Series of newest advanced models of Mikrosam's CNC machines for processing marble, granite and stones. This CNC machines has been designed to offer maximum flexibility and much opportunity for machining of marble, granite and stones. Traditional qualities combined with the most advanced technological innovations that were already implemented have made our machine ideal solution for marble, granite and stone industry.
High productivity machines, ideal for drilling, milling, 2D and 3D modelling, lettering, engraving, internal and external edging, bevelling, grooving, cutting with strait and convex disc.
|
|
V-CUT
CNC cutting centre with 3 controlled axes, designed for cutting profiles made of
aluminium, PVC, light alloys in general. V-Cut loads the extruded section and cuts it, then unloads the finished part all in fully automatic mode without need for operator
attendance.
The powerful and versatile software can handle predefined cutting lists, optimizing them to minimize wastage. The cutting head allows cutting at +/- 22°30' and intermediate angles.
|
|
|
|
|
|
The TK 804/3 model features an automatic machining and cutting system for aluminum profiles and it is designed to minimize the manual intervention of the operator during the machining cycle, allowing the operator only to load/unload profiles.
The machine comprises a multi-spindle combined unit, complete with 3 controlled axes, where it is possible to install a maximum of 8 electric-spindles to perform milling, drilling and tapping operations on 4 sides of the profiles before they are cut.
The machining line comprises:
In-sequence loader
Loading table with a 3 axis CNC pusher
Labeling machine (optional)
Multi-spindle combined unit
Cutting unit
Conveyor belt
Unloading table
Thanks to the versatility of its components the TK 804/3 model can meet the manufacturing needs of every customer: profiles loading/unloading systems, clamping, handling and machining can be customized according to the characteristics of the workpieces, to the working cycles and to the type of machining to be performed.
The high automation of the TK 804/3 model significantly reduces machining times while improving the production process.needs of each customer.
|
|
As the leading manufacturer of machines for processing aluminium and PVC profiles, we supply matured solutions for different applications.
You have profile - we cut it !
Further saws, like Table saws, Mitre saws, Double mitre saws, Notching saws, Vee-notch and cut off saws, Automatic saws and Automatic saws with pusher cover our product range.
|
|
AUTOMATICA E
Single-head, rising blade cutting-off machine with automatic cycle only for 90° cutting, equipped with N/C electric bar feeder with positioning tolerance in cutting down to ± 0.05 mm and automatic separator system for cut pieces.
|
|
|
|
|
|
SA-70NC
Solid Bar Sawing and Tube Cutting Machines
Shortest 25mm Crop Lengths Metal saw
SA-70NC – S ( HSS Saw Blade )
SA-70NC – U ( TCT Saw Blade )
SA-70NC – NF ( Non-Ferrous )
The new SOCO SA-70NC tube sawing machines incorporates the newesttube cutting technology with unparalleled functions. This revolutionary innovation brings you the shortest crop length available in the global market: 25mm (SOCO Global Patent). With capacity up to OD70 mm in solid bar cutting and tube cutting, it is guaranteed to bring you continuous savings and production.
Tube Cutting Machine Features:
• 25mm – The shortest Crop Length of any pipe cutting machine available in the market
• With the shortest crop lengths, the SA-70NC brings maximum material savings and more production
• Using a thinner and smaller TCT saw blade, there is lower initial investment in blade and long term savings in material
• HSS Saw blades may also be used, with standard built-in settings and cooling system, for even more savings on tube cutting
• TCT Saw Blade for maximum speed and performance in tube sawing and bar cutting
• Superior Speed : O.D.40mm Copper solid bar, L = 56.5mm,cycle time is 3.7sec
• Floating Feeding Carriage to ensure precise feeding and cutting lengths
• 6.5 Meters Tube and Bar Loading Magazine
Keywords
Pipe Benders,Tube Benders,Tube Bending,tubing bender,bending pipe,Pipe Bending,Bending pipe Machine,Tube Bending Machine,Pipe Bending Machine,tube cutting,metal saw,Circular Saw,Sawing Machine,tube cutter,pipe cutting,pipe cutter,circular sawing machines,Saw blades,chamfering machine,deburring machine
|
|
|
|
|
|
Because glazing bead cutting is a job of crucial importance for the quality of the finished frame, our glazing bead cutting units are designed to provide a perfect finish and be simple and convenient to use. They can in fact cut 2 glazing beads at a time. To ensure the utmost adjustment flexibility in accordance with the range being machined, their position is adjustable. The same concept has been applied to all the other registrations. You can in fact raise and lower the worktable and move the stops, which together with the clamps, secure the glazing beads. Once the different positions have been registered, these can be defined by means of the revolver (thereby obtaining up to 6 different and reproducible positions). This way, you no longer need to purchase the retention counter templates: you are thus provided with the utmost autonomy even when you change or extend your profile range. Cutting is done by means of 2 x dia. 250 mm blades while the milling of the fastening foot is done by another two dia. 155 mm coaxial blades.
