Marking area (x/y) 80 x 50 mm
Option sprint enables shorter marking times. Aprox. 2 - 3 seconds for 10 characters in 3 - 4 mm character heights
Expansion of the central unit with a sprint drawer
Fully prepared and ready to be integrated marking system
Easy integration in production and assembly lines
Infinitely adjustment of the different marking strengths
Works in all positions
Highest marking repeat accuracy by high value linear guidance in connection with ball bearing screws
Particular suitable for data matrix marking
Maintenance free mechanics and tools
Protective covering against smut
|
|
General description
Application: Marking control icons on high-end appliance tops
Features:
- 50-watt diode-pumped Nd:YAG laser
- 16-bit high precision galvanometers
- 10"x10" marking field
- Programmable linear laser motion
- Part length sensors for four discrete appliance families
- Manually adjustable Z-axis laser motion with digital position display
|
|
|
|
|
|
This product line, which provides a permanent, distinctive mark is ideal for promoting by brand recognition, date and batch codes, traceability, inspection and instructional marking. Matthews Airgrit Etching technology is a stress-free marking process that does not distort or fracture the shape of delicate or thin-walled parts.
Operating on a forced-blast principle, the Airgrit provides a permanently frosted or etched impression on the surface of flat or round parts by blowing fine abrasive grit through the relieved portion of a rubber mask. The result is a high-quality, frosted impression that contrasts with the product's surface. Click here to read more about masks.
Airgrit systems can economically and permanently mark glass, metal, ceramics, plastics and other fragile materials with hard, anodized or highly polished surfaces. This product group is an excellent choice for applications in the automotive, glass, and plastics industries. Several models are available for all process line configurations including bench top, floor and hand-held systems along with many options and accessories.
|
|
* Monode Electric Etcher - ME600 :
Marks all metals. Writes like a pencil. Speed of writing and the depth of mark can be varied by three wattage settings. Ideal for all tool cribs.
*Monode Stain Removing Kit :
Removes the burn marks from welding joints.
* Model 450 Digital Etching Unit :
Corrosion Proof Touch Pad, Programmable Etch Cycles, Operator Friendly Set-Ups, Lock out Features, One Year Warranty.
* Model 550 Digital Etching Unit :
Corrosion Proof Touch Pad, Programmable Etch Cycles, Operator Friendly Set-Ups, Lock out Features, Good for Deep Etch, One Year Warranty.
|
|
Electrolytic marking systems
You can find basic information about the function principle of electrolytic marking in the main menu at "Marking procedures".
Electrolytic marking is primarily distinguished by the fact that high-quality markings can be created very quickly - and that at an attractive cost level.
The STLING product programme principally has a modular structure. This means that most of our devices can be upgraded as required later on.
Thus, for example, a manual workplace consisting of an EU Classic can very easily be expanded to a semi-automatic system. Fully automatic solutions can also be realised on request.
|
|
General description
With over 20 years experience in laser marking, CMS is your best choice for fully integrated 4th generation PCB (Printed Circuit Board) laser marking systems.
All of our systems utilize high speed galvo steered lasers to mark any combination of:
- IDM Square matrix codes
- Rectangular matrix codes
- ECC 200 2D matrix codes
- UPS, 2 of 5, 3 of 9, 128 and EAN linear barcodes
- OCR Machine-Readable Text
- Alphanumeric Text with various fonts
- Graphics and logos
Our systems can be stand alone or can be integrated into your already automated production line. Systems can be designed to use automatic stackers, flippers, or any other kind of part handling system. See the PCB Marking system detail page for more features!
|
|
Function
The unit consists of a servo driven X/Y axle, a rotating application head and a conveyor with positioning mechanism to pick up and place the PCBs. The PCB is transferred by the conveyor into the application area. The X/Y axle moves the application head to the printer, a label is taken and then applied to the PCB. After the application process the PCB is released and then transferred to the following unit.
