3-axis machining center GS 600/5-T

vertical

Working range Travel X/Y/Z-axis 460 / 600 / 400 mm Distance spindle-table min./max. 150 / 550 mm 4th and 5th NC-axis (integrated) Clamping surface (round table) ø 320 [400 x 400] mm 4 T-slots (DIN 650) 4 x 14 H12 Radial T-slots [parallel] 4 x 90° [5 x parallel] Maximum table load 500 kg C-Axis Rotary-Diameter at A-Axis Center Ø 640 mm A-Axis Swivel Diameter (Swing) at X-Axis Center Ø 800 mm Table surface below A-Axis 100 mm Swivel range of the A-axis ± 140° Rotation range of the A-axis 360° RPM max Rotary-Table 100 U/min Drive system Digital AC servo motors Maximum rapid travel X/Y/Z at TCP 30 [60] m/min Maximum feed force X/Y/Z (40% Power-On-Duration) 4 - 5 - 5 kN Main spindle motor High frequency motor spindle Tool clamping: ISO-Taper HSK-A63, DIN 69 893 Maximum drive power (25% Power-On-Duration) 26 [16] [44] [17] kW RPM range : variable. 18.000 [10.000] [30.000] [42.000] [42.000] rpm Maximum torque (25% Power-On-Duration) 82 [102] [40] [11] Nm
