Slide switches

Primary current: 3, 5 A
Voltage: 125, 28 V

... tact switches make them suitable for high density mounting. Grayhill’s Toggle, Rocker, and Slide Switches are available in industry standard designs to allow for easy ...

Primary current: 0.22, 2.5, 1, 1.5 A
Voltage: 120, 125 V

Guard Lock Safety-door Switch D4SL-N •Wiring time is reduced with two types of wiring methods capable of one-touch attachment and removal. • A wide variety of built-in switches can be used for various ...

Primary current: 3 A - 10 A
Voltage: 14, 28 V

Dimmer and wiper controls are designed to complement the NGR family of switches. Paddle and Slide Control versions both have the look, feel and durability associated with our controls. Bezels and actuators ...

Primary current: 3 A - 6 A
Voltage: 125 V - 250 V

6A Power Level & 0.4VA Logic Level; Frame and PCB Mount, UL, CSA, cULusMiniature Slide SwitchesOver-center actuator block and plunger design gives crisp actuation, diminishes sparking, and increases operating life. Bright, ...

Primary current: 100, 200 mA
Voltage: 6, 12 V
Operating temperature: -40 °C - 85 °C

The AYZ series miniature slide switch from C&K feature a low-profile and are available in single or double pole models and double or triple throw models. Makers of computer peripherals, network products, ...

Primary current: 500 mA
Voltage: 12 V
Operating temperature: -40 °C - 85 °C

rame Material - PA66 Frame Flammability Rating - UL94 V-0 Frame Color - Grey Actuator Material - PA66 Actuator Flammability Rating - UL94 V-0 Actuator Color - Red Contact Material - Copper Alloy Contact Plating - Gold Terminal ...

Primary current: 0.4 A - 5 A
Voltage: 125, 250, 28 V
Operating temperature: -30 °C - 85 °C

The 4M-Series miniature slide switches offer a variety of ratings, circuits, contact materials, and terminal platings. With 14 termination choices and 8 actuator styles, this versatile switch ...

Operating temperature: -40 °C - 85 °C

... are robust and reliable. There are multiple applications in industry as well as in consumer electronics. The switches are a High-End alternative to jumpers and also work as address switches ...

Primary current: max 2.0 A
Voltage: max 12.0 V

IP6K7 sealed sub-subminiature switch Switching current from 5 mA up to 2 A at 12 VDC Suitable for actuation at angles of up to 40° (dependant on slide partner material etc) High contact ...

Primary current: 0.01, 25 mA
Voltage: 4, 24 V

Features Slide Dip Switch Variety of models with short or long actuators

Primary current: max 16.0 A
Voltage: max 250.0 V

The 2000 slide switch, manufactured by Arcolectric, is capable of accommodating up to 5 positions. It has a current rating of up to 16A 250V ac. It is equipped with PCB and a solder terminal and complies ...

Primary current: 10 mA - 100 mA
Voltage: 12 V

Sub-subminiature SJ IP6K7 sealed sub-subminiature switch Switching current 10 mA to 100 mA Switching voltage max. 12VDC Suitable for actuation at angles of up to 40° (dependant on slide ...

Primary current: 3, 1 A
Voltage: 250, 120 V
Operating temperature: -30 °C - 85 °C

... 500A Series subminiature slide switches with silver contacts have electrical ratings of up to 3A of 120 VAC with [cURus] approval. The gold contacts are rated for 0.4VA of 20V alternating or direct current. ...

Slide switch design features a fully enclosed housing which minimizes risk of corrosion and contamination. Features Vertical or horizontal leads Standards meet or exceed those of MIL-Q-9858A Make-before-break ...

Primary current: 50 mA
Voltage: 500 V

Our slide DIP switch versions are available in a broad range of low-profile, half-pitch (.05 inch), standard-pitch (.1 inch), through hole, and surface mount options. Our unique design and construction ...

Primary current: 10 A
Voltage: 250 V

Product number 4021.0512 Weight 5,200 g Product family Slide switches Switching function Changeover switch (DPDT) Number of poles 2-pole Mechanical life endurance 1E4 Rating IEC 10 A ...

Primary current: 100 mA
Voltage: 12 V

RoHS compliant Excellent contact stability by twin Gold-plated contact mechanism Load life of 30,000 cycles Compatible with automatic mounting Withstands high soldering temperature

Series HRM Description Operation: ON/OFF Circuit: SPST Travel: 0.65mm Force: 500gf max. Life: 2,000 cycles Switching: 25mA 24Vdc Non-switching: 100mA 50Vdc

Primary current: 8 A

The LF series is a type of slide switches with single and double pole. It is designed to have a back panel cut with 8 A ENEC electrical rating. It can reach 10.000 electro-mechanical cycle. It can be ...

Primary current: 100 mA
Voltage: 50 V

... gold-plated over nickel Terminals:nickel silver, gold-plated Material:case and slide: PA Construction:case sealed, slide recessed, sealed with protective tape Mounting:on pc-board - SMD Slide ...

Primary current: 1 mA
Voltage: 5 V

Dimension： Unless otherwise specified,a tolerance of ±0.4mm applies to all dimensions. Specifications： Operating frequency(electrical).....Max. 20 Operation / mim Contact resistance.....2 Ω(max) Dielectric strength(50 - 60 Hz).....100VAC ...

Primary current: 0.3 A
Voltage: 4 V

SSP Series H=1mm Slide Switches [FEATURES] 1. 1mm in height (horizontal). 2. Suitable for SMT reflow soldering. 3. Packaged in a tape (taping package) to allow the auto mounting of switches. 4. 1-pole, ...

Primary current: 10 A
Voltage: 250 V

The 4021 series is a double and four pole slide switches. These are equipped with a sunken slide that provides protection from accidental actuation. An assembly with screws and different connection kinds ...

Primary current: 500 mA
Voltage: 12 V

... series is a heavy-duty switch manufactured by EOZ. It is a compact changeover switch suitable for all PCB applications. The 1K2 can be utilized as a replacement for jumper. Instant recognition of switch ...
