SSI-CEB motherboard Pro WS C621-64L SAGE

Intel® XeonIntel® Xeon® WDDR4 SDRAM

Product overview
Intel LGA 3647 CEB workstation motherboard built for professional workloads, supporting multi-GPU configurations, large ECC memory capacities and extensive storage/connectivity options.

Key features

• Single-socket platform for Intel® Xeon® W-3200 and Intel® Xeon® Scalable processors
• Supports up to four double-decked GPUs with PCIe® Gen3 x16 link per supported slot (compatible with NVIDIA® Tesla® and Quadro®)
• 12 DIMM slots, up to 1.5 TB DDR4 with ECC support
• Efficient VRM heatsink with metal-fin-array for improved dissipation
• ASUS Control Center (ACC) support for centralized IT management and remote monitoring
• High-speed interfaces including M.2 (up to 32 Gbps) and USB 3.2 Gen2 Type-A/Type-C up to 10 Gbps

Overview highlights

• 2 x USB 3.2 Gen2 ports (Type-A & Type-C)
• USB BIOS Flash-back button
• 4 x USB 3.2 Gen1 ports
• 2 x Gigabit LAN ports (Intel I210)
• 5 x audio jacks + 1 x SPDIF/out (7.1-channel support)
• Intel LGA 3647 socket: supports Intel Xeon W-3200 and Intel Xeon Scalable processors
• 12 x DIMM slots (DDR4 2933 RDIMM) supporting 6-channel, 2DPC
• 1 x USB 3.2 Gen1 header
• 10 x SATA 6 Gbps ports
• Total 5 PCIe slots:
  • Slot-7: PCIe x16 (Gen3 x16 link)
  • Slot-5: PCIe x16 (Gen3 x16 link)
  • Slot-4: PCIe x16 (Gen3 x4 link)
  • Slot-3: PCIe x16 (Gen3 x16 link)
  • Slot-1: PCIe x16 (Gen3 x16 link) — note: only Intel Xeon W-3200 processors support 64 PCIe lanes
• Intel C621 PCH
• 1 x M.2 connector (supports up to 22110)

Performance and expandability
Supports Intel Xeon W-3200 (up to 28 cores / 56 threads, up to 64 PCIe 3.0 lanes in single-socket) and Intel Xeon Scalable processors on LGA3647. Suitable for compute-intensive tasks such as AI training, deep learning, 3D rendering, media production, simulation and visualization.

Multi-GPU and storage
Design allows four double-decked GPUs with full Gen3 x16 bandwidth on supported slots. NVMe expansion via an ASUS NVMe riser card (expandable to up to four NVMe SSDs) and Intel® VROC support (VROC HW key required for NVMe RAID functionality).

Reliability and memory
ECC memory support for single-bit error detection/correction and 12 DIMM slots enabling very large memory capacities (up to 1.5 TB) for stable professional workloads.

Cooling and thermal design
Multiple dedicated heatsinks, metal-fin-array VRM heatsink, interconnected heat-pipe paths and an M.2 heatsink to lower component temperatures and improve longevity.

Management and software
Includes ASUS Control Center (ACC) for centralized IT management: remote BIOS updates, system monitoring and simplified software deployment.

Technical specifications

• Model name: Pro WS C621-64L SAGE
• Brand: ASUS
• Socket: Intel LGA 3647 (CEB)
• CPU support: Intel® Xeon® W-3200; Intel® Xeon® Scalable
• Chipset: Intel C621 PCH
• Form factor: CEB workstation motherboard
• Memory: 12 x DDR4 DIMM slots (DDR4 2933 RDIMM), up to 1.5 TB, ECC support, 6-channel, 2DPC
• Graphics expansion: Up to 5 PCIe slots (multiple x16 slots with Gen3 x16 links); supports up to four double-decked GPUs
• Storage: 10 x SATA 6 Gbps; 1 x M.2 (supports up to 22110); supports ASUS NVMe riser card (up to 4 NVMe SSDs)
• Networking: 2 x Intel Gigabit LAN (Intel I210)
• USB: 2 x USB 3.2 Gen2 (Type-A & Type-C), 4 x USB 3.2 Gen1, 1 x USB 3.2 Gen1 header
• Audio: 5 x audio jacks + 1 x SPDIF/out, 7.1-channel support
• Cooling: Metal-fin-array VRM heatsink, multiple heatsinks and heat-pipe; M.2 heatsink included
• Special features: ASUS Control Center support, SafeSlot PCIe reinforcement, USB BIOS Flash-back
• NVMe RAID: Intel® VROC supported via RSTe; VROC HW key required
• Notes: Only Intel Xeon W-3200 processors support 64 PCIe lanes (affects PCIe lane allocation)
