CNC lathe QKA1226

horizontal2-axis4 tools

This series of lathe machine bed adopts high standard cast iron (HT300) one molding casting, guide way width is 755mm, processed by the second aging treatment, it owns the characters of stable performance, good rigidity, anti-vibration ability. Spindle bore diameter is 275mm, machined pipe diameter is 260mm. Two-point supported spindle with precision heavy-duty bearing, spindle speed is the automatic segmented gear shift control by the M code, stepless within segment controlled by the S code, achieving stepless speed and constant linear cutting. X-direction and Z-direction using precision ball screw assembly ensures a high processing accuracy, positioning accuracy and accuracy of retention. longitudinal (Z) feeding carried out by AC servo motor mounted on the left side of feed box drives the ball screw via planetary gear box. (X-direction) feeding carried out by AC servo motor mounted on the saddle back drives the ball screw via flexible coupling. Before delivery all the lathe machines are tested with British RENISHAW laser detector for dynamic accuracy detection and compensation, ensured they have a high positioning accuracy and repeat positioning accuracy. Standard configuration is with the 4-station turret which is free lifting and tool changes quickly and easily, a vertical 4,6 station and horizontal 6,8 station and other electric turret can be chosen. Tailstock is electric motor driven type, it can move automatically and quickly, manual type tailstock also can be selected according to users’ need. hook drag. The main motor is high-power AC variable frequency motor with frequency converter, the output is large and big range of speed.
