Molykote® synthetic oils are produced
through chemical synthesis to meet
targeted performance specifications and
to minimize impurities. Synthetic oils
are formulated with new generation
performance-enhancing additives.
Molykote mineral oils are produced in
a series of proprietary hydroprocessing
steps, which ensures that they are nearly
free of contaminants. Synthetic blends are
comprised of synthetic and hydroprocessed
mineral oil base stocks.
All oils in this section are available in pails
and drums.
Molykote® gearbox lubricants help prevent wear and process interruptions in power transmission
systems and components. Compared to conventional oils they also offer greater resistance to
oxidation and stable performance at high temperatures and under high loads. Molykote gearbox oils
maximize fill intervals and maintain viscosity characteristics at wide temperature ranges. Molykote
gearbox oils meet AGMA 9005-E02. In addition to AGMA, Molykote L-21XX series gearbox oils also
meet DIN 51 517 Part 3, US Steel 224, Flender, Cincinnati Machine, David Brown SL.53.101.
|
|
SUPRACO MPL Gears, multipurpose. Enclosed gears and loaded circulating oil, wheel and worm reducers.
ISO Grades available : 100, 150, 220, 320.
GEAR SY
|
|
|
|
|
|
SKF bearing greases:
The perfect solution for every application
SKF's vast experience in the development of rolling bearings forms the basis for the development of a special range of lubricants, the superior quality of which is obtained through continuous testing and studies.
LGMT 2: SKF general purpose industrial and automotive bearing grease
LGMT 3: SKF general purpose industrial and automotive bearing grease
LGWA 2: SKF high load, extreme pressure, wide temperature range bearing grease
LGFP 2: SKF food compatible bearing grease
LGEP 2: SKF high load, extreme pressure (EP) bearing grease
LGEM 2: SKF High viscosity bearing grease with solid lubricants
LGEV 2: SKF Extremely high viscosity bearing grease with solid lubricants
LGLT 2: SKF low temperature, extremely high speed bearing grease
LGGB 2: SKF green biodegradable bearing grease
LGWM 1: SKF extreme pressure low temperature bearing grease
LGHB 2: SKF high load, high temperature, high viscosity bearing grease
LGHP 2: SKF high performance, high temperature bearing grease
LGET 2: SKF extreme temperature, extreme condition bearing grease
|
|
LGWM 2
High load, wide temperature bearing grease
SKF LGWM 2 has been developed for lubrication under a wide
temperature range, high loads and wet environments.
LGWM 2 is a synthetic-mineral oil based grease using the latest
complex calcium sulphonate thickener technology.
LGWM 2 is suitable for temperatures down to - 40 ºC.
- Excellent corrosion protection
- Excellent mechanical stability
- Excellent high load lubricating capacity
- Good false brinelling protection
- Good pumpability down to low temperatures
Typical applications:
- Wind turbines
- Heavy duty off road applications
- Snow exposed applications
- Marine applications
- Spherical roller thrust bearing applications
|
|
| ... products without technical information |
| |
The flexible high performance heavy duty electric grease pump solution.
DUAL PUMPING MODULE
400cm3 (2x200cm3) pump modules installed in tandem configuration provide 400bar (5880 psi) and redundancy .
This allows the system to continue working even if one pump module becomes ineffective.
Sumo pump is suitable for large single line or dual line systems.
INSTRUMENTATION MODULES
Sophisticated add on instrumentation modules and options means even complex requirements can be met with off-the-shelf standard product.
QUICK SWAP SYSTEM
Both pumping modules can be quickly replaced from the front mounting of the pump. No pipe work needs to be disrupted meaning near-zero downtime during maintenance.
DUAL LINE OR SINGLE LINE IS EASY
The outlet plate fixing system has both Pressure and Return ports.
The outlets are directly compatible with Dropsa's electrical or pneumatic line inverters (including Modular version).
|
|
The Lubeplus GX is ideally suited to mechanical applications and plant used in the food processing, packaging and printing industries. Can accommodate systems with up to 200 lubrication points.
Lubeplus GX is designed to operate with Positive Dsplacement Units (PDU) or with Metering Flow units . The lubricator is available with a wide combination of condition monitoring features and a choice of 'with' or 'without' microprocessor control.
Gear Pump operation
Max. operating pressure 25 bar
Can pump Oil or fluid grease
Available in 3 or 6 litre reservoirs.
Supply voltages 110v or 240
|
|
The Electric barrel pump ready to be used on Progressive and Dual Line Lubrication systems.
The CannonPump has been designed to meet the requirement of designers that require a traditional barrel pump approach to system design when no compressed air is available.
|
|
|
|
|
|
BRAVO: THE SMALL PUMP PACKAGE WITH BIG FEATURES
This small pump package contains many innovative features exclusive to DropsA allowing fresh possibilities in lubrication systems engineering.
It is suited for not only for indoor industrial applications but also mobile plant and vehicle lubrication systems.
