Trolley or rail applications
The iLift ™ mounts to most standard trolleys and rail profiles and allows seamless end effector interface. It can also be configured with the Cobotics iTrolley ™ to create multi-axis Intelligent Assist Device (IAD) systems.
Interface with rigid arm configurations
For added versatility, the iLift can also be configured to provide vertical lift for rigid arm systems.
|
|
Single Girder Bridge Cranes - XMS
The XMS Single Girder Bridge Crane is a flexible solution for handling light loads within larger areas. The bridge and trolley move smoothly and quietly due to the enclosed XM profile. This XM profile is also very strong and allows long suspension distances.
Load range 125 - 1600 kg
Three different configurations:
Articulated
Rigid for mainly motorized version
Low headroom to maximize hook clearance
Hand operated or motorized trolley and bridge
Easy expansion
|
|
|
|
|
|
Ceiling Mounted Work Station Bridge Cranes are an excellent solution when a work area must be clear from any support structures that may interfere with operations. These systems require a building with an adequate overhead structure to safely support the load of the crane. Customers can install multiple bridges along one set of runways and greatly increase their productivity. Available in steel, aluminum, and stainless steel. Capacities are available from 150 - 4000 lbs with overall bridge lengths up to 34 ft.
- Enclosed track design is three times easier to move than traditional bridge cranes
- Trussed steel track permits longer spans which allows more flexibility in layout
- Aluminum track for use where lower bridge weight and easier movement are required
Features:
- Capacities up to 4000 lbs. with multiple track profiles and spanning capabilities
- Pre-engineered modular kit designs for easy expansion and relocation
- Enclosed track design helps keep out contaminants and dust
- Cold rolled steel with high strength, low weight per foot ratio for smooth rolling surface for reduced rolling resistance
- Versatile, and can perform a wide variety of material handling functions
- Economical enough to be devoted to individual work stations
- Ease of installation for reduced installation time & costs
- Can increase worker satisfaction
- Encourages safe work practices
- Rapid return on investment through increased productivity
|
|
Ceiling Mounted
Ceiling Mounted Bridges are some of the creative and well engineered Hoisting Solutions that JMF can provide. We will help you solve all your operational needs while simultaneously maximizing plant-floor utilization.
|
|
STAHL CraneSystems's single girder suspension crane needs very little space. It runs on the lower flange of the crane runway which is mounted directly on the ceiling and achieves the greatest utilisation of space possible. In particular in the case of restricted production areas, this permits optimum utilisation of the width of the room.
The lifting capacity of STAHL CraneSystems single girder suspension cranes ranges up to 10,000 kg. Suspension cranes in neighbouring bays can be connected; the crane interlock functions completely free of jolts and knocks. The hoist can travel onto the neighbouring crane together with its load and can reach any destination in the interlocked system.
|
|
|
The ABUS HB-System is a modular designed crane system with load capacities up to 2 t SWL. The system can be adapted to the conditions and dimensions of almost any application and reliably mounted on a wide range of different ceilings can easily be extended any time allowing it to grow with your business.
|
|
|
Standard cranes are largely constructed of standardised component assemblies. They range from single-girder cranes with a 1 ton load capacity to large double-girder cranes with a maximum load capacity of 80 tons. Standardised sub-assemblies enable you to benefit from series manufacturing methods, which guarantee consistently cost-effective and high-quality results. Extended standard cranes provide tailored solutions that go far beyond the already wide range of standard designs.
|
|
Our manual conveyors can be set up as transfer conveyors with small travelling cranes. Small travelling cranes are highly flexible and achieve significant space gains. Primarily used at paint facilities or for work station improvement, travelling platforms allow to combine both handling and sorting needs.
Fixed rails installed on either side of the transfer conveyor or conveyors are used for inventory.
The user of the small travelling crane can then choose from the inventory the part that he wants to process.
|
|
|
|
|
|
- Demag Standard Single Girder Crane products are designed to provide the optimal combination of performance and price.
- Our girder construction utilizes two types: WF beams or our unique box girder design.
- WF beams are used for cranes up through 10 ton capacity and 60 foot spans.
- Box girders are used for spans greater than 60 feet up through 10 tons and all spans up through 15 ton capacity. The design of the box girders provide for maximum strength with minimum weight. while modular end trucks allow for on-site installation.
- Standard bridge cranes include 2-speed selection for hoist and travel drives. Standard option packages include but are not limited to: variable frequency control, 2-speed variations, remote control, dual hoist arrangements and outdoor protection.
