Forward acting rupture discs
Burst pressure: 100 mbar - 40,000 mbar
Nominal diameter: 6 mm - 600 mm
SINGLE LAYER RUPTURE DISCS - THE FATHER OF ALL RUPTURE DISCS The rupture disc that started it all many decades ago. Even now, ...
Nominal diameter: 25 mm - 600 mm
The advanced manufacturing process of the rupture disc STAR guarantees minimum fragmentation when opening even at the highest pressures. Its star-shaped opening pattern is flatter than that of other ...
Nominal diameter: 25 mm - 100 mm
The CBS rupture disc protects intermodal tank containers with especially high demands regarding the leak-tightness and the temperature and corrosion resistance required for the pressure relief device ...
Burst pressure: 500, 300, 100 mbar
Nominal diameter: 50 mm - 300 mm
... reverse acting rupture disc with its buckling pins and the three-section design of the ODV forward acting rupture disc, ...
Burst pressure: 300 mbar - 6,000 mbar
The REMBE® graphite rupture disc GRX® is ideally suited to relieve pressure, when rupture discs must already respond at a relatively low pressure, the process temperature ...
Burst pressure: 0 psi - 720 psi
Nominal diameter: 13 mm - 600 mm
Continental Disc Corporation's impervious graphite rupture discs (bursting discs) are simple, reliable overpressure relief devices designed to protect processing systems, ...
Burst pressure: 1 psi - 2,000 psi
Composite Bursting Disc Type D The Type D Composite Bursting Disc consists of a slotted metal top section and a plastic or metal seal membrane located at the concave ...
Burst pressure: 1 bar - 100 bar
Nominal diameter: 1 in - 8 in
... consists of an inlet and an outlet of the NX-7R Safety Head plus the XN or LCN Rupture Disk, depending on the pressure required. Refer to Figure 1. The XN Rupture Disk (Bursting Disc) ...
Burst pressure: 0 bar - 12 bar
Nominal diameter: 2 in - 8 in
The VAC-SAFTM System rupture disks offer two-way relief to provide maximum protection of gas or liquid storage vessels and plant from damage caused by excessive vacuum or over pressure. We offer two ...
Burst pressure: 26 psi - 100 psi
A surge resistant rupture disk (bursting disc) for railroad took cars and over-the-road trailer service Industry. The disk is designed for direct installation on to standard threaded ...
Burst pressure: 20 psi - 3,000 psi
The versatile Poly-SD rupture disc can be used in liquid, vapor and two phase flow and is available in a large variety of materials. Specifically designed to help prevent material buildup on the rupture ...
Burst pressure: 2 psi - 6,000 psi
The cost-effective HO Rupture Disc is a composite disc consisting of two components, the seal member and a slotted top that controls the burst pressure. With a fluoropolymer seal, this ...