Special features
- PC controlled unit
- User guidance
- Print control possible after printing or after application
- High performance servo drive
- Rotating applicator head
- Printer slides out for easy maintenance
- Barcodes and data-matrix labels
- Programmable Z-axis
- 2 Thermal transfer printers
- ASYS label software for creating labels
|
|
General description:
The models 3000 / S / DPS-3000 Plus of the wafer marking system IL 3000 are designed to mark 300 mm wafers.
Different laser types and setups (solid-state laser, CO2 laser, UV laser etc.) are available to yield optimum process results for different wafer materials such as Si, GaAs, Ge, GaP, InP, Sapphire, Quartz and others.
The IL 2000 provides "Deep" marking (marking depth up to 100m) as well as "debris-free" marking (0,3 - 6m). A powerful software package, developed in cooperation with many customers over the past 10 years, offers immediate operating solutions for most customer applications.
The basic system has two vacuum end effectors and a vacuum aligner. An enhanced "Edge-Grip" handling system is offerd as an option.
The model 3000 Plus offers the possibility to mark the frontside and the backside of a 300 mm wafer simultaneously in a single process step.
|
|
PINSTAMP Systems are based on our original, "Floating Pin" Technology, which was developed and patented by TELESIS in 1985. This unique process, along with our broad product line and emphasis on excellent, 24 Hour Customer Service are what sets TELESIS apart from other pin marker manufacturers.
PINSTAMP Marking Systems have a well-deserved reputation for reliability. They provide high quality, state-of-the art marking technology in many varied manufacturing settings - from industrial equipment, automotive and aerospace applications to sporting goods and medical devices.
|
|
Precise, accurate and easy to use, the MULTI4 Bench is ideal for marking parts in a fixed position.
Marking layouts or files can be created and marked in seconds. With the standard marking functions provided, marking errors are greatly reduced or eliminated.
The Bench model is an ideal system for marking simple or complex components in batches or longer runs.
The marking is clean, nice looking and permanent.
|
|
Reliable, flexible and compact, the MULTI4 I can be easily integrated into semi automated or fully automated production lines.
The marking system is operated by an external control unit with RS-232 or optional Ethernet communications and I/O control for setting inputs and outputs from external equipment.
The Integrator model can mark several characters per second making it a perfect choice for production marking.
To ensure reliability, only high quality components are used in the MULTI4 construction.
|
|
TeleScribe Marking Systems
The SC3500/420 and SC5000/420 are the right choice when deep, low noise marking is required. Especially well-suited for VIN (Vehicle Identification Number) Marking applications. Marking windows available: 4" x 6" (100 x 150mm) or 2" x 7" (63.5 x 190.5mm)
TeleScribe Product Line
SC3500/420
SC5000/420
SS5500
|
|
|
|
|
|
The computer-controlled tag feed marking system is a totally automated system for marking tags up to 150 mm in length on the standard units. Customized machines can be ordered for extremely large tags.
The tag feeder is equipped with an adjustable loading rack, which can be quickly readjusted for a wide range of tag sizes. Standard machine size is 15 mm to 75 mm for width and 20 mm to 105 mm for length.
The MC-2000 plate feed system is equipped to mark in both manual and automatic modes. The manual mode gives you the ability to perform any one of the tag system functions through a series of push buttons located on the front of the machine. By simply moving the selector switch to the manual mode you can now move the pusher bar forward to check for clearance in the systems rails or mark a single tag to check mark location and quality of mark.
The MC-2000 tag feeder is also equipped with warning signals in case of a system jam or if the machine runs out of tags. The control box can also be programmed to mark a specified number of tags or mark until the stacker is empty.
All of the same characteristics that are found in the standard MC-2000 control box are included in the tag feed system.