VARIO-DRIVE: THE INNOVATIVE SYSTEM
VARIO-Drive is a new power management system for the pump motor that protects and adjusts the pumping system electronically. That means increased reliability and greater lifespan of the pump motor as well as the ability to electronically adjust the pump output from 50% to 100% of its nominal value.
You will find that you are able to precisely control and engineer systems like never before.
NEW GENERATION CONTROLLER
The integrated next generation control system is a central to delivering these new solutions to the customer.
It allows five different ways to trigger and control the lubrication event in a system:
1. Time based interval: 0 min - 99 hours
2. Impulse Counter: 1 - 9999 cycles
3. Combined Trigger: both Timer and impulse counter
4. Impulse Driven: uses impulse input to determine both standby and operation mode (0-9999 impulses)
5. Remote Only: Acts as Slave to host machine.
|
|
Professional Two Speed 14.4-Volt Cordless Grease Gun
Lincoln’s new, heavy-duty 14.4-Volt PowerLuber gives you the power to lubricate just about anything, anytime, anywhere. It features a two-speed switch for high-pressure or high-volume delivery and a cycle indicator pin to monitor grease output. A “Smart” charging system delivers reliable power while its ergonomic grip and balanced design provide optimal user control and comfort. Other features include a hook for a shoulder strap, a built-in hose and coupler holder, and a slim, compact carrying case.
|
|
ain areas of application are for mechanical engineering applications with demanding requirements for a defined lubrication: Ensuring a high degree of efficiency with minimal wear and long life, particularly in relation to tool spindles.
How it works: A flow of air inside a narrow tube teases a droplet of oil apart to form streaks that are then transported to the lubrication point. A nozzle continually supplies the bearing with oil in the form of fine droplets. The transporting air stream is practically oil-free upon leaving the bearing.
|
|
Ideally suited for plant in continuous operation: Steel Works, Cement Works, Rolling Mills, Large Cranes and Sewage Processing.
Designed for heavy duty performance and reliability, these multi-line radials are equipped with integral pumping units which deliver an adjustable volume of lubricant to each bearing feed line.
A maximum of 30 outlets is provided. Additional points may be covered by distribution blocks.
Radial Systems
MR/AF Range
Lubricants incl. Grade 2 grease
Ideal for larger installations such as steel works, fixed plant and coal mines
|
|
|
|
|
|
Battery Driven Grease gun LAGG 400B
Quick and easy grease filling
The SKF Battery driven grease gun LAGG 400B is a high quality grease gun suitable for lubricating bearings, machines, vehicles and other applications. Ergonomically designed and user friendly, the grease gun can be used with standard SKF grease cartridges (420 ml) or filled with approximately 500 cm3 (17 US.fl.oz) of loose grease.
Compared to hand operated grease guns, a 420 ml cartridge can be emptied in approx 10 minutes with minimum effort, resulting in significant cost and time saving
-Electrical operation and the ergonomic design of hand grip helps reduce operator fatigue compared to manual methods
-Easy-to-use one hand operation makes the grease gun user friendly
-Supplied with various electrical plugs and two power supply versions (230 and 110 V charger) makes it operational worldwide
-Battery operation allows use in almost all environments without use of a mains supply
-Long battery life of 1000 charging cycles helps reduce product life costs
-Refillable: grease filling nipple and de-airing valve allow filling up by filler or grease pump
-Safety valve setting set to 40 MPa (5 800 psi) helps increase operator safety
-Supplied with M10x1 nozzle, interchangeable with SKF hoses, SKF grease meter LAGM 1000E and other accessories
|
|
In-Line Lubricator :
In-Line Lubricators assure proper lubrication for small pneumatic hand tools. These in-line lubricators put the oil source right at the tool. Oil capacity is 1/4 oz. (1 ml) enough to last through an average 8-hour shift. This lubricator requires cyclical or intermittent airflow for proper operation, and consequently works best when installed at the tool inlet or on a short hose near the tool.
|
|
| ... products without technical information |
| |
| ... products without technical information |
| |
Air Line Lubricator
Sizes Available: Miniature Series 1/8", 1/4" NPT, Compact Series 1/4", 3/8", 1/2" NPT, Large Series 1", 1-1/2" NPT
Air line mist lubricator distributes oil into the compressed air line, significantly increasing the life of downstream equipment such as valves and actuators.
Bowl available in transparent polycarbonate or metal zinc die cast.
Bowl capacity: Miniature: 17cc, Compact: 160 cc, Large: 1 litre
|
|
The 09L Hi-Flow Mist Air Lubricator is designed to provide lubrication for most general applications in a pneumatic system. Units should be installed close to the application ensuring effective distribution of oil to pneumatic components.
FEATURES:
Metal Bowl With Sight Gauge & Manual Drain - Standard
Proportional Oil Delivery Over a Wide Range of Air Flows
Bowl Can Be Filled While Air Line is Under Pressure
Transparent Sight Dome for 360° Visibility
|
|