Both models can be connected to the locator stop mod. KIT_16DX featuring metric rule and two removable gauges. Support KIT_16SX is also available to be positioned to the left of the machine and which can be fastened to the floor to support the glazing bead on the loading side as well.
Both cutting-off machines can be connected to the DigiSTOP stop and to all the DigiFAMILY products for the electronic reading of the measurements to be cut.
TR55/2 and TR65N differ as regards the blade feed system. In the case of the TR55/2, this is manual, while in that of the TR65N, it is automatic (and speed is adjustable).
|
|
The TR_152 is a new-concept cutting-off machine specifically designed for cutting PVC profiles.
Because it features ø 550 mm blades and has 4 vertical clamps and 1 horizontal clamp on both heads, it can cut up to 4 profiles every work cycle (or 2 monoblocs). The particularity of the TR_152 is that it features ascending movement blades: this way in fact, the reference point is always the wider part of the profile and consequently the outer tip of the corner.
You can control mobile head movement in two ways. With the TR_152 by means of the electronic positioner; while with the TR_152E, you will have at disposal the complete software version, which will enable you to enter orders from the office and print the bar code labels to be affixed to the profiles later on in order to follow the production line until the frame is completed.
The maximum cutting capacity is 3500 mm, while minimum capacity is 360 mm.
|
|
TK 145/10 PLUS Exceptional double mitre saw.
New version of the TK 145/10 model completed with 600mm diameter circular blades that increase its cutting capacity. It offers exclusive performances thanks to its ability of working on multiple angles, thus obtaining a high precision level while ensuring robustness and reliability.
Special fabricated and welded steel bed frame with finish machined,
complete with slideways for the mobile head.
Automatic descent of fully safety protections.
Head tilting from 22° 30’ to 90°.
Accuracy: ± 0,1 mm.
Blade motor power: 2 x 3 kW
Blade motor revolutions: 2800 rpm
Blade diameter: 600 mm
|
|
TWIN ELECTRA SUN
Twin-head cutting-off machine with 3 controlled axes, automatic traverse of the moving cutting head and electronic control of every angular setting from 45° (internal) to 22°30’ (external) with accuracy of 240 places on each degree.
|
|
|
|
|
|
TK 145/20 CNC gold Exceptional double mitre saw.
Full protection with complete cover and front automatic lowering closure.
Special fabricated and welded steel bed frame with finish machined,
complete with slideways for the mobile head.
Double head tilting from 22°30’ / 90° / -45° operated by direct current
motors controlled by NC.
Noise deadening guaranteed by the complete enclosure and also
by acoustic insulation panels
Mobile head operated by direct current motors and controlled by NC.
Travelling speed: 24m/1’
Conveyor belt for chips removal
STANDARD PROGRAMS
- Single cuts
- Sequence of cuts
- Profile codes and profile heights stored in memory for automatically calculating cuts at 45°
- Loading of cutting lists originated from ABACUS/TEKNA program
- Wings cut
- Blade motor timeout: blade motor automatically turns off after an inactivity period of the machine
- Sequence of cuttings on bar: bar manual progress, variable cutting length, possibility to vary the cutting angle on any degree.