General Specifications:
Electrically driven pusher
Adjustable push bar
Two- (2) tag feed bars for different size tags
Four inch high stacker
One (1) tag weight with handle
Sixteen inch tag transfer table
Spring-loaded computer activated tag lock
Four-inch restacker chute
Adjustable slotted base
Manual/Automatic capabilities
Includes all wiring and software to work with the standard MC-2000
One (1) operators manual
Spare parts for complete machine include:
1-limit switch for tag unit
1-limit switch for MC-2000 unit
1-solenoid
1-spring
1-pin
1-oil
1-grease
1-set fuses
1-pin guide wrench
|
|
|
|
|
|
The MC2000 Superfast Bench-Top is the most rugged column and base marker available today. These single pin stamp markers are designed for deep, fast marking especially when readability after painting, galvanizing or plating is critical. Its patented Y axis slide design enables dot peen marking up to 16 characters per second, depending upon the character size.
Key Features:
-100% Carbide Stylus, able to mark hardened steel up to 62 HRC hardness
-Available in 3 marking window sizes:
50mm x 17mm (approx. 2 x 5/8)
100mm x 17mm (approx 4 x 5/8)
160mm x 17mm (approx 6.25 x 5/8)
-Adjustable marking speed up to 16 characters per second
-Aluminum base plate with tee slot for fixture mounting
-Height adjustment from 0 to 250mm
-Accordion style rubber boot over Z axis column for protection from the elements
-Motorized Programmable Z axis Option is available
-3 pneumatic marking head sizes available depending upon marking force required
-Flat, convex and concave surfaces can be marked
-Low impact marking with minimal vibration
-Ergonomic, lightweight design
-Cable lengths of 5 and 9 meters.
-Steel reinforced drive belts
-Long life heavy duty NSK slide
-2D Data Matrix. Standard feature when used with the MC2000 T Controller
-Import Logo files for marking. Standard feature when used with The MC2000 T Controller
MC2000 Series Bench Top
For direct part marking applications requiring larger marking window sizes, the standard MC2000 Series provides deep, high speed marking.
-Available in 2 marking window sizes:
90mm x 60mm (approx. 3.5 x 2.5)
150mm x 100mm (approx 6 x 4)
-Available in both electric and pneumatic design
-Aluminum base plate with tee slot for fixture mounting
-Height adjustment from 0 to 250mm
-Accordion style rubber boot over Z axis column for protection from the elements
-Motorized Programmable Z axis Option is available
-100% Carbide Stylus, able to mark hardened steel up to 62 HRC hardness
-Flat, convex and concave surfaces can be marked
-Low impact marking with minimal vibration
-Cable lengths of 5 and 9 meters.
-Steel reinforced drive belts
-2D Data Matrix. Standard feature when used with the MC2000 T Controller
-Import Logo files for marking. Standard feature when used with The MC2000 T Controller
-Angle and Arc marking capability
|
|
|
|
|
|
Mecco Marking & Traceability specializes in providing integrated dot peen marking solutions for high speed direct part marking for integrated assembly & automation solutions.
MC2000 Superfast | Dot Peen Marking
The MC2000 Superfast is the fastest, most reliable compact dot peen marking system available today. The premier system for direct part marking, the MC2000 Superfast is designed to meet short marking cycle times on production lines. Unlike other pin stamp marking equipment, the MC2000 Superfast utilizes a patented Y axis slide design for achieving faster marking times. The rugged simplicity of the MC2000 Superfast enables integrated dot peen marking up to 16 characters per second, depending upon the character size. The compact marking head permits integration of the marking equipment into small, confined areas and provides easier mounting to pneumatic approach slides.
With 3 available marking heads, the MC2000 Superfast is capable of deep, continuous line marking on a variety of material including:
- Steel : Forgings, castings, plate, carbon and stainless, up to 62Rc
- Aluminum : Forgings, castings, extrusions, plate
- Plastic : molded
MC2000 Series | Dot Peen Marking
For integrated dot peen direct part marking applications requiring larger marking window sizes, the standard MC2000 Series provides deep, high speed marking as well. Available in both electric and pneumatic design, the MC2000 Series of integrated dot peen marking equipment delivers precision, indent marking including logo generation, arc marking and 2D Data Matrix barcodes.
|
|
Mobile Marking Station:
Portable table
All steel construction
Tabletop is non-slip vinyl-matted 36 long x 22 wide
Bottom shelf 30 long x 20 wide
Wrap around bumper
14 x 20 x 5 small parts drawer with cylinder lock and keys
Six 3-prong grounded outlets on a plug strip with circuit breaker
Full pneumatic wheels, 2 swivel 2 rigid with brakes
Heavy Duty Retractable Electric Reel
Automatically retracts
125 volts
10 amps
7-3/4 wide x 12 deep x 12-3/4 high
Nema 4 rated
Cord length 30 foot
Air Line Reel
Double o-ring seal
Pressure rating to 250 P.S.I.
