Radar level transmitter 3051L

for liquidsHART4-20 mA

Direct mount or use a Tuned-System™ assembly that optimizes performance and reduces temperature effects by 10-20% for improved response time by over 80% versus traditional installations. Built-in diagnostics detect electrical loop issues and alert you to corrosion, water in the housing, or unstable power supply. Available with a graphical, back-lit display, Bluetooth® connectivity, Level specific configuration and enhanced software capabilities designed to access the data you need faster than ever before. Specifications Process Temperature Range Based on fill fluid: Communication Protocol 4-20 MA HART®, WirelessHART®, FOUNDATION™ fieldbus, PROFIBUS® PA, 1-5 V Low Power HART® Seal System Type Direct Mount, Tuned-System Transmitter Connection Welded-Repairable Process Connection Flanged: ANSI/ASME, EN/DIN, JIS Process Wetted Material 316L SST, Alloy C-276 Tantalum Diagnostics Basic Diagnostics Process Alerts Loop Integrity Diagnostics Plugged Impulse Line Diagnostics Certifications/Approvals SIL 2/3 certified to IEC 61508 by an independent 3rd party, NACE®, hazardous location, see full specs for complete list of certifications Wireless Update Rate1 sec. to 60 min., user selectable Power Module Life Up to 10-year life, field replaceable (order separately) Wireless Range Internal antenna (225 m) Features Tuned-System Level assembly and direct mounting produce optimal performance for level applications Application specific configuration allows you to transform your pressure transmitter into a level transmitter with volume calculations Complete level assemblies are leak-tested and calibrated to reduce leak points up to 70% and simplify installation
