Balancing vibration analyzer VA3PRO

for predictive maintenanceportabledigital

3-Channel Vibration Analyzer, Data Collector and Many More A true vibration analyzer real time FFTs, time waveforms etc. Modularly based buy only the modes you need User friendly interface graphical balancing mode Customize your VA3 Pro kit. Select a single axis acceleration sensor or triaxial sensor for your day to day data collection. A speed probe would be needed for balancing job and an ultrasound probe for leak detection. No problem measuring Orbits, Centerline using Proximity probes. 3x AC input – vibrations 3x DC input – process values 1x Trigger input (speed probe) Triaxial sensor readyIR temperature sensor LED stroboscope / flashlight Fast USB 2.0 communication Robust Push-Pull connectors Input channels: 3 x AC, ICP® power supply on/off 3 x DC for process values 1 x TACHO for speed probe / external trigger Input range: AC +/- 12 V peak-peak DC +/- 24V AD conversion: 24 bit, 64 bit internal signal processing No AutoGain function! Dynamic range S/N: 120 dB
