Interface software ALP programming environment

monitoringprogrammingsimulation

akYtec ALP software tool is a programming environment for akYtec programmable relays. Projects for programmable relays are written in the programming language FBD (Function Block Diagram) and ST (Structured text) according to IEC 61131-3. akYtec ALP is completely free. The algorithm is created in the FBD functional block language using ready-made components: - Logical functions: AND, OR, NOT, etc. - Arithmetic operations: ADDITION, MULTIPLICATION, COMPARISON, etc. - Functional blocks: COUNTERS, TIMERS, PID controller, etc. User-defined functions and function blocks in ST text language with support for: - Calling other functions and FBs inside the FB - Local one-dimensional arrays The ALP interface and help are completely in English and German. The help contains a complete description of the function blocks. Working with the interface and all the capabilities of ALP are described in detail. The ALP environment allows you to create your own functional blocks - macros. The created macros can be used in other projects as ready-made functional blocks. This significantly reduces the time for developing algorithms and the workspace on the canvas. You can debug the project without a connected device. For this purpose, a project simulation function has been added to the ALP environment. Online debugging reduces project debugging and commissioning time. You can store macros in your own offline macro database in the ALP environment. In addition to its own macros, ALP has an online database of ready-made macros. These are ready-made counters, analog conversions, regulators, macros for ventilation and pump control.
