IPコールステーション KNPA800miniR

PoEイーサネット4.3インチ

Overview
Model: KNPA800miniR
100-zone one-touch paging with a covered red emergency key
With gooseneck unidirectional microphone
Size: 213 (L) x 190 (W) x 76 (H) mm (excluding microphone)
Material: ABS (Acrylonitrile Butadiene Styrene)

Key Functional Features & Benefits

• Purpose-Built Design: engineered for professional PA applications and mission-critical reliability.
• Certified for Safety: EN 54-16 and ISO 7240-16 certifications for life safety and voice evacuation systems.
• 24/7 Operational Readiness: built for continuous operation with intelligent energy-saving standby features.
• User-Centric Interface: vibrant 4.3-inch TFT for clear, responsive control and simplified operation.
• Effortless Zone & Group Selection: select individual zones, pre-defined groups, or all-call broadcasts via expandable display.
• At-a-Glance Status Confirmation: visual indicators for power, communication status, and push-to-talk activation.
• Superior Audio Management: professional gooseneck unidirectional microphone, adjustable microphone sensitivity, volume control, and software-configurable parametric equalization.
• Seamless Integration of Audio Sources: 3.5mm jack for wireless microphone input.
• Flexible Broadcasting: selective zone, group-zone, and all-call paging options; automated and scheduled announcements; pre-recorded message playback.
• Emergency Priority: priority-based audio routing ensures emergency announcements override lower-priority audio.
• Enterprise-Grade Reliability: PoE operation, dual Ethernet ports for network redundancy.
• 100-key paging console with guarded emergency key: 10 pages × 10 physical paging buttons, 4 function keys, one main paging key and a red emergency key under safety cover.
• Secure Communication: supports AES67 for audio and AES70 for control; encrypted and authenticated communications.

Specification Highlights

• Built-in Chime Tone: supports automatic chime prior to live paging; configurable via system settings.
• Concurrent Live Paging: supports simultaneous live paging from multiple stations for non-overlapping zones.
• Zone Conflict Handling: applies predefined priority/occupancy policies (override/queue/restriction) for overlapping paging requests.
• BGM & Live Paging Mixing (Ducking): background music attenuation (ducking) during paging.
• Zone-based Paging: supports quick multi-zone selection and operations for daily and emergency broadcasting.

More Features / System Functions

• Product Positioning: professional IP network paging console for PAGA/PA systems, designed for safe-area control rooms and operation centers.
• One-touch Emergency Paging: covered red emergency key with anti-misoperation protection; supports press-and-hold or confirmation pop-up (configurable).
• Manual alarm/emergency paging: General Alarm / Gas Alarm / All Clear; zone/group selection, All Call and one-touch paging.
• Microphone & PTT: gooseneck unidirectional microphone with momentary (non-locking) PTT button; release to stop paging.
• Display & Indications: 4.3" TFT shows zone selection, call status and fault indication; status indication for power, operation and fault with acknowledge support.
• Anti-misoperation Protection: emergency key protected by flip cover; user privilege control for emergency/alarm operations.
• Mounting: supports desktop, wall mount and flush (panel) mounting; cut-out dimensions and mounting brackets optional.
• IP Rating: front panel protection IP22 (minimum) for indoor control room environment.
• Cybersecurity Support: meets IEC 62443 requirements for secure access control, configurable user privileges and password policy; minimizes enabled ports/services; integration with PAGA controller for encrypted control.
• Area of Use: designed for safe-area control room applications; for hazardous areas use IECEx/ATEX certified field paging stations as required.
• Alarm Indication: local and external alarm indication on 4.3" TFT with acknowledge/mute support; external alarm inputs/system events indicated via PAGA Controller/Server integration.

Caractéristiques / spécifications techniques

• Modèle: KNPA800miniR
• Dimensions: 213 (L) x 190 (W) x 76 (H) mm (excl. microphone)
• Matériau: ABS
• Certifications: EN 54-16, ISO 7240-16
• Affichage: 4.3" TFT color display
• Microphone: gooseneck unidirectional avec bouton PTT (momentary)
• Paging console: 100-key (10 pages × 10 buttons), 4 function keys, main paging key, guarded red emergency key
• Réseau: PoE support, dual Ethernet ports pour redondance
• Sécurité audio/contrôle: AES67 (audio), AES70 (control) encryption/authentication
• IP Rating: front panel IP22 (indoor)
• Fonctions audio: built-in chime, BGM ducking, parametric EQ, 3.5mm external mic input
• Montage: desktop / wall / flush (panel)
