Redundant power supply AD1500SR series
AC/DCdual-outputDIN rail

redundant power supply
redundant power supply
Add to favorites
Compare this product


Characteristics

Type
AC/DC
Output
dual-output
Mounting
DIN rail
Features
compact
Other characteristics
redundant, robust
Input voltage

Max.: 230 V

Min.: 115 V

Output voltage

24 V, 48 V

Current

Max.: 21 A

Min.: 0 A

Power

500 W

Description

This series includes AD1500-24SR and AD1500-48SR that with 115/230VAC selectable input range and complete protection design. The DIN rail / bracket mounting solution and compact dimensions let the models be suitable for distribution board that supplying power source for PLC, HMI and I/O devices. Long life aluminum electrolytic capacitor, 100% burn-in testing and moisture proof coating to let the industrial power supply series be rugged power supply, robust power supply and heavy duty power supply. All models are RoHS compliance, CE marking and meet UL508 requirement. INPUT Input voltage:115/230VAC Selectable Input frequency:47~63Hz Inrush current: 22A/115VAC (Cold start) 44A/230VAC OUTPUT Hold-up time (Full load@230VAC):20mS Min. Over voltage protection: Autorecovery Overload protection:Power limited Short circuit protection: Autorecovery Features Innovative design of industrial-grade power supply rail Natural convection air cooling High voltage protection Current overload protection Short circuit protection Din rail / retainer lock with fixed protection Selective warning signals (dry contact) / redundancy High power density High reliability Small size, high efficiency, low cost Comply with RoHS / UL / CE Standard 3-year quality warranty Operating Environment Operating temperature: -40 to 50 degrees Operating humidity: non-condensing 5% to 95% relative humidity
