- Through-hole turning chuck
Through-hole turning chucks
{{#each product.specData:i}}
{{name}}: {{value}}
{{#i!=(product.specData.length-1)}}
{{/end}}
{{/each}}
{{{product.idpText}}}
{{#each product.specData:i}}
{{name}}: {{value}}
{{#i!=(product.specData.length-1)}}
{{/end}}
{{/each}}
{{{product.idpText}}}
Rotational speed: 3,150 rpm - 8,000 rpm
Gripping force: 48 kN - 250 kN
Outer diameter: 110 mm - 400 mm
The Duro-A is a three-jaw chuck with a through-hole that can be clamped automatically (hydraulically) by a CNC machine. It is mainly used forturningcylindrical and disc-shaped blanks. Stable damping using axial tension The draw-in of ...
RÖHM GmbH
Gripping force: 0 kN - 115 kN
Outer diameter: 74 mm - 1,250 mm
The Duro-M is a manually geared scroll chuck with through-hole, drilling and turning jaws with cylindrical mount. It is mainly used on conventional turning machines for machining turned parts. Physical characteristics Chuck body (and ...
RÖHM GmbH
Key bar chuck with quick jaw change system. Guaranteed maximum jaw precision as far as these are only used on the same chuck, and base and top jaws are kept screwed on for recurring work. Optimized for turning applications, which ...
RÖHM GmbH
Gripping force: 1,000 N - 10,100 N
Stationary 3-jaw-clamping-chuck, pneumatic Through central hole up to 60.5 mm Self-centering Clamping force up to 10.100N Stroke up to 32mm Stroke control Rating IP 40
Gripping force: 13,500 N - 206,000 N
Stationary 4-jaw-clamping-chuck, hydraulic-pneumatic Self-centering Clamping force up to 206.000N Stroke up to 44 mm Rating IP 40
Stationary 4-jaw-clamping-chuck, hydraulic Self-centering Clamping force 1.000N for jaw Total clamping force 4.000 N Pressure 30 bars Stroke 5 mm for jaw Repeatability +/-0.03 mm Rating IP 65 max
Rotational speed: 3,600 rpm - 6,000 rpm
Gripping force: 41 kN - 160 kN
Outer diameter: 165 mm - 315 mm
Fast jaw change with quick change design and high repeatability – that is what makes the B-Top jaw chuck product line so flexible. Particularly for small lot sizes. Thus in most cases machining the chuck jaw to size is unnecessary. Flexibility ...
HAINBUCH GMBH SPANNENDE TECHNIK
Rotational speed: 3,200 rpm - 8,000 rpm
Gripping force: 70 kN - 235 kN
Outer diameter: 115 mm - 302 mm
Reliable and long life SPANNTOP nova – this development represents more than 30 years of SPANNTOP experience. It exploits all the advantages of the latest machine tools. The components are optimized for balance quality, and have an ...
HAINBUCH GMBH SPANNENDE TECHNIK
Rotational speed: 4,000, 3,600, 6,000, 5,400 rpm
Gripping force: 74, 41, 160, 115 kN
Outer diameter: 215, 165, 315, 260 mm
Flexible for small lot sizes Fast jaw change with quick change design and high repeatability – that is what makes the B-Top jaw chuck product line so flexible. Particularly for small lot sizes. Thus in most cases machining the chuck ...
HAINBUCH GMBH SPANNENDE TECHNIK
Rotational speed: 1 rpm - 6,000 rpm
Gripping force: 1 kN - 80 kN
Outer diameter: 165 mm - 370 mm
With Triton®, SwissChuck AG has introduced a modular power chuck range that caters to high-end applications such as turning, hard turning, and grinding. Precision manufacturing and high-quality materials components guarantee a radial ...
Rotational speed: 1,700 rpm - 7,000 rpm
Gripping force: 40 kN - 210 kN
Outer diameter: 130 mm - 450 mm
High Precision Power Chucks Size Range: 130mm - 450mm Number of Jaws: 2, 3 and 4 Jaws Large Through Hole Inch Serration BH-D Open Center Power Chucks feature a large through hole, and are designed for open center or partial open ...
SMW AUTOBLOK
Rotational speed: 1,800, 1,200, 1,500 rpm
Gripping force: 210, 240 kN
Outer diameter: 500 mm - 800 mm
High Precision Power Chucks Size Range: 500mm - 800mm Number of Jaws: 3 Jaws Large Through Hole Inch Serration BH-D Large Diamter Open Center Power Chucks feature a large through hole, and are designed for open center or partial ...
