The MTM Power series PMA19 35 has been designed for the use in 19" racks. Due to the very slim case with only 4 TE, the PMA19 35 require very little space within the complete system. The devices have been designed as universal compact power supplies with input voltage ranges of 85...264 VAC and 80...375 VDC for worldwide application. The switching frequency is 80 kHz and they are equipped an internal fuse at the input. The nominal outputs of 5 V, 12 V, 24 V and 48 V are adjustable. Despite the compact design, the devices fulfill all common safety and EMI standards, are prepared for Class I and have a high efficiency. They are continuous short circuit and overload protected and optionally available with a power fail signal.
|
|
|
|
|
|
MTM Power GmbH, the specialist for high quality power supplies, offers in its program the 19" Euro Card with up to six different, galvanically isolated outputs with 6 or 8 TE. With the MTM Power Card of the series MPK1, an unexpected variety of possibilities can be created for 19" applications. Approx. 1.000 different power supply variations as
19" plug-in can be realised. As in a construction kit, the 19" power supplies can be individually assembled with the three basic components front plate, PCB and connector as well as the vacuum encapsulated modules of the series PMA, PMAS, PMN, PMG and PML. The MPK1 offers 2 mounting positions for PCB modules with an output power of 5 to 48 W, either with single, dual or triple outputs. The MPK2 has one mounting position for modules with an output power of 50 to 100 W and up to three outputs. With the MTM Power Card, power supply variations can be realised in seconds. If requested, a separate LED for each output can be included on the front plate. All modules with the same input voltage can be combined with each other. As customised power supplies have the same dimensions and pinning, even these can be combined with standard modules.
|
|
Open frame
- 3 or 4 output voltages
- VME bus signalling
- Fan monitoring
Power systems
- From 300 W to 1000 W output power
- (n + 1) redundancy
- Design in 3 U subrack
19"
- AC/DC switched mode power supply
- AC/DC linear control systems
- AC/DC converts
|
|
GlobTek brings to power supply design and production the same skills and advantages that have made us number one customer's choice for over 25 years. Our vertical integration, highly efficient facilities, and steadfast obligation to quality and service excellence have enabled us to provide high-value custom engineered power supplies to many satisfied customers.
GlobTek engineers, designs, and manufactures both standard and customized AC-AC, AC-DC, DC-DC power supplies. Our designs fulfill power requirements ranging from 5 watts to 2 kilowatts. GlobTek's greatest advantage is our pledge to serving our customers. Recognizing your need to lower costs and get products to market faster, our team delivers your solution on time and on budget.
|
|
Daitron Ultra Low Noise AC/DC Power Supply HFS50 series can provide 50W at 5/12/24/36/48Vout options available.
In a small foot print and ultra low noise features are suitable for high end application in industry.
HFS series also has 30W type. (HFS30)
See product overview below link;
http://www.daitron.com/original_daitron/catalogs/Ultra_Low_Noise_Power_Supply_Daitron_Dec08.pdf
|
|
Our broad selection of both bench-friendly and system-ready instruments can meet your testing challenges - from basic to complex - with a wealth of available capabilities.
* Test confidently with clean, precise DC power that's fully specified and guaranteed
* Safeguard loads from potential harm with robust output protection and fault detection capabilities
* Enhance system flexibility with built-in, DMM-quality measurement functions
|
|
|
The EG...-130-... series control units contain a DC-side short-circuit protected power pack, voltage stabiliser and output relay. The control units can be actuated by all 2, 3 and 4-wire sensors with PNP, NPN, No, NC or antivalent functions.
|
|
Systems with a DC outlet transform the input alternative voltage, which was pre-conditioned, into a direct, filtered and controlled voltage supported by a series of batteries which is the ideal power supply for Telecommunications operator equipment and other types of equipment with a DC power supply, in which a faulty supply make cause the interruption of the services offered to customers or defects in the production, etc.
SALICRU has two ranges of rectifiers DC Power Systems DC Series OPTIMUS and energy systems of the DC series FAC P.
|
|
|
|
|
|
The Teledyne Hastings Instruments Digital 4-Channel Power Supply units are featured in a half-rack profile for simple drop-in replacement of the existing Model 200 and 400 units.
The THPS-400 instruments incorporate many features including an integrated totalizer with a count-up or count-down options, user selected filtering of readings, serial communications or Ethernet, communications.
