Whatever you want from a Bulk Materials cut-off valve you’ve got it with Clyde Materials unbeatable Dome Valve® - the cost effective valve solution.
The Clyde Dome Valve®, widely regarded as the original and best material handling valve in the world, offers exceptional life from only a single moving part. The Dome Valve® is recognised as a low maintenance, long life solution that can last at least 1 million cycles between maintenance inspections. It has the ability to cut through static or moving columns of material and is pressure-tight, ensuring a consistent pressure tight seal is created when the valve is in the closed position, but in the open position it provides an unrestricted full bore opening for the best product flow characteristics possible. The Dome Valve® can also be used as a line, vessel or reactor isolation valve.
The Dome Valve® enhances other technologies from Clyde Materials Handling, a leading provider of pneumatic injection, conveying, materials handling & vacuum cleaning solutions.
The solutions we create for our customers generate many benefits and are backed by three decades of domain knowledge, expertise and a track record of generating exemplary success.
Dome Valve® sold in the United States under the trade name ‘Spheri Valve’
|
|
1. Made only from rust proof and acid resistant stainless steel.
2. For a wide range of applications in all industries.
3. No pressure drop due to full flow bore.
4. Easy operation, even under high pressure.
5. Long life due to exchange seals.
6. Individually works tested.
|
|
Stainless steel ball valve
DN:1/4"-8"(DN8-DN200)
Heat-resisting, corrosion-resisting, oil proof.
Material:S.S.304/304L, S.S.316/316L
Standards:DIN,SMS,ISO,RJT,3A,IDF
Thread standard: BSP,BSPT,DIN2999,NPT
Working pressure:0-6.3Mpa,0-1000PSI
Temperature:0-100 degree
Minimum order: 1 pc
Applications: Food, Dairy, Beverage, Beer, Wine, Pharmacy,Biology,etc.
|
|
ART. 424
2-WAY FULL-BORE THREE PIECE CASTED STAINLESS STEEL BALL VALVE, THREADED-ENDS, BUTT WELD OR T-CLAMP
ART. 429
2-WAY FULL-BORE THREE PIECE CASTED STAINLESS STEEL BALL VALVE, THREADED-ENDS OR BUTT WELD
ART. 434
2-WAY FULL-BORE STAINLESS STEEL BALL VALVE, DIN 11851 FEMALE THREADED-ENDS
ART. 445
3-WAY FLAT BODY FLANGED STAINLESS STEEL BALL VALVE, “L” PORT
ART. 448
3-WAY FULL-BORE THREADED-ENDS STAINLESS STEEL BALL VALVE, “L” PORT
ART. 450-451
3-WAY FULL-BORE THREADED-ENDS STAINLESS STEEL BALL VALVE, “T” OR “L” PORT
ART. 460-461
3-WAY FULL-BORE FLANGED STAINLESS STEEL BALL VALVE, “T” OR “L” PORT
ART. 464-465
3-WAY FULL-BORE STAINLESS STEEL BALL VALVE, “T” OR “L” PORT, DIN 11851 FEMALE THREADED-ENDS
|
|
TORK Electric actuated valves are two series
1. Electric actuated ball valve
2. Electric actuated butterfly valve
TORK Electric actuated ball valve,T-EAV900Serie, are two main parts, a quater turn,90 degree turn electric actuator and ball valve. Out put torque value of electric actuator (Nm) , must be more 25%
than out put torque value of ball valve (Nm).
application: ball valves,butterfly valves,dampers,plug valves , on-off or proportional control
|
|
|
Industry imposes numerous constraints of operations. That is why FG Inox proposes you a range of valves with electrical or pneumatical actuators simple or double effects, 2 or 3 ways (L or T) from ND 15mm to 50mm.
|
|
DESCRIPTION
Solid ball valve for high performance tasks. All ball valves are CE/Atex approved and pressure tested. Can on demand be delivered with certifi cate EN10204 - 3.1.
Bold circle diameter and face to face dimensions of the body is equal to Worcester, Valtac and Mecafrance from DN15 to DN65 RB. This means that our type 1210/1310 can be mounted between existing end caps.
