Class aR fuses
... bolted-blade style. Visual blown fuse indication is standard on all fuses and optional micro-switch is available for external indication. PSX series are certified to UL 248-13 and designed to meet EN ...
Amperage: 40 A - 2,000 A
VAC: 700, 650, 1,300 V
... Features/Benefits • Best in Class DC performance • Extremely current limiting • Superior cycling capability • Global certification cURus, CCC, IEC • Direct bus-bar mount design • Visual and optional microswitch ...
Amperage: 10 A - 550 A
VAC: 200 V - 1,000 V
The new high speed fuses in the E-mobility line are designed in compliance with automotive standards, such as ISO 8820-8 and JASO D622.Also, they are available with melamine laminated fiberglass bodies that are capable ...
Amperage: 0.5 A - 125 A
VAC: 690 V
VDC: 700, 600 V
... without striker. Features & Benefits Three unique sizes from 0.5-125 amperes do not allow inter-changeability with other fuse classes Low I²t for improved semiconductor protection
Amperage: 4 A - 630 A
VAC: 690 V
Chordn's AS17B fuses have been engineered to provide state-of-the-art protection for semiconductors: diodes, thyristors, GTO's and IGBT devices. Fuses are assembled with pure silver, die-cut elements ...
Amperage: 35 A - 2,000 A
VAC: 1,000 V
VDC: 700 V
... American round style fuses were developed for higher voltage AC and DC drives, UPS systems, reduced voltage motor starters and similar applications where lower I²t and superior reliability were needed. This is a very ...
Amperage: 5 A - 2,000 A
These Socomec high speed fuses are made to protect power semi-conductors and DC circuits. These fuses are available in various sizes, with a voltage rate between 690 V or 1250 V and power ranging from ...
Amperage: 0.1 A - 30 A
VAC: 500 V - 600 V
... (minimum operating voltage for trip-indicator: 20V) • Without blown fuse indication 0.10 up to 0.80 A • (higher ratings without blown fuse indicator 10x38gRB - 690VAC) • aR-Class ...
Amperage: 1,250 A
VDC: 1,000 V
The product is specifically designed for DC fuse link uses. It is equipped with a rated voltage of 1000 V DC for L or R equivalent to 1 ms, a breaking capacity of 30 kA DC, and a rated current of 800, 1000 and 1250 Axial. ...
Amperage: 500 mA - 100,000 mA
VAC: 400, 500, 690 V
Description: HCaR Series,HC08aR、HC14aR、HC22aR, Class Of Operation:aR Security Certificate: CCC/TUV/cURus Application: Protect Semiconductor Facilities Standard: IEC ...
Amperage: 5 A - 900 A
Standards: IEC 60 269-4 BS 88-4 Class: aR Voltage ratings: AC 240 V – AC 700 V Current ratings: 5 A – 900 A High interrupting rating 100 kA Voltage ratings AC 240 V – AC 700 V Protection of Power Semiconductors ...
NH fuse-links with utilization category aR for semiconductor protection according to IEC 60269 respectively DIN EN 60269-1 and DIN EN 60269-4 with thread contacts and a rated voltage of AC1000V.
Amperage: 20 A - 2,000 A
VAC: 690 V
... D and type NH fuses (class gL/gG) are designed with high quality ceramic body. Main Characteristics • Excellent electrical insulation; • Mechanical strength; • Resistance against thermal shocks ...