These units also offer a simultaneous display of all four channels or selective blanking of unused channels, ratio control with analog outputs for stacking multiple power supplies, and easy to follow, menu driven calibration and setup.
Also available are the THPS 100 Power Supply units which are self-contained power supply and display for gas mass flowmeters, pressure transducers or any device with a voltage output. The units feature an automatically generated set point (0-5V or 0-10V), making it ideal for use with flow controllers and pressure controllers. Features include 4.5 digit display, ±15 volt, 250 mA transducer supply and CE compliance.
|
|
|
|
|
|
They may be unglamorous and unobtrusive, but without them it would not be possible to operate an electronic system. Power supplies are essential. They provide the voltage supply for sensors, actuators, controllers and other electrical loads. ifm offers low-cost transformer power supplies but also powerful switched-mode power supplies for different applications.
Transformer power supplies
Transformer power supplies provide a low voltage, normally 24 V DC to supply PLCs, sensors or evaluation electronics. A transformer according to DIN 0551 ensures a safe electrical separation from mains voltage and low voltage. The output voltage can be regulated (± 5%) or smoothed by means of capacitors. The different designs and output powers allow adaptation to diverse operating conditions.
Switched-mode power supplies
Primary switched-mode power supplies are a compact and economical solution to supply sensors, actuators and sensitive electronic components and are gaining more and more acceptance. As opposed to conventional transformer power supplies with regulated output voltage primary switched-mode power supplies need no heavy transformers so that there are fewer iron and copper losses. They are therefore distinguished by a very high degree of efficiency of up to 92 %.
|
|
|
The PSR series power supplies are regulated DC power supplies capable of operating from 100/240 VAC input, 50/60 Hz. The PSR power supplies include a shunt regulator and blocking diode. They can be used with any controller/amplifier combination to provide a complete solution for single- or multi-axis applications. The PSR series are available in two models: PSR-12-24 and PSR-6-48.
|
|
CSD Series Switching Power Supplies, in modular DIN case with Class 2 double isolation, 90…264Vac/100…350Vdc input.
Items with adjustable 5…15Vdc, adjustable 12…15Vdc, adjustable ±12…±15Vdc and 24Vdc output, 0.6A , 1A , 2.5A , 3A output currennt in 2 or 4 module-cases are available.
EMC compliant to Civil application standards; RoHS compliant; no grounding needed;
Short circuit, overload, over temperature, input / output overvoltage
protection. Designed for use with SELV and PELV circuitry.
|
|
|
Power supplies in modular 2- or 4-modules DIN boxes, 15, 30, 60 or 60W power, stabilized 5, 12, 15 or 24Vdc output; high efficiency, 50°C operating temperature without any performance reduction.
|
|
|
|
|
|
|
MTM Power GmbH, the specialist of individual power supplies, has designed a new generation of DIN rail power supplies, series HSA, for industrial application. As universal compact power supplies, they have an output power of 120 or 240 W. One of the major advantages is to increase to a maximum the readiness for operation of the system to be supplied even under difficult conditions. With dimensions of 50 x 130 x 130 mm (HSA120) and 80 x 130 x 130 mm (HSA240), they perfectly fit into cabinets only offering little space. The devices are available with output voltages of 12, 24, 36 and 48 VDC. They have a high efficiency of up to 89 %, are continuously short circuit protected and need no ground load. The output current is electronically limited in case of overload and the devices then change into constant current operation. Due to this characteristic curve and the reduction of the output voltage to 0 V at the same time, they are protected against short circuit damages and thus offer the possibility to supply loads with high inrush currents without switching-off or intermitting resp.
|
|
|
MTM Power GmbH, the specialist of individual power supplies, offers power supplies for DIN rail mounting with 15 to 75 W. These primary switched modules have been designed as universal compact power supplies with wide input ranges for worldwide applications in switching cabinets and allow an efficient, cost-saving solution for different tasks. They are vacuum encapsulated which allows the use under critical environmental conditions. Further features are rugged design, SMD-technology, automatic 100 % final test and 100-%-burn-in-test. MTM Power DIN rail power supplies comply with the Low Voltage Directives as well as the up-to-date EN standards as regards CE conformity. All devices are short circuit protected, need no ground load and are available with various modification possibilities.
|
|
Universal single and double phase power supplies, CWS series.
