Explosion-proof manual call point CP125

ATEXfire alarm

- ATEX and IECEX Certified for Zone 1, 2, 21, 22 - IP 66/67 Standards: EN (IEC) 600790 / EN (IEC) 600791 / EN 54 - GRP version also available - Net weight - 4.6 kg - Material - Case: 316L Stainless Steel The CP125 Anti-Screening Manual trigger is ATEX / IECEX certified for use in potentially explosive atmospheres. It can be used in conjunction with a fire alarm system and triggers alarms to alert potential hazard staff, report the need for immediate emergency response, and much more. Also called anti-skimming manual trigger (DMA) or ice-breaking trigger. Optional IEC61508 certification. Ambiant temperature - -40°C to +55°C Feed - max. 500 V AC. 250V DC Waterproofing protection (IP) - Ip66.ip67 Application / usage - ATEX zone ATEX zone - Zone 1/2 Gas class - IIC ATEX protection mode - Ex d (explosion) Certificates - Atex.iecex Frequency (Hz) - 50 / 60hz Material - 316L Stainless Steel Certificat_atex-en_us - NEMKO 13ATEX1563X Certificat_iecex-en_us - IECEX NEM 13.0033X Body colors - Red (RAL3001) Light source - LED LED indicator - 1¨