Antistatic stem with pyramid segment. Stem with 45° face of contact. This means larger contact area together with reinforced stem seat and a surface quality on Ra 0,2 ~ 0,3 um. These advantages will provide the posibility of a very long
lifetime.
PTFE with 25% carbon fi ll are used for seats and pyramid segment. This material is very suitable for high pressure and temperature and it is even more resistant to wear than traditional PTFE.
|
|
1-Piece, Instrumentation, 40 Series Ball Valves
1-Piece, Instrumentation, 40G Series Ball Valves
2-Piece, Instrumentation 33 Series Ball Valves
3-Piece, Alternative Fuel Service, High Pressure (up to 6000 psig [413 bar])
3-Piece, Instrumentation, High-Pressure (up to 10 000 psig [689 bar]), 83 Series Ball Valves
3-Piece, Multipurpose SK Series Ball Valves
3-Piece, Process / Instrumentation, 60 Series Ball Valves
|
|
Ultra Purity
Product standards:
Technical indicators:
Working pressure: 10kg/ c
Durability test: 5000 cycles
Inboard leaking rate: 1x 10-9 atm cc/sec
Internal leaking rate: 1x 10-9 atm cc/sec
Outboard leaking rate: 1x 10-9 atm cc/sec
Performance demand:
The leaking rate meets the SEMI F1 standards
under the technical indicators circumstances
mentioned above.
|
|
|
|
|
|
Any leakage of gas or liquid has to be avoided at all cost. SOMAS ball valve is designed to take care of this issue. The valve is a full bore, flanged ball valve with cylindrical bore made in dimensions from DN 25 to DN 400. The valve is made from stainless steel with spring loaded seats for good tightness, even at low differential pressure.
The valve ball is hardchromed as standard, but can also be supplied with Hi-Co coating. The valve can be supplied with actuator and accessories for manual operation, on/off or control applications.
Ball valves also in 3-piece form
SOMAS 3-piece full-bore ball valves are mainly intended for use as manually operated valves or remotely actuated on/off valves. The ball valve meets ISO standards.
The valve is available with threaded ends, welding ends or flanges. It is also possible to combine different types of ends.
SOMAS 3-piece full-bore ball valves are equipped with seats of two materials. Fibreglass-reinfoced PTFE as standard, or carbon-filled PTFE adapted for steam.
|
|
| ... products without technical information |
| |
|
Control valves for the food processing industry made of polished stainless steel with cavity-free body, PTFE packing or diaphragm seal and connection to a steam or sterile fluid line (optional). The valves comply with FDA and EHEDG regulations and can be sterilized using CIP or SIP.
|
|
Aseptic diaphragm valves, stainless steel
DN 4 – 150; valve bodies in stainless steel (investment cast, forged, block material) and special materials; surface finishes down to 0.25 µm Ra available with or without electropolishing; 2/2-way bodies (2/2-way valve), T-valves (3/2-way valve), tank valve (B600) , GMP-SAP valve configurations, (W600), multi-port valves (M600); connections to ISO, DIN, SMS, ASME BPE, JIS etc.; manual, pneumatic and motorized operators
|
|
Stainless steel diaphragm valve
Valve body material:S.S.304/304L, S.S.316/316L
SPECIFICATIONS:1"-6"
STANDARD:ISO,DIN,SMS,IDF
PRESSURE DURABILITY:<5BAR
TEMPERATURE DURABILITY:+180 degree
WORKING PRINCIPLE:Remote-controlled operation by the driving gear or manual operation by the handle.
Our factory specialized in producing all kinds of stainless steel products. The products use for petroleum,pharmaceutical beverage,dairy production equipments and other industries.
|
|
KZValve's 3-piece, SS, two way, motorized ball valves are the most versatile, reliable and affordable valves on the market today. Complete with a swing out style design, our valves also include a manual override capable bracket and coupling. The photo here is shown with KZCO's EH5 Heavy Duty actuator.