- Automatic motor start in manual cuts
- Possibility to work with inches
OPTIONAL PROGRAMS
- Extra-short cut - Extra-long cut
- Automatic in-sequence cuts
- Trimming
|
|
Bewo's automatic saws are built for strength and stability to guarantee high levels of production and durability over many years. Bewo offers 4 models: the SCF Quatro for high quantities and speed, the FCH, the ECH for heavy profiles and large dimensions, and the DCH, with its unparalleled speed.
|
|
|
|
|
|
SA-76NC ln-line
Extreme Speed Tube Cutting and Chamfering machine
HIGH PRODUCTION, FLEXIBLE and I2® SYSTEM
SA-76NC
The new SOCO SA-76NC tube cutting machine brings you the latest technology in tube cutting systems. This metal saw machine equipped with a 6.5/8.5/12.5 meters BTM ( Bundle Loading Magazine ) and a 2 / 3 / 4.5 meters output gate, the SA-76NC tube cutter offers unparalleled tube sawing output for tubes and pipes.
Together with SOCO control system, Touch Screen and i2® ( Intelligent Interface ) system, the SA-76NC tube cutting line offers precision and versatility, while allowing for quick setup times between different tube dimensions lengths.
SA-76NC in-line
Besides the standard tube cutting functions of SA-76NC, and the SA-76NC In-line may also be a part of complete Automation Cells for tubing. The working process is from Loading, Feeding, Pipe Cutting, Chamfering, Deburring , Air Clearing and Tube Collecting. It brings time saving as well as higher throughput and performance.
Keywords
Pipe Benders,Tube Benders,Tube Bending,tubing bender,bending pipe,Pipe Bending,Bending pipe Machine,Tube Bending Machine,Pipe Bending Machine,tube cutting,metal saw,Circular Saw,Sawing Machine,tube cutter,pipe cutting,pipe cutter,circular sawing machines,Saw blades,chamfering machine,deburring machine
|
|
TK 133 CNC
Semi-automatic single-head cutting machine
Construction Features
Blade dia 500 mm to get very good cutting capabilities
Full protection with complete cover and front automatic lowering closure
Strong cast iron head
Head powered double tilting from -45°/90°/22°30’ by means of a direct current motor managed by a positioner
Oleo-pneumatic blade advancement
Blade motor revolutions 2800 rpm
TK 137 - TK 138
Single-head cutting machine with upwards blade
Blade dia 600 mm to get very good cutting capabilities
Oleo-pneumatic blade upstroke
Spray lubrication
Full protection with complete cover
Chips collection drawer
Optional
RH side tables 801/E, 801/D, 802/M, 802/F
LH loading tables 802/SX, 85400 (only for TK 138)
Pusher (only for TK 138)
TK 137 For all cuts between 20°/90°/-20°
TK 138 It cuts at 90°. If associated to a pusher it can execute in-sequence cuts
|
|
Features of Hydraulic Matellic Disc Saw Machine:
-This series of machine adopts hydraulic drive. It’s especially suitable for thick material.
-Blade moves on perpendicularly slide way which have more stable cutting.
-Adopt two sides and two direction clamp which make workpiece stable.
-The precision is higher than band saw and bow saw with low noise and low pollution. The section is free of burrs and powder without secondary processing.
-The machine head can be adjust to the left and right for beveled cutting and grooving cut.
-Strong water circulation cooling system insures the life-span of saw blade.
-Use pole changing motor with two speeds which can meet the requirement of different metallic material cutting.
|
|
|
|
|
|
FA-110NC
Fullly Hydraulic Circular Sawing Machines
PRODUCTIVE, FLEXIBLE AND HIGH ACCURACY
Tube Cutting Machine Features:
NC Line
+ Touch Screen System for Tube Cutting Settings
+ Multiple Cutting Lengths per Tube
+ Servo Controlled Feeding
+ Vertical sliding saw head ensures stable and precise pipe cutting
+ Backlash eliminating device prolongs the life of saw blade
+ Counter Balance System for maximum stability through the entire cut
+ Patented Floating Feeding Carriage for superior tube cutting length accuracy and smooth material handling
+ Rigid and reliable clamping vise provides secure material holding
+ Automatic lubrication system maintains good work performance
+ Circulating cooling system results in smooth cutting surfaces and longer blade life
+ Electronic Saw blade protection cover for safety operation
+ Built-in chips tray for convenient cleaning and maintenance
Keywords
Pipe Benders,Tube Benders,Tube Bending,tubing bender,bending pipe,Pipe Bending,Bending pipe Machine,Tube Bending Machine,Pipe Bending Machine,tube cutting,metal saw,Circular Saw,Sawing Machine,tube cutter,pipe cutting,pipe cutter,circular sawing machines,Saw blades,chamfering machine,deburring machine
|
|
Board divide center Logicut. New screen operating with touch screen.