- Regardless of either girder type, our unique overhead crane design utilizes our modular end trucks and exclusive end truck girder connection. These features translate into savings based on increased performance and service life or our equipment. Additional savings are based on our ability for on-site installation which equates to reduced installation time and freight costs.
|
|
For the lifting, replacing and the exact position is there, dependent of the consumer target, a choice of two cross crane designs.
The first is a cross crane construction which bridge crane is confirmed at two extended running gears, who extremely become accurate in the both longitudinal beams. That is why the bridge crane stays in all the circumstances fixed on both cross tracks. This kind of type crane is suitable for integration in a total monorail circuit or for utilization above a bath progression.
The second is a cross crane construction, which is mounted at two short running gears. The bridge crane within a load carrier has no problem to run around an obstacle. That is why it has the name articulated crane.
Both crane constructions are builded from standard components and simply to mound, to extend or to change with bolted joints.
The carrying capacity is step by step builded from 100 until 1000 kg.
|
|
- Demag Standard Single Girder Under Running Crane products are designed to provide the optimal combination of performance and price.
- Our girder construction utilizes two types: WF beams or our unique box girder design.
- WF beams are used for cranes up through 10 ton capacity and 60 foot spans.
- Box girders are used for spans greater than 60 feet up through 10 tons and all spans up through 15 ton capacity. The design of the box girders provide for maximum strength with minimum weight. while modular end trucks allow for on-site installation.
- Standard bridge cranes include 2-speed selection for hoist and travel drives. Standard option packages include but are not limited to: variable frequency control, 2-speed variations, remote control, dual hoist arrangements and outdoor protection.
|
|
Underhung and Under-running cranes are two ways to refer to the same type of crane. With underhung cranes, the end trucks ride on the bottom flange of the runway beam rather than on top like other types of overhead cranes. With an underhung crane, the runway beam is often suspended from the roof, which eliminates the need for extra floor columns to support the runway. This can be advantageous if floor space and the need to reduce obstructions is a major issue in the factory or warehouse. An underhung crane may even be appropriate with sloped ceilings or multiple crane systems.
Underhung cranes can be either single girder or double girder. Double girder underhung cranes are often suitable for longer span or higher capacities.
However, underhung or under-running cranes are typically limited to lighter capacities (usually about 10 tons maximum).
|
|
This typology of overhead bridge crane is used when the rails don't permit the bearing of the end carriages on the top position.
The travelling units of the bridge crane are appended to the rail ways.
The crane is constructed around the travelling units in order to maximize the space usage and minimize the crane overalls.
The Bonfanti's cranes are developed and produced in the respect of the ISO 9001 norms (TUV)
Main features:
- CE certification
- Hoisting capacity: up to 2 metric ton
- Span: up to 12 meters
- Suitable for installations under ceiling
- Hoisting unit: High quality electric hoist
- Possibility to manage the traveling movements with inverter control
- Pendant push-button or remote control
|
|
|
The lifting capacity of STAHL CraneSystems single girder suspension cranes ranges up to 10,000 kg. Suspension cranes in neighbouring bays can be connected; the crane interlock functions completely free of jolts and knocks. The hoist can travel onto the neighbouring crane together with its load and can reach any destination in the interlocked system.
|
|
STAHL CraneSystems is the specialist for high-performance cranes in the upper S.W.L. range. This naturally includes the double girder overhead travelling crane with an S.W.L. of up to 160,000 kg and a span of up to 30 m. Large, unwieldy loads can be handled extremely safely and accurately. This is particularly true when several hoists equipped with a precise electronic synchro control are used in tandem operation.
The double girder overhead travelling crane can be integrated into planned or existing buildings utilising special installation variants. The top hook position brings particular advantages on a double girder overhead travelling crane. The load hook is lifted between the crane girders. Additional requirements such as maintenance platforms on crab or crane, cabins or higher crane travel speeds can be achieved quickly and easily.
|
|
When it is a question of the safety of man and machine in hazardous areas, STAHL CraneSystems is pioneering, forceful and consistent.
The STAHL CraneSystems GmbH is regarded as a specialist for explosion protection world-wide. With our experience and our know-how from many decades, our own fundamental research and our own R&D, with approvals from the Federal Physico-Technical Institute (PTB) and other test institutes in many countries, STAHL CraneSystems occupies a special position in this field. All components of a crane or hoist are strictly from our own production, from motor and brake to control and switchgear.
This ensures optimum, high-quality explosion protection. The new rigorous ATEX regulations on mechanical explosion protection are of course met. STAHL CraneSystems was the first manufacturer of overhead material flow technology to implement the ATEX 100a directive 94/9 in its production programme.
|
|
STAHL CraneSystems developed the innovative small crane technology KT 2000 as early as 1984. This high-quality modular system is specially designed for the S.W.L. range up to 2,000 kg.