VALVE FEATURES:
- Valve sizes from 1/2" to 2"
- Valve Body: CF8M SS
- Ball and Stem: 316 SS
- Body Seals: EPDM
- Max PSI 1000 @ 70F
- PTFE seats and stem seals backed by a durable Viton O-ring
- Manual override capabilities
ACTUATOR FEATURES:
- High quality, durable actuator housing rated NEMA 6P for waterproof applications and NEMA 7D for Ignition Protection applications
- 12/24 VDC and 24 VAC operation available
- Tough Aluminum gear box with metal gears
- Waterproof wire plug connectors
Coupled with the field proven KZValve EH Series actuators, these units can power through jobs leaving solenoids in the scrap pile.
Consult our Engineering or Sales staff for application assistance.
|
|
|
Streamlined flow valves, outside screw with bellows, maintenance free, manufactured of stainless steel PN 40.
|
|
WEKA Stainless Steel Valves are based on know-how meticulously acquired over years of development and manufacturing of critical stainless steel components for industry and science. WEKA constantly works with customers to develop new solutions for special applications and process requirements. Our technological strengths have resulted from our wide and deep applications experience in specialized fields.
WEKA Stainless Steel Valves are widely used in chemical process industries, hydraulic power equipment, thermal power plants, petrochemical industries, cryogenic processes of liquid air separation plants, and cryogenic and high-pressure gas purification processes.
WEKA Stainless Steel Valves are the preferred choice for applications involving temperatures extremes (down to -196 °C, up to 400 °C) and high pressures (up to 700 bar).
|
|
|
|
|
|
After a thorough test concerning the needs within the various fields where technical application is carried out, e.g. the biotechnology and semi-conductor industries, as well as pharmaceutical, food and medical processes, the Ratti snc industry has projected a new diaphragm valve, which allows for clean and sterile handling of the fluid.
Through the research of an innovating internal design, a system has been carried out, it includes an option for an open and a closed valve, that is, internal inclined contact surfaces to drain the fluid.
This valve makes the cleaning process easy, thus foreseeing a minimization of empty volumes and the tinning of the fluid areas.
The valve is completely autoclavable, the body and the external parts are totally manufactured in AISI 316 L, while PTFE support bars file the handle and the diaphragm.
The valve is manufactured in the following dimensions: from 1/2" to 3", which include connections according to the BS-OD 4825 codes.
Whenever the pieces are traced for validation, the valve is laser identified, including the production series number, and it is furnished, upon request, with the chemical analysis certificates of the materials, as observed in code EN 10 204.1B, and in superficial finish checking.
|
|
two pieces, three pieces, two ways or three ways, threaded or to weld, butterfly valves, knife gate valves,...
we offer a complete range of products to offer you the right answer to your needs.
|
|
| ... products without technical information |
| |
PKV-06 stainless steel pilot controlled non-return valve
Application
PKV-06 is used as a static load holder.
Specifications
The PKV-06 valve, made of stainless steel W.St.1.4301, allows unrestricted flow from V to C ports and blocks flows in the opposite direction until pressure is applied on the pilot port.
|
|
DESCRIPTION
Very reliable and simple construction.
Self aligning between flanges.
Very flexible and low weight due to the small face-to-face measurements.
Easy mounting because of the eye bolt on top of the valve.
Large field of application due to many options.
Disc and hinge cast as one.
Protected o-ring. The o-ring is placed in the body protecting it from fl ow, detachment and tear.
|
|
Liquids, steam and gases - SOMAS check valves are suitable for all of them. This valve is designed and made for clamping between flanges. SOMAS provide two types, with or without a spring, both made from stainless steel to meet the demands of our customers.
High capacity and short closing time are the check valves great advantages. The closing time is short due to the seat angle in the body, which makes the check valve especially well suited for liquids, steam and gases. Another advantage of the check valve is that it can easily be disassebled by the customer for cleaning or shaft replacement.
|
|
TYPE GATE, GLOBE, CHECK
SIZE RANGE 1/2” TO 24”
BONNET TYPE BOLTED
MATERIAL CF8, CF3, CF8M, CF3M, CF8C, CF10, DUPLEX, INCONEL,
MONEL, HASTELLOY …etc
PRESSURE RANGE CL 150, 300, 600
ENDS BUTT WELD
FLANGE: ANSI, JIS, DIN
OPERATOR HANDWHEEL, CHAINWHEEL, BEVEL GEAR, PNEUMATIC,
HYDRALIC, MOTORIZE
|
|
| ... products without technical information |
| |
|
|
