Imaging colour measuring technique
Contact persons: Dipl.-Ing. Tobias Porsch; Dr.-Ing. Udo Krüger
The imaging analysis of light sources and illuminated scenes is getting more and more important.
The LMK 98-4 color / HighRes color camera is equipped with a filter wheel adapted to the color matching functions of the 2° CIE standard observer (CIE 1931) for color measurement. Thus, luminances and color coordinates can be measured in a spatially resolved way.
The filter wheel has 6 filter positions, with 4 filters being required for color measurement. Furthermore, the measuring system can be equipped with additional filters for the scotopic luminance V'(%u03BB), the circadian principal function C(%u03BB), with an IR filter (measurements in the NIR range %u03BB=780-1000 nm), the filter for blue light hazard (BLH) or a clear glass filter.
|
|
|
|
|
|
Imaging luminance measuring technique
Contact persons: Dipl.-Ing. Tobias Porsch; Dr.-Ing. Udo Krüger
The imaging analysis of light sources and illuminated scenes is getting more and more important. The complex evaluation of those scenes requires to know the luminance distribution. Solving the necessary measuring tasks by means of measuring devices working point by point either takes an enormous amount of time or is possible only within a coarse raster grid or is not possible at all. Thus, the development of CCD matrix cameras, has enabled the user to solve measuring problems such as measurements for glare evaluation according to the UGR method, the analysis of visibility conditions in the road traffic at night, immission evaluations of glare sources, the determination of contrasts in illumination situations (workplace) or directly on light sources (e.g. lamps/luminaires, displays, night design, indicators).
- measuring of luminous and illuminated surfaces
- determination of luminous and background-lit symbols
- data for simulations in the development of lamps, luminaires and headlamps
- photographing of complex illumination and light distribution situations
Advantages:
- complex evaluation of luminous and illuminated scenes by means of the photograph of an imaging luminance distribution
- simultaneous recording of a big number of connected geometrical data
Resulting data
- luminance distributions in measuring images L(x,y)
- derived lighting-engineering parameters such as illuminance distribution E(x,y) and luminous intensity distribution I(x,y)
- compatible statistical data (e.g. EXCEL®, MatLAB®, LabVIEW®)
|
|
The FP8800 Flame Photometer is used for simple, precise and inexpensive measurement of concentration of alkaline elements in aqueous solutions for analytical applications in process and laboratory. It was developed especially for industrial applications. It features a PROFIBUS DP and two Ethernet interfaces for computer-aided process control (SPC). Two USB-ports are intended for data export (e.g. in .csv format) or firmware update via USB flash drive. The FP8800 features the use of propane or butane as a
fuel gas which allows flame-photometric measuring up to three elements simultaneously. In addition purified and dried air is required. Measurements can be performed either with or without internal standards. Standard solutions are used for calibration, while control solutions are used to verify results. All samples, controls and standards are presented
manually. The device can be customized flexibly to users´ requests.
|
|
|
|
|
|
SIDEPAK™ AM510 PERSONAL AEROSOL MONITOR
The SIDEPAK™ AM510 Personal Aerosol Monitor is a rugged, lightweight, belt mounted laser photometer, weighing as little as 16 oz. It is compact and quiet, minimizing interference and worker discomfort. The built-in sampling pump lets you attach a wide variety of size-selective inlet conditioners for worker breathing zone or area measurements with a respirable cyclone or one of the three integrated impactors. The AM510 comes with TSI's Smart Battery Management System™, which includes long-running NiMH or alkaline battery packs and provides precise run time information in minutes remaining.
The AM510 personal aerosol monitor's easy-to-read display shows your data in both real-time aerosol mass concentration and 8-hour time-weighted average (TWA). With its convenient data logging and long battery life, the monitor is also ideal for extended sampling. Easy-to-use TRAKPRO™ Data Analysis Software lets you pre-program sampling events and create effective graphs and reports. Available in single- and 3-unit kits.