Type 2000
cutting length on request
|
|
Numerically controlled copy router with -90°, 0°, +90° and intermediate angles section rotation for working on 3 sides and quick release spindle for ISO30 cone. Z axis manual down feed with position display. The machine is manufactured in accordance with CE regulation.
|
|
|
|
|
|
The TS72 CNC cutting line is able to cut four different programmable lengths out of the same bar unloading in 4 different positions. Brush deburring, in-line measuring, washing systems and collecting devices are fully integrated. All adjustments are CNC programmable as well as the working cycle starting from a bundle loader (up to 4000kg), with bar selection, cutting and unloading.
TS72 has a capacity of O.D. 8mm to 102mm with a max. cutting length configuration of 1500mm - 3000mm - 4500mm.
Main features:
* One CNC programmable length stop provide the best material optimisation of 4 different length cuts out of a single bar.
* Automatic and efficient programming not depending from the operator's skills.
* TS72's programming selects for the operator the optimum working parameters for the best possible machine performance, from a complete and proven technological database covering blade speeds and feeds for differing materials, saw blade selection and material feed.
* The cutting head construction with hardened and ground helical gears and automatic backlash compensation guarantees longer blade life and its full exploitation, low noise levels and the very best cut quality.
* The material feed system and vice geometry assure the most positive clamping of the material during the cutting cycle whether the material is thin wall delicate tube or tough thick wall tube.
* During the material feeding process, the material is lifted away from the vice bed and vice jaws to prevent the material surface being marked or scratched.
* Blade life, even under arduous cutting conditions, is much improved by micro-lubrication and by turbo refrigeration.
|
|
The circular sawing machine SC 45 by BELL is a perfect combination for the user who wants to saw the wood at the right length before splitting.
It is reliable and compact, a very good compromise among weight, size and log capacity, suitable for every kind of use.
One of the main feature is the wheels which allow to move the SC 45 very easily, another one is the telescopic rod which allow to load even longer wood logs, and the "set-size" rod which let the user saw all logs at the same length.
|
|
High performance cut-off units
You will obtain from us the most suitable cut-off units according to the profile or tubing form, material and line speeds.
Special merits: Outstanding cut-off quality and high cutting speeds.
High-Speed profile cut-off machine with synchronous linear motor
The TK 123.20 LA is designed for a flying operation in rollforming and tube welding installations with high rollforming speed or high part output. It is especially suitable for cutting small and thin-walled profiles and tubes with particular cutting quality. It achieves for example a speed of 200 m/min cutting aluminium window spacer bar profiles. Cutting short profiles a part output up to 100 parts per minute and more can be reached. The machine is also suitable for punching of profiles in flying operation. Cutting and punching can be done in combined or single mode.
|
|
Electropneumatic sawing machine with up-feed blade and automatic feeding device
|
|
|
|
|
|
High speed, flexible and extremely accurate
The TS72 CNC cutting line is able to cut four different programmable lengths out of the same bar unloading in 4 different positions. Brush deburring, in-line measuring, washing systems and collecting devices are fully integrated. All adjustments are CNC programmable as well as the working cycle starting from a bundle loader (up to 4000kg), with bar selection, cutting and unloading.
Main features:
* One CNC programmable length stop provide the best material optimisation of 4 different length cuts out of a single bar.
* Automatic and efficient programming not depending from the operator's skills.
* TS72's programming selects for the operator the optimum working parameters for the best possible machine performance, from a complete and proven technological database covering blade speeds and feeds for differing materials, saw blade selection and material feed.
* The cutting head construction with hardened and ground helical gears and automatic backlash compensation guarantees longer blade life and its full exploitation, low noise levels and the very best cut quality.
* The material feed system and vice geometry assure the most positive clamping of the material during the cutting cycle whether the material is thin wall delicate tube or tough thick wall tube.
