| The CT224 consists of a 12-Channel Temperature Monitor and MincoSoft™ CT224 Software. It is the next generation in temperature monitoring equipment from Minco designed to meet the needs of electric machinery protection. The 12-channel scanning capability, standard RS485/RS232 interface and Windows-compatible software utility for system configuration and data logging provide overtemperature and undertemperature protection and critical feedback to safeguard expensive machinery. |
|
Turbine Sentry - System Overview
An overview of the complete system and how this system is of benefit to gas turbine operators.
A typical system comprises three parts:
Blade Sentry - Measurement Pyrometer
The non-contact thermometer is mounted through the gas turbine casing and measures the temperatures of individual rotor blades.
Rotor Sentry - Data Acquisition System
The DAS logs individual blade temperature readings taken by the measurement pyrometers, samples and processes the data for use by the data analysis software, Data Sentry.
Data Sentry - Data Analysis Software
This powerful pc-based software utility has all the tools and functions necessary to obtain a complete picture of how efficiently the gas turbine is running, as well as identifying potential problems at an early stage.
|
|
| ... products without technical information |
| |
| Quest Technologies offers a variety of thermal environmental and WBGT heat stress monitors. Datalogging heat stress monitors also available. |
|
A portable sulphuric acid dewpoint monitor (Lancom 200) is designed specifically for plant requiring only periodic monitoring of the sulphuric acid dewpoint temperature for boiler efficiency checks, corrosion protection and evaluation of the effectiveness of corrective measures such as fuel additives and changes in the combustion conditions.
A continuous sulphuric acid dewpoint monitor (Model 440) is permanently installed in order to optimize combustion conditions by maintaining the temperature of the flue gas slightly above the sulphuric acid dewpoint temperature. It can continuously monitor the changes in boiler operation and provide a direct loop input to the boiler's own combustion control system. |
|
Large, well illuminated clear display, on-hand-operation by THUMB-WHEEL, rigid housing.
Portable Digital-Thermometer:
- C100: 1 channel, for Pt 100 (4-wire)
- C110: 2 channels, for 1 x Pt 100 and 1 x Thermocouple
- C120: 2 channels, for 2 x Thermocouple, indicating also differential temperature
Portable Indicator for Humidity:
- E200: Temperature and relative humidity, with rigid probe
- C200: Temperature and relative humidity, with rigid probe
- C210: Temperature and relative humidity, with flexible probe
Portable Digital-Manometer:
- C300: Barometer (barometric air pressure)
- C310: -500...+500 Pascal pressure+vacuum+differential
- C320: -100...+100 mbar pressure+vacuum+differential
- C330: -1000...+2000 mbar pressure+vacuum+differential
Portable Universal Indicators:
- C900: for all transmitter with standard signal output (e.g. 4...20 mA, with power supply for the transmitter)
e.g., together with our pressure transmitter, as Portable Digital Manometer, ranges 0...10 mbar up to 0...2000 bar available. |
|
The powerful indicator N1500 offers among its universal input and the 2 relay outputs for the monitoring of the threshold values many other functions. The Min.- and Max.-values can be prompted with just a keystroke. Also there is a Hold and a Peak-Hold Function whose readouts can be deleted using either the function key or the digital input. The high tact frequency of 15 measurements/second (5 measurements/second when using linear input, thermocouples or Pt100) allows the N1500 indicator to monitor fast processes. It offers also the possibility to linearise the measurement signal when using non-linear input signals (mV, V, mA).
Features:
- Universal input
- Linearization of mV, V, mA signals
- 2 Relay outputs
- 6 Alarm features
- Voltage output 24 VDC for external 2-wire transmitter
- Memory for MAX and MIN values, hold and peak features
See more information in our shop:
***www.temperature-shop.de*** |
|
- Big keys for use with gloves
- Programmable characteristic curve end points (up to 24 control points)
MIN/MAX value detection,
- Display-Hold
- Auxiliary power output for measuring transducer/sensor
- Optocoupler or relay outputs
- Programmable limit values
- Optional: with serial interface |
|
Enhanced indicator
Double input Indicator - Transmitter with four addressable alarms
1/8 DIN 96x48
Universal input for temperature sensors, mA, mV, Volt, IR, custom
High level second input 0/4...20 mA, 0/1...5, 0...10 V
3 digital inputs
3 SPST relays NO, 1 SPDT relay
0/4...20 mA retransmission output
4 addressable alarms with delay, latching and blocking functions
ISA sequence on alarms
Display of MIN, MAX value
Hold and temporized hold to display peaks
Dedicated alarm acknowledge key
5 digits 2 colors display with different combinations
RS 485 serial communications
Power supply 100...240 Vac, 24 Vac,dc
Transmitter power supply
IP65 front panel protection |
|
| The Tecal Accu-Temp is a good choice for use as a laboratory grade reference thermometer. It's available in a single or dual channel model, along with direct temperature readout in degrees F, C and ohms. Combine the Tecal Accu-Temp with one of our secondary standard PRT's for a high accuracy temperature measurement system. Don't rely on battery operated, low accuracy hand-held model PRT indicators for your critical temperature measurements. |
|
Features:
- Compact 1/8 DIN size fits into standard industry panel cutouts.
- Large and super bright red 0.56" LED display
- Safety screw terminals for power and signal inputs.
- Type K, J, T and RTD available |
|
The Icon 100 Series Refrigeration Controllers measure, display and control the temperature of refrigerated cases and coldrooms. The Icon 100 Series can read temperatures from up to two thermistor probes (thermostat and defrost probes), and have relay outputs for compressor, defrost, fan and alarm.
The operating parameters are configurable using a four-button keypad.
Features:
Relay outputs (compressor, defrost, fan and alarm).
Heating function on 111S/SR and 121S/SR
Internal real-time clock on all models for up to 4 scheduled defrost cycles per 24 hours.
Displays status for alarm, network, defrost and setting mode.
Honeywell Genus® network - Can be linked to a Honeywell supervisor for monitoring and logging.
Allows for multiple controller programming.
Dual Probe types (NTC 2k and PT1000)
|
|
| ... products without technical information |
| |
| ... products without technical information |
| |
Programmable panel meter for process, temperature and load cells.
Size: 96x48x60 mm.
Tricolor display: ±19999 (4 ½ digits)
|
|
| ... products without technical information |
| |
| ... products without technical information |
| |
Large, well illuminated clear display, on-hand-operation by THUMB-WHEEL, rigid housing.
Portable Digital-Thermometer:
- C100: 1 channel, for Pt 100 (4-wire)
- C110: 2 channels, for 1 x Pt 100 and 1 x Thermocouple
- C120: 2 channels, for 2 x Thermocouple, indicating also differential temperature
Portable Indicator for Humidity:
- E200: Temperature and relative humidity, with rigid probe
- C200: Temperature and relative humidity, with rigid probe
- C210: Temperature and relative humidity, with flexible probe
Portable Digital-Manometer:
- C300: Barometer (barometric air pressure)
- C310: -500...+500 Pascal pressure+vacuum+differential
- C320: -100...+100 mbar pressure+vacuum+differential
- C330: -1000...+2000 mbar pressure+vacuum+differential
Portable Universal Indicators:
- C900: for all transmitter with standard signal output (e.g. 4...20 mA, with power supply for the transmitter)
e.g., together with our pressure transmitter, as Portable Digital Manometer, ranges 0...10 mbar up to 0...2000 bar available. |
|
|
|
