In-line flow switches

Flow Switch are slim, inline switches to reduce pressure drops to a minimum. They incorporate a unique, dual-diameter, internal bore and piston configuration to minimize flow constriction. Liquids are able to smoothly pass around the ...

Flow Switches offer accurate flow detection, with 1% repeatability, over a broad range of flow settings and port sizes. Its durable construction delivers long-life reliability in either water or oil. Generous flow paths keep pressure ...

Flow Switch is a rugged, inline flow switch that uses 100 micron filtration and is less susceptible to clogging than other high-pressure inline flow switches. The one-piece magnetic PPS composite piston makes the FS-380 ideal for high-pressure ...

• 2-wire flow switch for liquids, pastes, slurries (≥20μS/cm); also for hygienic use and immersed applications (IP68) -25…+150°C / -13…+302°F; max. 25 barg / 360 psig • For pipes DN25…400 / 1…16", optional for >DN400 / 16" • For AC ...

• Flow indication without power supply • Up to 30,000 l/h or 132.09 GPM (US) • Thread: G3⁄4…2, 3⁄4…2 NPT • -40…+300°C / -40…+570°F; max. 40 barg / 580 psig The DW 181 is an inline flow controller for locally indicating the flow ...

Mechanical flow controller for clean liquids • Flow indication without power supply • Up to 30,000 l/h or 132.09 GPM (US) • Flange: DN15…65 / 1⁄2…21⁄2", max. PN40 / ASME Cl 300 • -40…+300°C / -40…+570°F The DW 182 is an inline ...

CONTINUOUS MATERIAL FLOW DETECTION WITH TREND MONITORING Microwave sensor for contactless monitoring of material flows with trend monitoring FEATURES & BENEFITS • Absolutely insensitive against material deposits • For any line diameter • ...

Magnetrol® flow switches are highly reliable flow control solutions utilized to sense the presence or absence of flow in horizontal pipelines. Model F10 switches are vane actuated for use on gas or liquid flow applications in 2 inch or ...

Magnetrol® flow switches are highly reliable flow control solutions utilized to sense the presence or absence of flow in horizontal pipelines. Disc-actuated Model F50 switches are in-line type used for sensing clean liquids in 2 inch ...

Thermatel® TG1/TG2 provides a two-wire, intrinsically safe circuit between the probe and remote din rail enclosure. The flow/level/interface switches provide a new level of performance and reliability not found in previous switches. Continuous ...

Inline-Compact • up to 6 l/min Series SDN - Flow controller DC 24 V PNP output Relay output Analog outpul\ G1/4 thread • 04 mm G1/4 thread • 09 mm EGE offers thermodynamic flow controllers without moveable parts, which means ...

Inline-Compact • up to 40 l/min Series SDN - Flow controller DC 24 V PNP output Relay output Analog output G1/2 thread • 015 mm G3/4 thread • 019 mm EGE offers thermodynamic flow controllers without moveable parts, which means ...

Inline-Compact Series SDNC 503 DC 24 V Flow monitoring Can be easily integrated in the tubing Immediately ready for use - no adjustment EGE offers thermodynamic flow controllers without moveable parts, which means they are robust ...

Robust metal design for high maximum flow rates Brass or stainless steel design, pipe section DN 8...50 SIKA flow switches are used for monitoring volumetric flows. Depending on the individual requirements, they are available ...

Plastic design with PVC pipe section for special applications PVC glue fitting DN 15…50 SIKA flow switches are used for monitoring volumetric flows. Depending on the individual requirements, they are available for different ...

High switching currents. Micro switch as signal transmitter if devices are to be switched directly, without control brass pipe section DN 10...50 SIKA flow switches are used for monitoring volumetric flows. Depending on the ...

IF…E – Adjustable electric flow switches Flow rate0,1…140 LPM H2O Materials Anodized aluminium – Nickel-plated brass – 304 stainless steel Sealing: NBR (standard) – FKM - EPDM Max pressure 150 bar Operating temperature -10°C ...

