Process control system as1

regulatingweighingautomation

Overview
The as1 Control System is an industrial plant control solution for asphalt production, delivering automated mix production, data reporting and remote access. Developed for both batch and continuous plants, as1 supports operators with clear controls and business-relevant information.

as1 Control System (General)
as1 provides fully automated mix production while allowing safe manual operation. The system collects statistical data, generates built‑in reports and enables remote data access via the Internet. Key functions include unlimited recipe management, dynamic in‑flight correction, automatic burner control and full integration of electrically heated bitumen storage tanks.

as1 Control System for Batch Mixing Plants
For batch plants the system improves production consistency and process transparency. It supports locking of silo loading to prevent material mixing, composite or individual feeder proportion adjustment during production, automatic burner step‑up/step‑down control and burner diagnostics via trend graphics. Additional features include production lists for sequential processing, support for various dosing systems, automatic optimisation of aggregate‑to‑bitumen ratio, a feeder calibration wizard and convenient onscreen recipe selection with on‑the‑fly recipe change.

Highlights (Batch)

• Extensive statistics with daily reports and trending tools
• Silo loading lock based on bin content to prevent material mixing
• Composite or individual feeder proportion adjustment during production
• Fully automatic burner step‑up and step‑down
• Automatic burner control for consistent mineral temperatures
• Burner diagnosis through trend graphics and status display
• Production lists for successive processing
• Support for various dosing systems
• Automatic optimisation of aggregate‑to‑bitumen ratio
• Automatic correction of in‑flight parameters
• Dynamic switch point from coarse to fine batching
• Feeder calibration wizard
• Onscreen recipe selection and on‑the‑fly recipe change
• Automatic batch reduction during warm‑up
• Automatic loading bin control
• Remote maintenance access and online diagnosis
• Automatic connection to the Ammann service platform

as1 Control System for Continuous‑Mixing Plants
For continuous plants as1 enables gapless production and operational preselection. Features include multiple production pre‑selection, configurable startup and step‑down ramps, a graphic recipe timing view, automatic loading bin control and silo loading lock to keep materials segregated.

Highlights (Continuous)

• Fully automatic burner step‑up and step‑down
• Automatic burner control for consistent mineral temperatures
• Burner diagnosis via trend graphics and status display
• Multiple production pre‑selection for seamless production
• Onscreen recipe selection and on‑the‑fly recipe change
• Automatic loading bin control and silo loading lock
• Configurable startup and step‑down ramps
• Graphic recipe timing view
• Remote maintenance access and online diagnosis
• Automatic connection to the Ammann service platform

Special modules
Optional Ammann as1 modules extend functionality to meet specific plant requirements, adding features for automation, monitoring and optimisation.

Support & Download (available materials)
Documentation, product literature and the as1 Plant Asset App materials are available for support and download from the manufacturer.

Technical specifications (summary)

• System type: as1 Control System for asphalt plants (batch and continuous)
• Production modes: Fully automated mix production and safe manual mode
• Recipe management: Unlimited recipes, onscreen selection, on‑the‑fly changes
• Batching: Dynamic in‑flight correction, coarse‑to‑fine dynamic switch, automatic batch reduction during warm‑up
• Feeder control: Composite or individual feeder adjustment, calibration wizard
• Silo/bin management: Loading lock based on bin content, automatic loading bin control
• Burner management: Automatic step‑up/step‑down and control, burner diagnosis with trend graphics
• Quality optimisation: Automatic aggregate‑to‑bitumen optimisation, automatic in‑flight correction
• Production continuity: Production lists, multiple production pre‑selection (continuous)
• Start/stop control: Configurable startup and step‑down ramps (continuous)
• Monitoring & reporting: Extensive statistics, daily reports, trending tools, graphic recipe timing
• Connectivity & service: Remote maintenance access, online diagnosis, automatic connection to Ammann service platform
• Integration: Full integration of electrically heated bitumen storage tanks
