of marking, cutting, welding and surface treatment systems with extremely high dynamic performances.
The offer of such systems covers from very high speed labeling and packaging systems to high resolution systems for very large working areas.
|
|
|
|
|
|
StarCut®
The new StarCut Generation stands for high quality and speed of cut in a compact form at attractive prices. The whole family is modular, and comprises technologically high-quality components.
The power supply with IGBT switches ensure pulse frequencies of up to 4000 Hz, and a unique pulse-to-pulse stability. The CAN-bus based controller guarantees safety and flexibility for all present and future applications. These include pulse increments of 10 µs, dynamic power control, and on-line trouble shooting.
The laser resonator, based on the proven StarMark rail concept provides high laser power with optimal brilliance of beam. Depending on the application, TEM00, TEM10, TEM20 or fiber-coupled, low-order-mode beam profiles are used. The fast shutter, with a switching time of less than 10 ms, permits holes to be cut in an economically attractive time.
In many areas, the StarCut series provides uniquely high qualities of cut. With approx. 200 installations in the areas of electronics, medical technology, and electromechanics, it has already set a standard for the industry.
|
|
Cutting Head HP1.5"
With integrated non-contact distance control
For high pressure cutting applications
Cartridge replacement system enables faster change of focal length
Preadjustable focusing optics
Water cooled connector head
All connections in the upper part
All water guiding parts are made of highly corrosion-resistant stainless steel
Error signals in case of collision, cable breakage and exceeding the measuring range
Focal lengths: 3.75", 5", 7.5", 10"
Lens diameter: 1.5"
Free aperture: 33 mm
Axial length (f = 5"): 236.4 mm
Max. cutting gas pressure: 25 bar, 365 psi
Nozzle standoff distance: recommended: 1.0 mm to 5.0 mm, possible: 0.3 mm to 10.0 mm
Measuring resolution: < 0.01 mm
Mass (f = 5"): 4.0 kg
|
|
Cutting head YR30
With integrated non-contact distance control
Electrically monitored breakaway
Small measuring spot
Preadjustable focusing optics
All water guiding parts are made of highly corrosion-rsistant stainless steel
Error signals in case of collision, cable breakage and exceeding the measuring range
Focal length: 73 mm
Lens diameter: 30 mm
Free aperture: 27 mm
Axial length: 120 mm
Max. cutting gas pressure: 20 bar, 290 psi
Nozzle standoff distance: recommended: 1.0 mm, possible: 0.3 mm to 10.0 mm
Measuring resolution: <0.01 mm
Mass : 1.1 kg
|
|
