Monitoring control system ESEP

processautomationquality

Description
The ESEP is a complete automation concept engineered for the annular gap expander. It consolidates more than twelve years of process and automation know‑how into two core elements: a switch cabinet housing a Siemens S7 PLC that performs the main control and regulation, and a PC‑based visualization and operator station (Windows / InTouch). The switch cabinet should be installed close to the machine for direct process control, while the HMI can be placed remotely via Ethernet to the control room. ESEP supports monitoring of up to three expander lines and includes a variant optimised for KAHL extruder OEE and the crown expander.

Applications and Advantages

• Full automation of the complete expander line
• Consistent product quality at high throughput
• Reduced manpower requirements and clearer operator tasks
• Visualization and monitoring of up to three lines on a single PC
• Improved process monitoring and traceability
• High availability using proven industrial components
• High process flexibility — adjustable and extensible
• Fast and cost‑effective commissioning
• Fieldbus integration to reduce installation costs

Technical specifications

• Automation concept specifically for annular gap expander
• Over twelve years of process and automation expertise integrated
• Two main components: switch cabinet with Siemens S7 PLC and PC-based visualization/operation station
• Visualization implemented with Windows and InTouch (Wonderware)
• Primary process control and regulation executed in the switch cabinet
• Up to three expander lines can be displayed and monitored on a single operating station
• Communication between PLC and PC via Ethernet (HMI can be installed in the control room)
• Variant available optimised for KAHL extruder OEE and crown expander
• Supports requirements of modern production management (monitoring, OEE, traceability)