* During the material feeding process, the material is lifted away from the vice bed and vice jaws to prevent the material surface being marked or scratched.
* Blade life, even under arduous cutting conditions, is much improved by micro-lubrication and by turbo refrigeration.
|
|
|
|
|
|
SUPER TECHNICS 350 SA
Automatic circular saw, robust, fast and precise cutting of metal profiles and solid materials: for professional use in maintenance workshops and low duty production.
Optional sawdisc Ø 350mm.
One way miter from (0° to 45°).
Three cutting speeds.
Mobile countervice.
Sawdisc breakage protection with safety clutch.
Adjustable cutting head downfeed speed.
SEMI-AUTOMATIC CUTTING CYCLE:
Manual vice adjustment through handwheel - semi-automatic start through pedal switch or control panel switch - the machine carries out a complete cutting cycle including vice locking, cutting head downfeed, cut, cutting head return and vice opening.
AUTOMATIC CUTTING CYCLE:
Bench vice and feeding vice manual adjustment - mechanical adjustment of the cutting length - semi-automatic start through pedal switch or control panel switch - the machine carries out a complete cutting cycle including vice locking, cutting head downfeed, cut, cutting head return and vice opening. Automatic material multi-feeding till the number of cuts programmed on the piece-counter.
|
|
You cannot afford to risk any cut-off compromise? DREISTERN cut-off machines operate with every type of cutting process. Whether you wish to use saw units, shear units or punch units, you simply exchange the cut-off unit and you immediately have the ideal cutting process at your disposal. It is not important whether you require fixed tube or profile lengths or frequently changing lengths.
You will certainly appreciate the high cut-off precision. You will discover one particular characteristic after many years. DREISTERN machines never seem to age. They are designed and built to endure many years of hard work.
|
|
K12-14MS, Metallurgical saw, 14" abrasive wheel. Great for Met labs! Contain the dust!
5 HP, 3 PH 1725 RPM TEFC motor.
External manual operation.
Dual moveable 4" screw vises.
Capacity 2-1/2" solid, 3" shapes.
Magnetic switch, low-voltage protection at switch, 24V.
Internal halogen light - 24V.
1" wheel arbor, 12" or 14" blade, (not included)
Dual coolant nozzles.
2200 spindle speed at 1725 RPM.
Flood coolant, 10 gal., 1/3 HP.
Dimensions L 39" x W 26" x H 60"
Enclosed wet cutting metallurgical saw.
Options: Power down feed #PH-14, Oscillation for large sections # OSC-14, door interlocks.
700 lbs.
|
|
TV21
AUTOMATIC 'V' CUTTING MACHINE
Automatic 'V' cutting machine LISI TV 21. Sawing machine for 'V' cuts on PVC profiles. Movable carriage with fix 45° inclination blades. Vertical adjustment of the working table. Manual adjustment of the cutting height by handle and reading on a millimeter rule. Two vertical pneumatic clamping cylinders.
|
|
|
Pendulum saw for cutting wide boards. Machine complete with a 500 mm diameter saw blade, two roller tables 2000 x 600 mm with open ends for an easy loading of the material to be cut, and two manual stops. On demand the machine can be supplied with the oil-pneumatic feed of the sawing group.
|
|
Advantages when compared with bandsaws:
·Higher cutting performance due to a 5 to 10 times higher feed rate
·Smaller foot print
For cutting sizes over 150 mm, bandsaws are typically more economical.
The differences are:
·Universal saws with vertical from the top or from the bottom of the table coming saw blade, suited also for miter cutting
·Production saws where orders are processed fully automatically without any personnel
·Mass production saws with very high output levels and extremely small cut piece tolerances.
|
|
|
Series of double mitre saws with right head fixed and left head mobile for cutting glazing beads. In the basic version the mobile head movement is driven by a handwheel complete with mechanical gauge to read the measurement. Available on request are the versions VIS with handwheel and digital display of the cutting length, NC with electronic positioner that can store up to 400 lines and NCT with numerically-controlled positioner connected via cable to an electronic gauge. All the models come complete with rotary table with mechanical locking devices for 90° and 45° angles right and left, two pneumatic clamps synchronized with blade descent and a glazing bead support on two levels for simultaneous cutting of two glass stops.
|
|
|
|