With a single rail size, overhead monorails, suspension and overhead travelling cranes can be assembled individually and economically. Straight and curved sections and crossovers, switch points and turntables are assembled with plug and bolt elements and can thus be modified if necessary to suit new, individual production requirements.
STAHL CraneSystems's LCS small crane system has been on the market since 2004. Constructed as a simple modular system for plug and bolt assembly, it is designed for the S.W.L. range up to 1,500 kg or 2,000 kg.
|
|
The Eurosystem overhead handling system can be perfectly adapted to your work-site layout or production line and offers a variety of possible configurations.
Eurosystem offers a wide range of possibilities: monorail system, runway, single-girder overhead crane, double-girder overhead crane, single or multiple track systems with changes of direction.
|
|
ABUS Overhead Travelling Cranes lift loads up to 100 tonnes SWL and transport them to any point chosen within the building area. They are available in 4 different versions for a variety of applications: Single Girder Cranes, Double Girder Cranes, Underslung cranes and Single Girder Wall Travelling cranes.
|
|
|
|
|
|
Handling Equipment
Cranes and other lifting equipment are some of the traditional products made by UNEX a.s. UNEX offers a wide variety of lifting equipment - from simple hoists to sophisticated devices manufactured according to customer requirements including general repairs and renovation of all types of cranes.
Manufactured types of cranes:
* Bridge cranes - chiefly used for handling loads in manufacturing process
* Portal cranes - used for handling goods in trans-shipment centres
* Assembling jib cranes - used for assembling and disassembling equipment, devices, machine chambers, power stations etc.
* Port cranes - used in ports for handling all kinds of goods
* Special cranes - key-ready cranes at the customer's request
Engineering characteristics at the customer's request:
* Movement: stationary, movable, revolving
* Actuating: manual, electric, hydraulic
* Construction: box, frame
* Operating: wireless (radio) or infrared remote control, hanging push-button panel, possibly from a cabin or a crane cage
* Power supply: trolley wire (wire, track, angle, covered), cable drum
When manufacturing and repairing cranes we use components from world-established manufacturers in the field of power supply systems (Wampfler, Vahle), and in the field of updating and operating systems with frequency converters (Nord, Lenze, Telemecanique).
|
|
STAHL CraneSystems's single girder overhead travelling crane with an S.W.L. of up to 16,000 kg is flexible and astonishingly adaptable. It runs on the top flange of the crane runway. Its use enables rational, economical material flow solutions to be achieved even in low or small buildings.
The existing space can be utilised to the full by using various installation variants. The crane bridge girder can be individually adapted either -flush at top- (EL-A), -flush at bottom- (EL-B) or -raised up- (EL-C). A clearance of approx. 100 mm to the ceiling is specified for single girder overhead travelling cranes. Particularly in low-ceilinged rooms, this permits minimum headrooms and optimum adaptation to the building profile. The height of lift can be increased even further by using an STAHL CraneSystems cantilever crab.
|
|
|
It makes it possible to empty one or more pits, to manage one or more products in a surface of storage, and to supply one or more hoppers in a completely automatic way. Current flows until 100 m3 per hour.
|
|
|
The KBK crane construction kit is a system designed for building a wide variety of cranes and suspension monorails from only a few standard components. Various profile section sizes can be combined within a crane installation to achieve the optimum configuration. This is demonstrated by installations tailored to meet specific application requirements, from simple suspension monorails to complex area-serving material flow solutions. Whatever the variant, one factor always remains the same: the cranes utilise the free space beneath the ceiling, thus leaving valuable floor space free for other productive activities. Manufactured in large series, KBK components offer high functional reliability, a long service life and good value for money.
|
|
|
|
|
|
OUR LIFTING AND TRANSPORT SYSTEMS
Our activity started by focusing on simple lifting systems:
* STANDARD SINGLE AND DOUBLE GIRDER BRIDGE CRANES
* STANDARD AND SPECIAL GANTRY CRANES FOR MOVEMENT OF CONTAINERS
* ELECTRIC WINCHES
* PATHS AND INFEED POWER LINES
* COLUMN AND PILLAR JIB CRANES
* SUSPENDED SINGLE TRACK LINES
With acquired experience, our wish to grow and diversify our production has pushed us to increase our range of plants, with the objective of service more and more the increasing demands of the market:
* FLAMEPROOF BRIDGE CRANES
* STACKING BRIDGE CRANES
* SPECIAL BRIDGE CRANES WITH TELESCOPIC AND FIXED SPREADERS FOR THE MOVEMENT OF CONTAINERS CAPACITY 50 TONS
* BRIDGE CRANES WITH EXTRACTABLE LOWER GIRDER FOR LATERAL STOCKING
* SUSPENDED CRANES, ACCESSORIES
With these plants we believe to have collected a large consent from the national market, as well as several cranes supplied abroad, by supplying in terms of quality and performance as requested by our clients.