Ratchet engagement
Fully enclosed and replaceable rewind spring
Adjustable guide arms
1 solid steel axle
Full flow brass swivel joint
Overall size 17-1/4 long x 7 wide x 18-1/4 high
30 foot of 3/8I.D. hose
|
|
|
FineMarker is the professional plasma system for marking, notching and punching. With the continuously variable marking current in the range between 4 and 25 ampere plates and profiles can be marked durably or temporarily. A water-cooled plasma torch ensures a long lifetime of consumables. Materials: mild steel, stainless steel, coated plates, even with oily or wet surface.
|
|
Stand alone machine - compact - speed - innovative
Available in 2 versions: pneumatic or electro-magnetic
Marking window: 100x120mm
A fast & innovative machine for an easy identification of all your parts.
SIMPLE
Unpack and plug your XF500: it's ready to mark!
All-in-one: keyboard included, software integrated, you have all the traceability functions you need (Text, counters, dates, serial numbers, Data MatrixT codes, logos etc.). Autonomous (no computer needed) and
INNOVATIVE
Easily create your marking files: wide screen, icons, graphic preview.
Use your USB drive and import/export logos (.plt) and files.
VERSATILE
Adapt it to all your needs: Wide range of accessories available.
|
|
|
|
|
|
P5000, The New Marking Solution
The P5000 uses the micro-percussion technology which, contrary to traditional technology, does not require additional consumables.
The P5000 optimises the "cost/productivity/marking quality" ratio.
This machine allows a quick marking: 5 characters per second, with a high quality.
SIMPLE & VERSATILE
The P5000 is really easy to use and to install, no specific training is required. This machine is robust and easy to maintain.
The P5000 adapts to the size of the part to mark (height up to 300mm) and it can mark all types of materials up to a hardness of 62 HRC.
SELF-CONTAINED & AUTONOMOUS
The P5000 is self-contained with an integrated control unit, and can operate without a computer.
Thanks to its USB ports, the P5000 proposes extended memory and connectivity with peripherals.
TECHNICAL INFORMATION
- Power: pneumatic or electromagnetic
- Marking area: 100x120 mm
- Character size: 0.5 -100 mm (0.1 mm increments)
- Height of the part to be marked: max. 300 mm
- Dimensions: L=580 mm - W=280 mm - H=734 mm
- Weight: 34 kg
- Standard marking tool: PN22 or EM11/c
ACCESSORIES
ProPen offers a large choice of accessories for these marking machines.
|
|
Machine Parameters:
1.Hot stamping areaF60 x 90 mm
2.Worktable areaF105 x 150 mm
3.Operate way:manus
4.Height adjustmentF0 - 30 mm
5.Hot stamping widthF50mm
6.PowerF110 V / 220 V / 240 V
7.Teat wattageF300 W
8.Temperature adjustmentF0-200oC
9.WeightF8.2 Kg
10.Gross WeightF9.2 Kg
11.DimensionF260 x 160 x 340 mm
12.Dimension with packageF340 x 230 x 360 mm
Advantages:
1.Front loading foil system - for easy set up.300 watt flat heating element - for efficient heating.
2.Pressure control limiter - for precise printing.
3.Horizontal sliding table - for convenient working.
4.Integral lay gauges - for accurate product placement.
5.Micro adjustable auto foil feed. 60x90mm print head.
6.Pen jig and type chase included.
Testing:
1. a stamping plate;
2. some golden foil;
3. some samples.
