ZTA/ZTT SERIES 2.000MHz~40.000MHz
CRB SERIES 190KHz~1250KHz
CRB 456F/503F/480E SERIES 456KHz, 480KHz, 503KHz
ZTACC/CS/CV/MG/MT/MX; ZTTCC/CS/CV/MG/MT/MX 2.000MHz~50.000MHz
LT10.7 SERIES 10.7MHz
|
|
Series :
ZTACC :
Frequency : 1.84MHz to 8.00MHz
ZTACS :
Frequency : 6.00MHz to 13.00MhZ
ZTACV :
Frequency : 8.00MHz to 13.00MHz
ZTACW :
Frequency : 20.00MHz to 25.99MHz
ZTTCC :
Frequency : 1.84MHz to 8.00MHz
ZTTCR :
Frequency : 4.00MHz to 8.00MHz
ZTTCS :
Frequency : 6.00MHz to 13.00MHz
ZTTCV :
Frequency : 8.00MHz to 13.00MHz
ZTTCW :
Frequency : 20.00MHz to 50.00MHz
ZTB Y :
Frequency : ±2KHz
|
|
ZTTCV....MT Series 8.00-13.00 ZTTCV....MX Serie 16.00-50.00
ZTTCC....MG Series 1.84-8.00 ;ZTTCS....MT Series 6.00-13.00 ZTTCS....MX Series 13.01-50.00 ;ZTACV....MX Series 16.00-50.00
ZTACV....MT Serie 8.00-13.00; ZTACS....MX Series 13.01-50.00 ZTACS....MT Series 6.00-13.00 ;ZTACC … MG Series 1.84-8.00
|
|
PARAMETER
Frequency Range 13MHz /19.2MHz/26MHz; Supply voltage Vcc 2.4~3.0V
Control voltage 0 Vcc ; Output Waveform Clipped Sine Wave `
Output Level 0.8 Vp-p ; Input Current 1.5 mA Max
Operating Temp. Range-30+75℃ , Storage Temp. Range: -40+85℃
|
|
1.SCOPE
This specification shall cover the characteristics of 1-port SAW resonator used for remote-control security.
|
|