185-550Vac input, very high efficiency, low operating temperature . 75, 120 and 24W power, 12, 24 and 48V output.
> 14 A output current peak for 0.5 s for starting-up heavy loads and fuses selectivity.
Short circuit, overload, over temperature, input / output overvoltage protection.
High reliability and immunity against overvoltages due to failures on AC line.
|
|
Daitron Inc offers ultra low noise AC/DC power supply for noise sensitive applications in small foot print, light weight and high efficiency with ultra low noise equivalent to linear type of power supply products at reasonable price range.
See product overview below link;
http://www.daitron.com/original_daitron/catalogs/Ultra_Low_Noise_Power_Supply_Daitron_Dec08.pdf
As a critical power component, our solution can provide high performance in medical, industrial and even other applications, too.
HFS150A series certified EN60601-1 medical standards.
These products line are Green conscious products - RoHS free, Halogen Free PCBs and Vinyl Chloride free.
Also met with several safety standards - UL60950-1, CSA-C22.2, EN61000-4-2/3/4/5/6/8/11, EN55022-B, FCC-B, VCCI-B.
Some specific products comply Harmonic Regulation : EN61000-3-2 Class A compliance*.
* HFD, DFS100/150A, DLS100B series
|
|
Daitron Ultra Low Noise AC/DC Power Supply HFS50 series can provide 50W at 5/12/24/36/48Vout options available.
In a small foot print and ultra low noise features are suitable for high end application in industry.
HFS series also has 30W type. (HFS30)
See product overview below link;
http://www.daitron.com/original_daitron/catalogs/Ultra_Low_Noise_Power_Supply_Daitron_Dec08.pdf
|
|
Absopulse's modular power systems are comprised of plug-in (Eurocard) converter and rectifier modules, and 19" and 23" shelves including motherboards and power distribution panels. These modular designs allow for easy servicing in the field.
Our modular systems offer:
- Output power up to 5kW per 19" shelf
- Almost any input/output and mechanical configuration
- N+1 redundant operation and hot-swap
- Multiple outputs
- Expandability - as power requirements increase, more modules can be added.
- Reconfiguration option
|
|
AC/DC power-supply units
The wide range of AC/DC power-supply systems supplied by
Zentro-Elektrik includes devices with one or several output voltages, switched mode or series-regulated devices, modular power-supply systems, including units with hot-swap features and a large selection of power-supply systems in general.
They can be used in various applications as individual devices or redundant system solution or even as battery chargers and DC UPS units.
|
|
Features :
- 1U low profile
- 19-inch rack mounting
- Control and monitor up to 3 RCP-1000 units
- Suitable for all kinds of RCP output (12V,24V.48V)
- Digital meters for output voltage, output current, and internal temperature on front panel
- Potential meter for adjusting output voltage of RCP-1000 unit on front panel
- Relay contacts and LED indicators for AC fail, DC fail, and over temperature warning
- Removable fixing accessory
- 3 years warranty
Description : RCP-MU is the monitoring and control unit used for the RCP-1000 series rack power. It can decode the l2C signal sent by RCP series and display through digital meters or relay contact signals. RCP-MU can also turn ON/OFF or trim the output voltage of RCP-1000 remotely that make the basic control more easily.
|
|
|
|
|
|
1U low profile 19" rack mount power solution consisting of 1 to 3 hot-swappable RCP-1000 units that, up to 3000W, can be provided in a single rack. Featuring active PFC and 10.67W/in2 extremely high power density. With the ability to provide rated output wattage even at 100VAC input, due to its high efficiency design, and three output voltage levels that can allow 12V@180A, 24V@120A, 48V@63A to be selected as the front end power configuration. The racks can also be paralleled together (up to 3 racks) for higher wattage output applications
* Universal AC input
* Built-in 5V/0.3A auxiliary power
* Built-in active PFC function, PF>0.96
* Short circuit, over load, over voltage & over temperature protections
* Forced air cooling by built-in DC fan with fan speed control
* Low profile:1U height
* Active current sharing up to 3000W (3 units)in 19" rack
* Remote control for single unit
* Built-in remote sense function
* Output voltage trimming function
* Hot-swap operation
* Optional I C serial data bus
* AC OK & DC OK signal
* Internal ORing diode
* Option of AC Inlet or Terminal block on Rack
|
|
|
|
|
|
DC – UPS Systems for Safety Relevant Installations
With their modular construction, the latest DC – UPS systems in the GTLB/GTPB series from Zentro Elektrik expand the existing comprehensive range of DC – UPS systems for supplying power to safety relevant installations.