Product Description
H-900 is an ideal machine for specialist printers of smaller items, the hobbyist, for taking to craft fairs and pony shows or simply those on a limited budget.
|
|
FlyMarker Mobile
Independent, hand-held CNC marking device
Marking area (x/y) 75 x 25 mm
Sturdy, low-noise, electromagnetically driven marking pin
Marks nearly everything, permanently...point by point!
100% mobile and compact hand-held pinmarker
Integrated display, keyboard, rechargeable battery
Optimum price performance ratio!
Instruction time for operators without CNC-knowledge: 1 minute!
Marks clear and well defined numbers, letters, various signs and logos in
dot matrix
Dot peening marking system
|
|
|
|
|
|
The handy marking solution.
A handheld machine, the M3000 offers the freedom of movement you need thanks to its design and portable battery. It can mark parts which are large, heavy, or in hard-to-reach areas.
The M3000 is available in pneumatic or electromagnetic versions.
TECHNICAL INFORMATION
- Marking area: 60x40 mm
- Character size: 1-30 mm in increments of 0.1 mm
- Dimensions (without handle):
L=350 mm
l=240 mm
H=200 mm
- Weight: 4.5 kg
MARKING POSSIBILITIES
- Linear, radial and angular marking
- Special marking (normal, inverted, mirrored, reflected text)
- Character adjustment, centering, character spacing, compression, inclination
- Programming of varaible data:
date and time, incrementing serial numbers, batch numbers, shift codes...
- Logotypes
- Available fonts: point separated or 5x7 matrix, CE mark
DOCKING STATION
This accessory converts your portable machine into a benchtop machine.
With a crank, you can easily adjust the distance between the stylus and the part for small parts and tags.
ACCESSORIES
Pro-Pen offers a large choice of accessories for these marking machines.
|
|
CNC Scribe Marker VU4 Sprint
Marking area (x/y) 80 x 50 mm
Option sprint enables shorter marking times. Aprox. 2 - 3 seconds for 10 characters in 3 - 4 mm character heights
Expansion of the central unit with a sprint drawer
Fully prepared and ready to be integrated marking system
Easy integration in production and assembly lines
Infinitely adjustment of the different marking strengths
Works in all positions
Highest marking repeat accuracy by high value linear guidance in connection with ball bearing screws
Particular suitable for data matrix marking
Maintenance free mechanics and tools
Protective covering against smut
|
|
MULTI4 is available in Scratching version. This technology using compressed air is ideal in situations where marking impact noise is an issue (<72dba) or where highly defined characters are required.
It allows permanent marking on numerous materials, from plastic to tempered steel.
Precise, accurate and easy to use, the Multi4 Scratching technology is particularly suited for marking parts generating noise, for good looking marking as well as for tooling marking.
Marking layouts or files can be created and marked in seconds. With the standard marking functions provided, marking errors are highly reduced or eliminated.
The MULTI4 Scratching model is an ideal system for marking simple or complex components in batches or longer runs.
|
|
|
|
|
|
Your ideal partner for the marking of name plates!
The innovative, network-compatible CNC table marking system NetMarker excels at marking quality, simple handling and ease of use. The NetMarker offers unequalled opportunities. The all new NetMarker raises the standards for high precision marking requirements within industrial production. It also offers many other further component marking opportunities with a wide range of additional features.
The competitive table marking system NetMarker works as a stand-alone machine. With its compact design being extremely space-saving. The electro pneumatically operated dot peen marking system is suitable for durable, efficient, permanent and quick marking tasks with the ability to mark almost all kind of parts made of metal. Naturally, you can mark pressure-sensitive, thin-walled, coated or moderately curved parts as well.
The system program NetMarker to handle the marking system is 100% operator prompted. It is designed to be transparent and self-explanatory. The system program NetMarker offers all modern characteristics of an intuitive program creation. It enables an online help option as well as the possibility to change the marking position and text within the marking preview screen.
Furthermore, an additional rotating axis can be programmed. All established features, like continuous numbering, circle marking, date and time & batch are already enclosed in the scope of delivery. Special signs and logos are available upon request.
|
|
MAP Automatic marking, punching, shearing line for metal profiles - flat bars - angle sections - I - U - H- UPAF, etc.