Applications:
- Personal exposure monitoring/IH studies
- Ambient/work area monitoring
- Trending/screening
- Engineering studies
- Epidemiology health studies
- Environmental sampling
|
|
POCKET Colorimeter II
More than 30 flexible, single parameter instruments
- Easy operation
- Small enough for almost any pocket
- Reliable results without a mains connection
- Rugged construction yet lightweight
DR 800 series—compact colorimeters
The DR 800 models are preprogrammed for different numbersof tests:
– DR 820: 20 tests
– DR 850: 50 tests
– DR 890: 90 tests
All three DR 800s work best in combination with the practical HACH tests for reliable, fast results in wastewater, drinking water and process water analysis.
|
|
|
|
|
|
WTW has developed a new line of field instruments based on optical measurement offering the following capabilities:
• pHotoFlex: photometry, pH
• pHotoFlex Turb: photometry, pH, turbidity
• Turb 430 IR and Turb 430 T: turbidity
The instruments have been designed to extract the optimum performance from the latest generation optics optics with state-of-the-art LED technology.
Remarkable features include:
• Low power consumption
• Robust
• Display-driven user interface
• Waterproof
• Integrated smart cuvette adapter for 16 and 28 mm cuvettes
• Hand held
The exceptional versatility of the pHotoFlex, pHotoFlex Turb and Turb 430 makes them ideal for use in process control, water analysis, and the beverage industry.
Both pHotoFlex and pHotoFlex Turb are equipped with a pH function, measuring the full pH range from –2.00 to 16.00. The pH measurement is simplicity itself, offering automatic temperature compensation and auto buffer recognition.
For turbidity measurement the Turb 430 IR offers a large range from 0-1100 NT/FNU. Outstanding features include: Automatic 3-point calibration, GLP compliant data export via RS 232, calibration record and the setting of a calibration interval.
|
|
|
The LumiCam 1300 imaging photometer and colorimeter captures complex luminance and color distributions in an instant. A monochrome version of the camera is available for applications requiring luminance measurements without color information. The LumiCam 1300 is based on the Interline CCD sensor ICX-285 from Sony, offering an exceptional signal to noise ratio, low smear and very low blooming. A multi-exposure mode provides up to 6 orders of magnitude of dynamic range in a single image, with an absolute measurement range covering 0.0001 to 100,000 cd/m². Higher luminance values are achievable through the use of optional optical density filters. The compact format of the LumiCam 1300 makes it very flexible and opens a diverse range of possible applications. The accompanying LumiCam Software provides comprehensive functions for convenient analysis and documentation of results.
|
|
The ADR-1200S measures mass concentrations of particulates by means of light-scattering photometry. The system has the capability to collect sampled particles on a membrane filter for gravimetric or chemical analysis.
The ADR-1200S can be used for particulate size-selective measurements using either the metal cyclone (included) or the optional inline impactor Model DR-PM10/2.5. The latter is especially designed for PM10 and PM2.5 monitoring. The cyclone is preferred for either respirable particle monitoring or to obtain information on particle size distribution. In addition to the real-time/continuous measurements by light scattering, the system enables the user to collect the sampled particles on a membrane filter for gravimetric and/or chemical analysis.
|
|
|
|
|
|
Transmitter of Iluminancia
By photometric sounding with adjustment of angle with local indicator and RS-485 MODBUS.
2 xs 4-20 mA. IP-65
The DMM-4000/LUX is a measurement system of the ambient iluminancia by means of sounding LUX-2000 with correction of the spectral curve. Appropriate to be located in dispersed zones and to transmit data by means of RS-485 Modbus towards acquisition systems. In option they allow to control directly balastros of lights
with the purpose of to maintain a luminosity predetermined.
Transmitter of iluminancia (photometer)
Sounding LUX-1240 in body of aluminum and glass
Rank from 0 to 10,000 lux (máx. 100.000 lux)
Sensorial head with correction of angle
Cds sensor with reception angle máx. 240 º
Spectral response of 400 nm to 800 nm
Control PID for regulation of balastros (optional function)
Double bow of transmission (or control) that allows to handle two soundings LUX-1240
Logical entrance for presence detector
Feeding 85... 265 Vac (either 12 or 24 Vdc in option)
Communication RS-485 MODBUS
APPLICATIONS
- Measurement and control of the ambient illumination.
- Labor Audits of illumination.
- Farming or piscicultural Investigation, with capacity of programmed control to emulate cycles of day-night.
- Quality control of lights.
- Supervision of public lighting system, offices, buildings, etc.
