Semi-mobile concrete batching plant CBT 60 SL Elba

single-shaftstand-alonecompact

Overview
The CBT 60 SL Elba is a transport‑optimised linear concrete mixing plant designed for fast installation and straightforward relocation. Its compact, folding design allows setup without a permanent foundation on a compacted surface (250 kN/m²). The plant integrates a CEM 1000 S Elba single‑shaft mixer (1000 l) and a linear aggregate bin for 2–4 aggregate types. Cement, water and aggregate scales plus electrical and pneumatic components are pre‑installed and connected. An integrated control cabin houses the switching cabinet and provides space for the control system. With a theoretical output of 60 m³/h, the CBT 60 SL Elba suits a wide range of industrial on‑site concrete applications. Optional cement silo solutions are available.

Key Advantages

• Fast, low‑cost installation using folding assembly
• Pre‑installed and connected sub‑assemblies (mixer platform, linear bins, scales)
• Transport‑optimised design; relocation possible in two open‑top containers

Highlights / Core Data

• Mixer volume: 1000 l
• Theoretical max concrete output (compacted fresh concrete): 60 m³/h
• Integrated single‑shaft mixer model: CEM 1000 S Elba
• Relocation: requires two open‑top containers

Specifications (table)
Type | Max. concrete output compacted fresh concrete [m³/h] | Mixer volume [l] | Active aggregate stock [m³] | Max. components | Max. cement types
CBT 60 SL | 60 | 1000 | 30-50 | 2-4 | 4

Technical characteristics

• Type: CBT 60 SL
• Max. concrete output (compacted fresh concrete): 60 m³/h
• Mixer volume: 1000 l (CEM 1000 S Elba)
• Active aggregate stock: 30–50 m³ (integrated linear bin for 2–4 aggregate types)
• Max. components: 2–4
• Max. cement types: 4
• Relocation: transport‑optimised design; requires two open‑top containers
• All key components (cement, water, aggregate scales, electrical and pneumatic components) are pre‑installed and ready for operation
• Integrated control cabin houses the switching cabinet and provides space for the control system
• Installation without foundation on a surface compacted to 250 kN/m²
• Optional solutions available for cement silo installation
• Designed for accessible service and maintenance