MAP range: MAP 160 MAP 300 MAP 450
Universal, powerful and high-speed machines
MAP 160, 300 and 450 machines are flexible marking, punching, shearing systems for metal profiles, etc., designed to switch easily from angle sections to flat bars, or to I - U - H profiles.
The modular design makes it possible to adjust equipment capacities to user requirements at the lowest cost.
Access to tools, punches and dies, is easy and makes it possible to switch production quickly.
The MAP series punching-shearing lines are the only machines on the market performing in a single pass all operations normally carried out on beams:
- easy programming
- fast and precise
- flange and web punching in a single pass
- easy and quick machine adjustment.
These machines are especially suited to steel structure construction.
|
|
CNC micropercussion MV5 U3
- Fully prepared and ready to be integrated marking system
- Application as a pin marker
- Standard marking area (x/y) 100 x 100 mm. Other marking areas on request!
- The marking head works electromagnatic
- Maintenance free mechanics and tools
- Extremely high marking quality by high value linear guidance in connection with ball bearing screws
- Particular suitable for data matrix marking
- Type of protection IP54
- Dot peening marking system
- Optimum marking deepth
|
|
|
|
|
|
Microdots Marking Systems, the model F.2 has a window area of 100x100mm (4x4In). Here F.2 is displayed as fixed marking machine with base and double column.
Technical Details:
This technology can mark up to a 1mm depth and on surfaces irregularities up to 14mm (0.5In).
All models are available:
as portable handy tools,
as integrated systems,
as fixed structures.
Easy to program, F.2 can manage all following functions:
1000 programs in memory,
texts in line, angular, mirror,
arc-texts,
serial numbers,
batches of production,
time and date,
working shifts,
customized codes,
preview, diagnostic and many more.
The excellent management of the mechanical movements allows marking:
logos,
2D Matrix and OCR codes,
fonts per dots 5x7 and 11x16,
continuous line fonts.
The flexibility of the software allows communication:
with PC direct and wireless,
through RS232 / RS485,
from/to PLC,
from Bar Code readers,
TXT files,
integrated floppy disk port.
Low maintenance, reliable and friendly use, all Microdots Marking Machines are supplied complete with programmable controller with JOG function, tungsten-carbide stylus in 3mm or 6mm diameter, filter and air regulator and all accessories to suit customers needs.
|
|
Dot peening marking system MV5 T0
Marking area (x/y) 100 x 100 mm
Highest stability of the column frame by massive tracks
Fast adjustment of the height by a hand wheel. Four times faster than conventional column frames
Integrated digital height index
Highest marking quality at maximum speed by precise mechanics
Easy operation
Maintenance free mechanics and tools
Highest flexibility by system expansion with additional components
Micro percussion marking system
|
|
|
|
|
|
Microdots Marking Systems, the model F.1 has a window area of 65x65mm (2.5x2.5In). Here F.1 is displayed as fixed marking machine with base and double column.
Technical Details:
This technology can mark up to a 1mm depth and on surfaces irregularities up to 14mm (0.5In).
All models are available:
as portable handy tools,
as integrated systems,
as fixed structures.
Easy to program, F.1 can manage all following functions:
1000 programs in memory,
texts in line, angular, mirror,
arc-texts,
serial numbers,
batches of production,
time and date,
working shifts,
customized codes,
preview, diagnostic and many more.
The excellent management of the mechanical movements allows marking:
logos,
2D Matrix and OCR codes,
fonts per dots 5x7 and 11x16,
continuous line fonts.
The flexibility of the software allows communication:
with PC direct and wireless,
through RS232 / RS485,
from/to PLC,
from Bar Code readers,
TXT files,
integrated floppy disk port.
Low maintenance, reliable and friendly use, all Microdots Marking Machines are supplied complete with programmable controller with JOG function, tungsten-carbide stylus in 3mm or 6mm diameter, filter and air regulator and all accessories to suit customers needs.
|
|
|
|
