Screwdrivers are available with various impact mechanisms. Each application has it’s own mechanism. Therefore please take note of the
information below before purchasing a tool.
1-Hammer
The 1-hammer system makes 1 impact per rotation at 1 side of the anvil. This causes a higher energy per blow. The screwdrivers with the 1-hammer system are especially suitable for wood and steel screws.
2-Hammer
The 2-hammer system makes 2 impacts per rotation at both sides of the anvil. This mechanism is used for wood and steel screws and works more quiet than the 1-hammer system.
Direct drive
These direct drive screwdrivers are suitable for selftapping screws and wood screws.
Clutch mechanism
Screwdrivers with a clutch type mechanism are used for standard applications with normal joints. The mechanism works by means of
spring pressure. When reaching the torque the mechanism slips.
Shut-off mechanism
To comply with the ever increasing demands for screwdriving accuracy and work safety, we present a new range of pneumatic screwdrivers with a maximum torque repeatability. Along with the exceptional torque accuracy, the new Jointech Plus 2 torque control system has automatic high speed air shut off to allow for a considerable reduction of the reaction to the operator's hand.
|
|
The LÖSOMAT high torque pneumatic wrench works quietly and is robust, with its rotary drive motor. An air control unit supplies constant air pressure.
Main application areas:
Power plants, transport industry, chemical industry, plastics industry, cable cars and lifts, mining, tunnel construction, shipyards, oil and gas industry and cement industry
|
|
|
Get it together fast and accurately with Atlas Copco pneumatic screwdrivers. For industrial assembly operations, accurate fastening and productivity go hand in hand. Atlas Copco pneumatic screwdrivers will bring quality and productivity in to the assembly process. The clutch controlled screwdrivers are designed for optimum productivity and quality, with accurate and consistent torque control that will reduce quality problems and minimize production line down time. The screwdrivers are ergonomically designed- they are light and comfortable to hold, with fast clutch release, ergonomic design and soft warm grips prevents operator strain.
|
|
The Cleco family of pneumatic tools is one of the most
diverse in the portable tool industry. With a broad
selection of clutches and motors, this line of tools covers
a wide range of torque at several speeds. Coupled with a
diverse line of attachments and throttles, these tools are
suitable for an indefinite number of applications.
|
|
CP Industrial screwdrivers:
These tools are suitable for high production rates such as those on production/ assembly lines, where high durability is required and the tools are used frequently. Our industrial tools combine the best of quality, durability and ergonomics for your most demanding applications.
CP RediPower screwdrivers:
RediPower tools are suitable where the tool is used intermittently for industrial maintenance or non-intensive production.
|
|
The large variety of our handheld Screwdrivers, offered in many different design series, provides an ideal coverage of most torque ranges.
The simple and compact air motor makes the tool lightweight and easy to operate.
Our tried and tested MICROMAT™/MINIMAT™-clutch, is the basis for an extreme high repeatability. We guarantee the user-friendliness and an unmatched lifespan, due to the constructive design, which is specialized for operation in a harsh industrial environment and because of our quality-assured production.
|
|
|
|
|
|
Joining components in today's industrial environment is much more than putting wrench to bolt. It's about finding a solution that links the operator and the joint and delivers unparalleled accuracy and repeatability. Ingersoll Rand has a superior knowledge of the threaded fastening process, acquired through years of application work with the world's leading manufacturers in the motor vehicle, aerospace, appliance, and electronics industries. We understand the interface of the tool and operator - and know how to leverage the power of ergonomically-designed equipment to maximize productivity.
Beyond just product, Ingersoll Rand's extensive capabilities help you before, during, and after your line or work area is configured for production. Presented here is Ingersoll Rand's portfolio of products and services specifically tailored to the modern assembly environment. Whether your business is assembling motor vehicles, automotive components, aircraft systems, appliances, office furniture, or consumer electronics, there is solution from Ingersoll Rand that will meet your needs and exceed your expectations.
|
|
Reversible screwdriver
V.620RF
Technical caracteristics
- Free speed : 1,800 rpm.
- Recommended working torque : 13 N.m.
- Average air consumption : 110 l/min.
- Air inlet thread : 1/4".
- Working pressure : 6.2 bar.
- Screw size : M4.
|
|
On-Pin - Pneumatic Screwdrivers
We can offer a variety of different models of hand-held pneumatic screwdrivers covering most torque ranges.
Available as hand-held or pistol grip the On-Pin range is manufactured in a ergonomically sturdy light weight design.
Automatic shut-off when torque is achieved
Push-start design
Quick chuck for easy changeover of driver bits
Low noise & air consumption
|
|
QA 4 / QA 6 / QA 8
Precision Air Nutrunners
High precision shut off clutch
for consistent repeatability and process quality
Adjustable shutoff clutch provides repeatability that improves joint quality
Quick, precise clutch shutoff limits torque scatter and reaction to the operator
ISO 5393 tested
Cycle counting capability enables integration into process control systems for QA4 and Remote tools.
Clutch tested to over 1 million cycles without failure
Proven components from our world-class line of DC electric tools
2 Year Warranty on clutch and angle heads
Three powerful motor options to match your torque and speed requirements
Adjustable Shutoff Clutch or Stall
Multiple drive sizes, spindle lengths, and floats
Single or Multi-spindle fixtured systems to increase productivity and improve joint quality
Run with Lube or Lube free
|
|
|
Get it together fast and accurately with Atlas Copco pneumatic nutrunners. For industrial assembly operations, accurate fastening and productivity go hand in hand. Atlas Copco pneumatic nutrunners will bring quality and productivity in to the assembly process. The clutch controlled nutrunners are designed for optimum productivity and quality, with accurate and consistent torque control that will reduce quality problems and minimize production line down time. The nutrunners are ergonomically designed- they are light and comfortable to hold, with fast clutch release, ergonomic design and soft warm grips prevents operator strain.
|
|
|
Stanley nutrunners offer all tool geometries, mounting options, and output types on all pneumatic and electric tools. Geometries include pistol, straight, angle, and offset. Mounting options include reaction bars, base mount brackets, flanges, and spring-loaded spindles. Output types include the industry-leading portfolio of crowfoot, tubenut, hold-n-drive, and flush socket heads. Stanley also delivers custom configurations to address extreme assembly challenges. Stanley pneumatic nutrunners include continuous drive and pulse types. Continuous drive nutrunners have either clutch or air shut off.
|
|
|
|
|
|
Maintenance & Automotive
Ingersoll Rand impact tools are the brand of choice for professional automotive mechanics and the racing teams of NASCAR. New geometry and materials together with years of engineering knowledge combine to deliver the best torque ranges and the lightest most durable product on the market.
Whether you choose the classic 231C or the newest revolution in impacts, the 2135Ti Titanium ½" impact, you will quickly see why professional mechanics around the world turn to Ingersoll Rand.
3/8" Drive
1/2" Drive
3/4" Drive
1" Drive
Industrial Production
The toughest industrial applications in the world run 24- hours a day, 7 days a week,
365 days a year...that's why Ingersoll Rand is dedicated to manufacturing impact tools that
can hold up to your toughest jobs.
Ingersoll Rand Industrial Production Class impact tools are designed with durability in mind, from the vanes turning the motor to the hammer frames and anvils. Proprietary hardening and treatment processes, innovative ergonomic design, and excellence in manufacturing all add up to the longest lasting, hardest hitting impact tools in the business.
3/8" - 3/4"
1" - 1 1/2" Drive
2" - 3 1/2" Drive
Torque Control
Electric
|
|