IFE – Adjustable electric flow switches Flow rate0,3…60 LPM H2O Materials Nickel-plated brass Sealing: NBR Max pressure 50 bar Operating temperature -10°C +80°C Intervention differential ca. 45% Electrical connection ...

Adjusted switching value ●Highly reproducible ●Insensitive to dirt Characteristics The volume flow raises a piston (fitted with a magnet) out from a valve seat against a spring force. The piston actuates a hermetically separated reed switch.

Highly reproducible ●Precise, stepless adjustment of the switching value ●Insensitive to dirt ●Short installation length CharacteristicsThe volume flow raises a piston (fitted with a magnet) out from a valve seat against a spring force. ...

Large analog display ●Monitor and display ●Simple adjustment by means of drag indicator ●Insensitive to dirt ●Short installation length Characteristics The volume flow raises a piston out from a valve seat against a spring force. The ...

The KOBOLD flow meters and switches model DSV are focused around the rule of the well-known float kind flow meters with the exception of the ordinary decreasing measuring tube. This abolish the ordinary issues of managing the cylindrical ...

The DVK Series manufactured by M-ZERT is a Calorimetric flow meter, monitor and totalizer model. This device is used for measuring and monitoring the small and average flows from airs in hoses and piping. It is characterized as a maintenance-free ...

The All-Metal Flow Meter and Switch is highly designed to provide an excellent quality functionality and performance for very specific purposes. The device is in compliance to the principle of a very popular float-type meter except for ...

Inline flow-switch for liquid media in stainless steel housing with transistor output 4320.12/13 M Water and water-based liquids 4321.12/13 M Oil- and oil-based liquids Other media on request Operating principle: calorimetric (thermal) ...

Inline flow-switch for liquid media with transistor output 4320.1x water and water-based media 4321.1x oil- and oil-based media Other media on request. Operating principle: calorimetric (thermal) non contact Measuring ...

Inline flow-switch for liquid media in stainless steel housing with relay output (18-30VDC) 4320.40 M water and water-based liquids 4321.40 M oil- and oil-based liquids Other media on request Operating principle: calorimetric ...

Measuring principe Karman vortex Measuring range 10÷250 l/min Output signal Digital: NPN or PNP / Analog: Voltage 1÷5V or Current 4÷20mA Process connection 25A - 30A Materials in contact with the fluid: PPS - FKM - CPVC Temperature ...

Measuring principe Karman vortex Measuring range 0.4÷40 l/min Output signal pulses, display with analog voltage output 1÷5V or 4÷20mA current Process connection 3/8" - 1/2" - 3/4" Materials in contact with the fluid: PFA Temperature ...

Measuring principe Karman vortex Measuring range 0,5÷100 l/min Output signal Digital: NPN or PNP / Analog: Voltage 1÷5V or Current 4÷20mA Process connection 3/8" - 1/2" - 3/4" - 1" Materials in contact with the fluid: PPS - Stainless ...

- Complete flow alarm unit, monostable version - Monostable: sensor detects set flow value - Consisting of: sensor FA2-H, 2 light guides FO1 (600 mm long), pre-amplifier with adapter K-FA-H, electronic controller FA-1.1 - For float-type ...

FLOW – MR1KV – Piston sensing element – Liquid and gas media application – Hermetic separation between flow and switch head – Nickel plated Brass or St. Steel body – Process connections from 1/4″ to 1” Gas-F – Setting ranges from 0,4 ...

FLOW – RVM – Piston sensing element – Liquid and gas media application – Hermetic separation between flow and switch head – Nickel plated Brass or St. Steel body – Process connections 1/4″ Gas-F – Setting ranges from 0,04 to 3 l/min. ...

FLOW – FCM Piston sensing element Vertical or horizontal mounting Easy and fast replacement of the switch head Liquid and gas media application The flow switch FCM was built to enable a simple control of the flow rate and a fast signal ...

COMECOs PSF100 flow switch is designed to operate with low-viscosity, non-viscous, clean or dirty liquids with moderate flow rates as water and water solutions, oil, and fuels. This model utilizes the well-know principle of thermal dispersion, ...
