Threaded pipe line filter
Maximator GmbH
Pipe Line Filters
MAXIMATOR Pipe Line Filters are used to filter process fluids in high pressure systems. The cup type design is used when maximum filtration surface area and a single micron size element is preferred. This design increases the filter area as much as 6 times the area of the disc type filter, and will permit higher flow rates with a lower pressure drop, and longer intervals between element changes.
Filter elements come standard in 5, 30, or 56 micron sizes and are easily replaced. Filters are rated for temperatures -60˚F to 660˚F (-50°C to 350°C).
Materials:
Body, cover, cover gland: 316 series stainless steel
Element: 300 series stainless steel