The AC/DC systems in standby parallel mode are designed for outputs
from 250 Watt up to 600 Watt and fitted with batteries at the customer’s request. Additional DC/DC converters can be added to the system if more output voltages are required.
A battery control and monitoring module allows to control the charging current and temperature control of the charge closing voltage.
Over and above this, numerous monitoring and control signals are provided via relays, LED’s or potentiometers. A signal relay, for example,
if the charging voltage fails, to switch off the battery on it reaching the closing discharge voltage, to give advance warning of reaching closing discharge voltage with an additional adjustable threshold or individual limitation of the battery charging current to prolong battery life, and
many more. LED displays and adjustable potentiometers provide for comprehensive signalling and the ability to adjust the maximum charging voltage or the defined point of battery switch-off.
|
|
|
|
|
|
The 9130 is a fully programmable triple output DC Power Supply delivering 0-30V/0-3A on 2 outputs and 0-5V/0-3A on 1 output. Each output is fully floating and outputs can be adjusted independently or connected in series or parallel to produce higher voltages or currents. The 9130 is ideally suited for applications in Electronic Test, Production and Service, where multiple independent DC supplies are required and bench space is at a premium.
# 3 independent, fully programmable and electrically isolated outputs
# Display & adjust Voltage and Current settings for all 3 channels simultaneously
# Flexible output configuration: Operate in series or parallel tracking mode
# SCPI compatible command set. Communicate via USB interface using the included USB to TTL Serial Converter cable
# RS232 interface cable, converting from RS232 to TTL, is optional (order IT-131)
# OVP (Over Voltage) and OTP (Over Temperature) protection
# Output on/off control
# Excellent stability and regulation
# Very compact foot print (rack mountable 2U x 1/2U)
# Application Software for front panel emulation and simple test sequence generation included
# 50 memory locations for instrument state storage & recall
|
|
Our Power Supply with single to 4 channels and digital/analogue display series. Its high stability and enhanced linearity makes this regulated DC power supply significantly useful in where high performance and stable power sources are required. It is widely adopted for R&D, educational and industrial usage.
General Features:
- Single to 4 adjustable channels
- 0-30V voltage linearly adjustment
- 2 display for voltage and current
- Low noise and ripple (<1mV)
- voltage and current pre-set feature
- CV/CC mode auto change
- Full LOADING continuous operation over 16 Hrs
- Conforms to EN61010-1
|
|
Bench Top power supplies are recommended for research and laboratory use. They offer flexibility in terms of voltage range and output polarity. These are stand-alone units which all feature an output voltage display.
The PM20D and PM30D dual output supplies include a 4 digit LCD read out and low voltage (+-5V and +-12V) supplies. Lower cost versions, PM20S and PM30S offering only single polarity output are also available. All supplies in this range accept ac or dc input - referred to as universal supply input.
features :
- mains input
- output range up to 3000V
- low ripple
- positive or negative HV
- overload protected
- clear display of output voltage
- multi-turn set dial
|
|
A wide range of power supplies for nearly every requirement.
- Powers from 80W to 12kW
- Currents from 0,4A to 300A
- Voltages from 18V to 300V (or even higher, by request)
- 19" and desktop models with 2/3/6/9HE
- Custom designs possible
- Programmable via analogue interface, USB, IEEE, RS232 or CAN
- Exchangable interface cards with LabView support
- Special version ZH with active load (2400W peak pulse power) and high voltage dynamics, as well as triggerable car start curve according DIN 40839
|
|
This type of power supply has all in one:
High efficiency, low line distortion and power factor correction (PFC). It’s an optimal combination of good cost-performance for both; end-users and power production companies.
|
|
# Models 1785B, 1786B, 1787B & 1788 are Programmable DC Power Supplies that offer new levels of "ease of use" and programmable functionality. Direct key in entry makes voltage and current selection fast, accurate and easy. In case calibration allows for simple, cost savings, uninterrupted operation. Sixteen user programmable preset outputs
# Controllable Output On/Off Switch
# 10mV/10mA setability resolution
# Closed case calibration
# Low ripple and noise
# Excellent temperature stability
# Serial interface cable and software included
|
|
|
|