- Automatic control of illumination of one or two independent zones by direct control on its balastros.
|
|
|
PM Series™ Imaging Photometers and Colorimeters are highly accurate, CCD camera-based systems useful for making precise spatial measurements of luminance and chrominance. All of our PM Series™ products include Radiant Imaging's powerful data acquisition and image processing software. This tool simplifies system control and provides easy access to a number of analysis capabilities, including chromaticity coordinate information, color temperature, angular dependence of display properties, and even Mura defect detection. Built-in support for ActiveX controls allow the experienced user to develop customized applications, and to perform automated testing using software such as LabView, Matlab, VBA, VBScript, Javascript, C and C++.
|
|
|
|
|
|
Jenway is the world leader in Flame Photometer production, with our simple, easy-to-use models found in many thousands of laboratories all round the globe. This interference free method of measuring Sodium (Na), Potassium (K), Calcium (Ca), Lithium (Li) and Barium (Ba) is common in the food processing and feed industries, for agricultural, dairy and wine analysis, in chemical and petrochemical processing, in the drinks industry, in environmental and water analysis, cement, mineral and ore processing and many more… A key area of application is in the clinical laboratory where flame photometers have traditionally been used for the measurement of electrolytes in serum, plasma, urine and other body fluids.
The Models PFP7 and PFP7/C are low temperature, single channel flame photometers designed for the routine determinations of Na & K (Ca, Ba and Li optional). With in-built automatic flame failure detection for user safety these products can be used with Propane, butane, LPG or natural gas, an optional compressor is also available where a clean air supply is not available.
The Model PFP7/C is specifically designed for use in clinical applications. The in-built lineariser circuitry enables readings of both Na and K at the normal clinical serum concentrations to be displayed directly in mmol/l. Serum samples must be diluted prior to presentation to the flame photometer. The Series 7 diluter is available to enable this to be carried out efficiently and accurately.
|
|
CL 22D & 26D
Dual Channel Flame Photometers
Salient Features & Benefits
- Dual Channel.
- Concentric non-corrosible Nebulizer.
- Mixing Chamber designed for stable flame.
- Flame System: Stainless Steel round Burner with LPG as Fuel and Air as Oxidant.
- Narrow band Interference Filters.
- Small quantity of sample needed.
|
|
|
|
|
|
Process PhotometersPUV3402 and PIR3502 ...
The Next Generation of On-Line Process Photometers.
Multiwave™ Process Photometers are designed to provide on-line measurements of gas or liquid components, in simple or complex process streams, for process control, product quality assurance, safety, catalyst protection and area monitoring.
The Multiwave™ is a fixed filter photometer that utilizes optical filters to make continuous measurements. The single beam, dual wavelength concept used in the Multiwave™ compensates for source and detector aging and the obstruction of cell windows, while allowing the sample cell to be isolated from the electronics.
The Multiwave™ design takes the single beam, dual wavelength concept one important step further, by adding up to eight filters to the filter wheel. This improved method provides more measurement solutions than a conventional single component process photometer. The use of multiple wavelengths enables the Multiwave™ to compensate for numerous interferences and perform multiple component applications.
The new Multiwave™ Process Photometers offer even more performance,
operating efficiency and versatility to the user. The Multiwave™ line features two basic models, each offering a wide range of applications capability.
PIR3502 Multiwave™ Photometers can be applied to Infrared and Near
Infrared measurements.
PUV3402 Multiwave™ Photometers are designed for the Ultraviolet and
Visible spectral regions.
|
|
Model 7500 Infrared Gas Analyzer
Teledyne's Series 7500 Infrared (IR) Gas Analyzer is capable of detecting up to three individual IR absorbing components (i.e. CO, CO2, CH4, SO2) on a continuous basis.
Conveniently packaged in either a 19" rack mount or NEMA-4 wall mount enclosure, the Series 7500 can also be supplied with an oxygen sensor - Micro-fuel cell, paramagnetic, or ZrO2 -- providing the operator with a space-saving, four in one, cost-effective design.
The NEMA-4 enclosure can be X or Z-purged to satisfy hazardous area installation requirements.
|
|
| ... products without technical information |
| |
|
|
|
|
The PFO3372 Multiwave Fiber Optic Photometer solution is effective in UV(ultraviolet), VIS (visible), NIR (near infrared) applications where:
- Sample Stream is highly toxic
- Corrosive products are analyzed
- Streams are at high temperature
- Streams are at high pressure
- The Sample is at high vacuum
- The Sample needs to remain sanitary
- Fast response time is required
- Sample is at a high pressure
ABB process photometers provide continuous on-line measurement of gas or liquid components, in simple or complex process streams, for process control, product quality assurance, safety, catalyst protections and area monitoring.
