Chemical pump MPA series

electricself-primingperistaltic

The patented Maguire peristaltic pumps are designed to accurately meter precise amounts of liquid color into the main flow of natural material directly above the throat of your process machine. Metering is accomplished by the compression and release of a flexible pumping tube by six hardened dowel pins that rotate within a Celcon® housing. Positive Displacement Pump Series MPA pumps are true positive displacement pumps, with no seals, check valves or clearances to allow even the slightest internal leakage. The units are self-priming and will pass any entrapped air bubbles in the liquid through the pump without loss of prime. They can pump liquid with viscosity as high as heavy syrup. Automatic Speed Control The MPA pumps use automatic speed control to assure self-adjusting accuracy. This pump can be used for both injection and extrusion. Three Tubing Sizes Available Various tubing diameters and assemblies are available to provide a wide range of outputs.
