Hydraulic load lifting grab BGL-600

Overview
The Bag Grab Lifter is a crane-mounted device designed to lift sacks and similar loose materials. It connects to standard crane systems and is ready for immediate use. The unit provides a controlled lift with an automated locking latch and a compact clamp design.

Functionality
The automated locking latch secures and releases loads without manual intervention, supporting smooth cycle times and reducing handling errors. The clamp combines a compact footprint with high structural strength. Rated lifting capacity is 100 kg, with a grip range of 400–600 mm to accommodate different bag sizes.

Applications

• Manufacturing material handling
• Mechanical processing and workshops
• Warehouses and distribution terminals
• Loading/unloading operations

Safety & productivity
By automating sack handling, the Bag Grab Lifter reduces operator exposure to manual lifting and repetitive strain. This lowers the risk of injury and operator fatigue, contributing to steadier throughput and improved process reliability.

Technical specifications

• Brand: Aardwolf
• Product code / Model: BGL-600
• Lifting capacity: 100 kg (221 lb)
• Grip range: 400–600 mm
• Locking mechanism: automated locking latch
• Compatibility: connects to standard crane systems; ready for immediate operation
• Design: compact clamp with high-strength construction
• Typical applications: manufacturing, mechanical processing, warehouses, distribution terminals
