Modular conveyor belt ZLNI560121

spiralrubbernitrile rubber

Overview
ZipLink® modular spiral-link conveyor belts combine a structured spiral link mesh with a selectable top-cover to create spliceable endless belts without special presses or tools. The low-elongation polyester monofilament carcass provides lateral stability and allows repair or replacement of limited sections, reducing downtime and simplifying maintenance.

Product range summary

• More than 30 belt constructions pairing proven rubber and top-cover materials with a spiral-link mesh that can be spliced at any length.
• The ZipLink® construction eliminates splice-area strength loss because the mesh preserves carcass integrity across joints.

Materials and characteristics
Nitrile

• General characteristics: Thermoset rubber; oil and fat resistance; wear and impact resistance; FDA/USDA compliant options; service temperature -18 °C to 121 °C.
• Main applications: Food processing (meat & poultry, fish, cereal flakes); chemical industry; textile roller covers; cardboard production.

Natural Rubber

• General characteristics: Thermoset rubber; excellent abrasion resistance; good grip in wet and dry conditions; FDA-compliant options; temperature range -40 °C to 121 °C.
• Main applications: Paper and cardboard; wood industry; inclined conveyors; tobacco; agriculture.

Carboxylated Nitrile

• General characteristics: Thermoset rubber; abrasion and oil resistance; good wet/dry grip; temperature range -18 °C to 121 °C.
• Main applications: Paper and cardboard; wood; sugar industry; detergent powders; metalworking.

SBR

• General characteristics: Thermoset rubber; good abrasion resistance; strong grip; economical; temperature range -40 °C to 121 °C.
• Main applications: General package handling; airport baggage systems; brick and tile; chemical; carton handling.

Silam

• General characteristics: Thermoset rubber; release properties; chemical resistance; FDA/USDA compliant options; continuous temperature -54 °C to 176 °C, intermittent up to -58 °C to 260 °C depending on carcass.
• Main applications: Tyre mixing; chemical industry; shrink tunnels; food processing; leather and textiles.

Teflon (PTFE)

• General characteristics: Thermoplastic; excellent release and chemical resistance; good oil/fat resistance; FDA options; limited abrasion resistance; temperature range -50 °C to 82 °C.
• Main applications: Extrusion; food industry; chemical processing; fiberglass production.

Cotton / Felt

• Characteristics: Suitable up to 120 °C.
• Main applications: Tyre industry; cardboard; metal stamping; automotive; aluminium extrusion.

Fabric top-covers

• Characteristics: Low friction coefficient for high-speed running. Specific constructions include ZipLink® bridge raiser belts for extreme conditions (high humidity, high temperature, high speed).
• Main applications: Logistics (merge and infeed); corrugated board (bridge raiser).

Featured product (example)
Article Code | Description | Belt thickness | Hardness top side | Info
ZLNI560121 | Nitrile EZP 10/1 01+C37 brown | 6.3 mm | 50A Shore | datasheet available

Technical specifications / Notes

• Series: ZipLink® (spliceable spiral-link mesh conveyor belts).
• Available constructions: 30+ combinations of top-covers and spiral-link mesh.
• Carcass: Low-elongation polyester monofilament for lateral stability and easy tracking.
• Typical temperature ranges by material provided above; compliance (FDA/USDA) depends on specific construction.
• Operational benefits: in-place splicing, sectional repair/replacement, elimination of splice-area weakness.