SMW AUTOBLOK
Rotational speed: 2,000 rpm - 6,500 rpm
Gripping force: 70 kN - 240 kN
Outer diameter: 165 mm - 630 mm
High Precision Power Chucks Size Range: 165mm - 630mm Number of Jaws: 3 Jaws Centrifugal Force Compensation Large Through Hole Inch Serration BHD-FC Open Center Power Chucks feature centrifugal force compensation for high speed ...
SMW AUTOBLOK
Rotational speed: 42,000, 5,000, 3,300, 6,000 rpm
Gripping force: 57, 74, 38, 96 kN
Outer diameter: 254, 169, 305, 210 mm
FEATURES * The entire body of the power chuck is made of specialalloy steel.The all body is made resistant to friction. *Lubrication ducts are specially designed.In this way, the Gress oil is distributed equally to all surfaces.and the ...
Ozkayali Workholding and Spanntechnik
Rotational speed: 6,000, 4,500, 5,000, 7,000, 3,500 rpm
Gripping force: 143, 56, 36, 110, 85 kN
Outer diameter: 305, 210, 135, 169, 254 mm
FEATURES * The entire body of the power chuck is made of special alloy steel.The all body is made resistant to friction. *Lubrication ducts are specially designed.In this way, the oil is distributed equally to all surfaces.and the ...
Ozkayali Workholding and Spanntechnik
Rotational speed: 7,000, 4,500, 6,000, 5,000, 3,500 rpm
Gripping force: 85, 143, 56, 36, 110 kN
Outer diameter: 135, 210, 254, 169, 305 mm
FEATURES * The entire body of the power chuck is made of special alloy steel.The all body is made resistant to friction. *Lubrication ducts are specially designed.In this way, the oil is distributed equally to all surfaces.and the ...
Ozkayali Workholding and Spanntechnik
Through-hole 3-jaw power operated chuck. (High speed and high accuracy) This model provides high-repeatability with cross-key structure that does jaw positioning. It's available to use as high speed rotating specification. GX model ...
Closed Center Power Chucks Unique ‘double slide key’ only available at MMK! Thru-Hole 3-Jaw Power Chuck The He model is superior in rigidity, durability, and safety, with the double-slide key structure. This unique ‘double slide ...
Rotational speed: 572 rpm - 7,200 rpm
Gripping force: 23.5 kN - 226.5 kN
The Z chuck model is equipped with a large through-hole and high speed capabilities. It is extremely versatile for general machining applications. The matching cylinder is from ZKP series. Thru-Hole Power Chucks Provides the extra ...
Rotational speed: 0 rpm - 5,000 rpm
Gripping force: 0 kN - 86 kN
Outer diameter: 30 mm - 210 mm
Kitagawa's leading power chuck can be used with both hard and soft jaws. Chucks are manufactured from high grade alloy steel. Three jaw wedge style power chucks deliver up to 20% more speed, gripping force and bore size when compared ...
Kitagawa Europe
Outer diameter: 102 mm - 830 mm
Automatic self-centering BIG THRU-BORE CHUCK with built-in pneumatic cylinder
Chuck with face driver for clamping shafts used for turning operations Transmission of high torque Accuracy: high concentricity Max. clamping diameter: 120 mm.
Hardinge Sure-Grip Power Chucks are lever-operated, counter-centrifugal and dynamically balanced. This enables you to continually operate your CNC lathe at higher spindle speeds and feed rates with less concern for loss of jaw force normally ...
Outer diameter: 200 mm - 500 mm
Low Maintenance Wedge Style Power Chuck With Centrifugal Force Compensation The new QLC-LM three-jaw power chuck with through-hole is the low maintenance variant in the QLC family. Inside it is based on the well-known QLC technology ...
ITW Workholding
Properties and application: Cast iron lathe chuck Mounted on adapter plate The set includes: 1 set of external solid jaws, 1 set of internal solid jaws, key, mounting screws Used in low speed turning operations
Rotational speed: 1,760 rpm - 5,000 rpm
Gripping force: 52.49 kN - 273 kN
Three-jaw power chuck with bore - centre mount or according to DIN 55026 - compatible with Kitagawa - serration 1,5 x 60° - all sliding surfaces are hardened and ground for accurate actual running and long service repeatability
Rotational speed: 3,150 rpm - 8,000 rpm
Gripping force: 20 kN - 100 kN
BERG power operated chucks type KH are designed for high speed, high capacity lathes. They stand out for their high clamping force and precision, a particularly large open centre for bar stock, as well as high maximum rotational speed ...
Berg & Co. GmbH Spanntechnik
