Stools of safety
Use - Individual and professional for the operations of "picking", to be always "with the height" and in safety, in narrow alleys: stores, files, libraries, warehouses.
Construction - weld steel tubular Chassis.
Crawl of safety on the left side of the scale of access. Plate and steps in multiplis with phenolic joining, non-skid aluminum alloy sheet with checkerworks or out of grating, depth 150mm approximately.
Railing on 3 sides, made up of a handrail out of tube, a stringer with middle height and a plinth of 150mm. Shelf of consultation on all the models.
Bearing - Train of bearing consisted a lifting framework equipped with 4 casters: 2 fixed and 2 swivelling gone up with polyamide ERNYL® wheels of Ø80mm. Protection - Oil-based paint. Charge with maximum use 150Kg.
Operation - Ordering of the lifting framework by a lever which, drawn and maintained with a hand with the slope of safety, puts the 4 wheels in contact with the ground and raises the stool. This one can then roll and be operated without sorrow. The stool being brought to the desired place, it is enough to release the lever: the 4 feet rest then on the ground and stability is total, the train of automatically being retracted bearing.
The user cannot thus climb the steps without releasing the control stick, which ensures a total safety.
|
|