Our offers for each specific product are also completed with a service for installation, start-up and testing on site, as well as an assistance and maintenance service
|
|
JDN air cranes in standard version are suitable for working in hazardous areas.
The delivery programme comprises explosion-proof
- overhead cranes
- suspension cranes as well as
- slewing cranes
- which can be adapted to your individual demands as complete special installations are our speciality.
Different JDN Cranes in Detail
- overhead cranes with one or two main girders
- suspension cranes also with minimised headroom - with special low headroom trolleys
- slewing cranes
- cranes with mechanically coupled synchronised hoists
- cranes with parallel hoists
- carrying capacities up to 50 t
- with spans up to 18 m
Higher carrying capacities and spans on request.
|
|
|
|
|
|
Don't settle for a standard crane if it doesn't fit your application. At North American Industries, our engineers take great pride in their ability to provide customers with the crane that best meets the requirements of their application. North American Industries builds cranes, providing advice on the features and benefits-at times after on-site consulting--and then quoting sensible options from which to choose.
To find the right crane, decisions must be made about speed, capacity, lift, and options that will make it the best possible fit for your project.
Many times it takes only a small modification of a standard configuration to make a great improvement on the crane's performance for a particular job. Other times, it has proven best to redesign the complete handling system to achieve the desired results.
Our Qualifications for Building Customized Cranes :
We have hands-on experience in very demanding environments requiring special material handling. For example, we can design cranes for high duty cycles, tight dimensional constraints, precision, long loads, and extreme weather conditions. See the "News" section of the website to read about some specific projects for which NAI designed cranes.
In addition, we have met the unique specifications of government and federal agencies.
|
|
Double Girder Bridge Cranes - XMD
The double girder construction of the XMD enables this crane to handle bigger loads and longer spans than the single girder design. The XMD has a lower construction height than the XMS, thus maximizing the available workspace. The XMD crane incorporates all the features common to the XM profile.
Smooth and silent load handling and long suspension distances
Load range 125 - 2000 kg
Three different configurations:
- Articulated
- Rigid for mainly motorized version
- Low headroom to maximize hook clearance
Hand operated or motorized trolley and bridge
Easy expansion
|
|
Twin girder crane
A twin girder crane system is the heavy-duty choice. The twin girders are welded together in a triangular construction to stabilize operation when handling loads up to 1500 kg. The twin girder crane is optionally equipped with motorized trolleys to automate the traveling motion of the girder and/or hoist. The two-speed motorized trolleys can be equipped with a frequency converter for more options.
|
|
|
|
|
|
Products for Hazardous Environments
Konecranes offers a competitive and comprehensive range of explosion proof cranes and components. All strategic components, such as wire rope hoists, chain hoists, belt hoists, travelling machineries, end carriages and crane controls are designed and manufactured to ensure the highest safety level required in hazardous atmospheres in chemical and petrochemical plants, oil refineries, gas power plants, waste water treatment plants, paint shops etc.
Konecranes explosion proof cranes cover range from low capacity jib cranes up to high capacity double girder process cranes. Konecranes Ex industrial cranes are available in single and double girder construction using profile or fabricated box girder design. Different main girder connections are used to tailor the crane to exactly meet the individual application requirements.
Loads up to 80 tons (higher capacities upon request)
Single girder, under running and double girder cranes
Ex proof classification EEx de IIB T4 or EEx de IIC T4
Read about technical and operational benefits in the wire rope hoist section
|
|
Konecranes offers solutions for all lifting needs from High Capacity Service Duty Cranes to Heavy Duty Process Cranes, including modular cranes and tailor-made lifting solutions. Konecranes' knowledge of industrial processes and products of proven quality makes it easy for our customers to find optimal solutions for their lifting needs.
Heavy duty industrial cranes provide solutions for two main types of applications:
Service Duty Cranes: For installation and support tasks, which sets the highest capacity requirements:
- High lifting capacity
- Compact size (effective space utilization)
- Low wheel loads and total weight
- High accuracy for load positioning
- Minimised need for crane maintenance
Process Duty Cranes: For continuous material handling, which sets the highest performance requirements:
- Frequent operating cycles
- High speeds
- Automation and/or special control systems
- Difficult operating environment
- In-built prevention for load swinging
|
|
|
|