The PFO3372 incorporates the use of fiber optic sampling accessories for added measurement capability.
Moisture applications such as water in acds, water in methanol, water in hydrocarbons or hydrocarbons in water are good candidates for the fiber optic option. Applications that require a fast response time, such as monitoring the Lower Explosive Limit (LEL) for hydrocarbons in air, should also be considered.
|
|
|
|
|
|
Near-field goniophotometer RiGO801
Contact persons: Dipl. Ing. Knut Bredemeier, Dr.-Ing. Franz Schmidt
The full determination of the data of luminaires and lamps becomes more and more important:
- Primary prerequisite of a correct illumination planning
- Simulation, development of luminaires and lamps
- Cataloging and presentation
The goniophotometer type RIGO801 utilizes imaging CCD measuring technique for determining ray data and luminous intensity distributions.
The correct determination of the luminous intensity distributions (Lid) of lamps and luminaires is performed far within their photometric limiting distance on the basis of image-resolved measurements of luminous intensity distributions. A CCD-camera is moved by a goniometer around the measuring object at rest on a spherical surface, with the radius of this sphere being fixed only by the field angle of the camera. Thus, the goniometer can also be installed in small laboratories.
Advantages:
- Full description of the light emission by ray data
- Small dimensions of the set-up
- Measuring in normal position
Resulting data:
- Luminous intensity distributions (LID)
- Ray data available in various formats (e.g. ASAP, SPEOS, LucidShape, LightTools, Zemax, SimuLux)
- Processing and archiving of the LVK data in a photometric database (LumCAT)
|
|
|
|
|
|
The integration of high-quality digital cameras in the LMK system is an attractive possibility of recording luminance images in an easy and quick way, regardless of your measuring computer. For subsequent evaluation, the complete range of functions offered by the LMK LabSoft software can be utilized.
With the LMK mobile camera, the TechnoTeam company possesses substantial know-how and many years of experience in this field of luminance measurement, which is also proved by 140 cameras of this type being sold. The product range has been expanded by the second generation of modern mobile luminance measuring cameras type LMK mobile advanced.
Applications:
- Indoor measurements, for example in offices or at workspaces. Easy glare assessment according UGR standard.
- Fast and easy determination of luminances in outdoor areas. For example the illumination of public squares and places in the urban surrounding (veiling luminaces) or street and traffic way illumination (TI Threshold increment)
- Review the illumination on façades and of street lighting fixtures and other public traffic ways.
|
|
POCKET Colorimeter II
More than 30 flexible, single parameter instruments
- Easy operation
- Small enough for almost any pocket
- Reliable results without a mains connection
- Rugged construction yet lightweight
DR 800 series—compact colorimeters
The DR 800 models are preprogrammed for different numbersof tests:
– DR 820: 20 tests
– DR 850: 50 tests
– DR 890: 90 tests
All three DR 800s work best in combination with the practical HACH tests for reliable, fast results in wastewater, drinking water and process water analysis.
|
|
|
|
|
|
WTW has developed a new line of field instruments based on optical measurement offering the following capabilities:
• pHotoFlex: photometry, pH
• pHotoFlex Turb: photometry, pH, turbidity
• Turb 430 IR and Turb 430 T: turbidity
The instruments have been designed to extract the optimum performance from the latest generation optics optics with state-of-the-art LED technology.
Remarkable features include:
• Low power consumption
• Robust
• Display-driven user interface
• Waterproof
• Integrated smart cuvette adapter for 16 and 28 mm cuvettes
• Hand held
The exceptional versatility of the pHotoFlex, pHotoFlex Turb and Turb 430 makes them ideal for use in process control, water analysis, and the beverage industry.
Both pHotoFlex and pHotoFlex Turb are equipped with a pH function, measuring the full pH range from –2.00 to 16.00. The pH measurement is simplicity itself, offering automatic temperature compensation and auto buffer recognition.
For turbidity measurement the Turb 430 IR offers a large range from 0-1100 NT/FNU. Outstanding features include: Automatic 3-point calibration, GLP compliant data export via RS 232, calibration record and the setting of a calibration interval.
|
|
