Round tube connector 30210 0201 04

cast aluminumquick

can be used vertically or horizontally, connected to pipe or to hose, and threaded connection available, design traps water and does not allow water to enter downstream point of use. Technical Specification Suitable fluids compressed air (oil-free, wet or lubricated), vacuum, inert gases (Argon, Nitrogen, Helium), Contact us for a complete list of suitable fluids. Maximum working pressure 15 bar* from -20°C to +80°C vacuum level: 1 mbar (absolute pressure). *maximum working pressure for 200 mm is 13 bar Lubricant compatibility Compatible with all types of mineral and synthetic compressor oils. Resistance to Corrosion, aggressive environments, mechanical shocks, thermal variations and UV for outdoor applications. Fire resistance Fittings are all in aluminium, non-flammable and with no propagation of flame. Materials piping is made of 6063-T5 calibrated alloy aluminium and is powder coated outside, pipe, fittings, and valves are available silicone-free.
