Taptite 2000 eliminates the need for pre tapped threads, as they create their own threads on installation, therefore reducing pre-assembly costs.
Other advantages are low thread forming torques, High strip torques and High clamping forces, therefore offering a superior process-reliable fixing.
|
|
|
Remform® screws have been designed specifically for applications in plastics, with their unique thread profile, they offer low screwing in torques coupled with high strip torques make Remform® the perfect answer when looking for the right screw for plastics applications
|
|
Specifications
Sizes: #8 to 1/4"
Lengths: 3/4" to 3-15/16"
Head Styles: Flat and wafer
Drive System: Phillips
Point Styles: Types 3 and 4
Material: Carbon steel
Finishes: Phosphate or gray Stalgard®coating
Features & Benefits
Eliminates costly pre-drilling of wood
Broad selection of sizes
Can be used with steel up to 5/16" thick
Gray Stalgard coating provides 1000 hours of salt spray resistance and was developed for use with ACQ treated lumber with retention levels no higher than 25 PCF
|
|
|
|
|
|
|
Substitute the drive code for the ? and the length for the L In the part no. to specify the exact part required. The 30 deg. Flank angle and recessed core diameter of these thread forming screws for plastic have been developed following theoretical appraisal, exhaustive calculations and final proof testing. The 30 deg. Flank angle produces low radial forces when engaging the plastic, therefore resulting in less radial stresses, in other words the hoop stresses in the plastic bosses are less than those experienced with conventional screws. The recessed core geometry provides the ideal flow director for the displaced plastic, encouraging a uniform flow to fill the pitch of the screw without material jamming. This results in the maximum amount of plastic being engaged providing higher sheer loads due to the increased bearing depth of the thread. A combination of the above and the ease of penetration of the 30 deg. Flank angle through the material, encouraging plastic flow, reduces the torque required to drive the screw in. This therefore increases the margin between drive and stripping torque which minimises the potential of stripping during installation. The optimum pitch and maximum fill features provided by the recessed core results in a large area of plastic to be sheered prior to screw failure in tension. This creates a high resistance to pullout loads.
|
|
